Toshiba Satellite 2805-S401 Specifications

TOSHIBA
Satellite ® 2805 Series
Product Highlights:
Performance:
Satellite 2805-S401. Mobile Intel®
Pentium® III processor featuring Intel
SpeedStep™ technology 700MHz,
128MB SDRAM, expandable to
384MB, and a 20BB HDD.
Satellite 2805-S301. Mobile Intel®
Pentium® III processor featuring Intel
SpeedStep™ technology 650MHz,
128MB SDRAM, expandable to
384MB, and a 10BB HDD.
Satellite 2805-S201. Mobile Intel®
Celeron™ processor 650MHz, 64MB
SDRAM, expandable to 320MB, and a
6BB HDD.
Connectivity: LAN- and Internet-
ready with 10/100 Ethernet and
V.90/K56flex modem ports, allowing
broadband access
Enhanced Multimedia: 15" (2805-
S401), 14.1" (2805-S301), 13.3"
(2805-S201) TFT active-matrix
display; 8X max. DVD-ROM, S3
Savage/IX graphics controller; and a
booming subwoofer for a full
multimedia experience
All-in-one, stylish design: built-in 8X
DVD-ROM, 20BB (2805-S401), 10BB
(2805-S301), or 6BB (2805-S201)
hard disk drive, and diskette drive --
no swapping required
Productivity Tools: Toshiba Active
Menu, FreedomWare, and
Great Software Offer
Advanced Service & Support:
Toshiba's suite of services is ready
whenever and wherever you are;
on-line support,
VirtualTech™
Toshiba software updates. Optional
SelectServ™ extended warranty,
SystemGuard™ and other programs
to protect your investment
Product Specification
Processor
Mobile Intel® Pentium® III processor featuring Intel
SpeedStep™ technology, 700MHz (2805-S401) or
650MHz (2805-S301); Mobile Intel® Celeron™
processor 650MHz (2805-S201)
256KB Level 2 cache integrated on die (Mobile
Pentium III models)
128KB Level 2 cache integrated on die (Celeron
model)
Integrated co-processor
Data/Address Bus Width: 64-bit/32-bit
100MHz Front Side Bus
Memory
128MB SDRAM expandable to 384MB (2805-S401
and 2805-S301); 64MB expandable to 320MB
(2805-S201)
Internal memory expansion slot
128 Mbit PC100 SDRAM . 3.3V
BIOS
APM V1.2; ACPI V1.0b; PnP V1.0a; VESA V2.0;
DPMS; DDC2b; SM BIOS V2.3, PCI BIOS V2.1
System Architecture
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 2000 TAIS satellite_2805series_spec.doc Rev. 8 04/24/01
PCI Bus V2.2
Hard Disk
20BB (2805-S401), 10BB (2805-S301), or 6BB
(2805-S201) hard drive, Enhanced IDE, 2.5"
Service removable
9.5 mm height
13ms average access time
Supports PIO Mode4 or Ultra DMA33 Mode2
Diskette Drive
Built-in 3.5", 1.44MB
DVD-ROM
Built-in 8X max. speed
110ms average access time
4469/10816KB/sec maximum data transfer rate
(DVD Mode)
1545/3600KB/sec maximum data transfer rate (CD
Mode)
Compatibility: DVD-ROM, DVD-R, CD-ROM, CD-R,
CD-RW
Video
S3 Savage/IX Graphics Controller
64-BIT graphics accelerator
2x AGP bus
128 BitBLT hardware
8MB internal video memory
Display
15.0" diagonal (1024 x 768) with 2805-S401
14.1" diagonal (1024 x 768) with 2805-S301
13.3" diagonal (1024 x 768) with 2805-S201
Internal display supports up to 16M colors at 1024
x 768
External Color Support
800 x 600 and 640 x 480; 60/70/85Hz Non-
Interlaced @ 16M
1024 x 768; 60/70/85Hz Non-Interlaced @ 16M
1600 x 1200; 60/70/85Hz Non-Interlaced @ 64K
Audio
Yamaha YMF754B-R
3D sound support with HRTF 3D positional audio
Toshiba
16-bit stereo, .WAV and Sound Blaster® Pro
compatible, MIDI playback
2 built-in stereo speakers with subwoofer
64-channel wavetable music synthesis
Full duplex sound support
Hardware acceleration for DirectMusic and
DirectSound
Microphone and Headphone ports
Communications
Integrated V.90/K56flex modem
Integrated 10/100 Ethernet
Keyboard
Full sized 85 keys with 12 function keys
2.7mm travel
Dedicated Windows® keys
Integrated AccuPoint® II pointing device with scroll
buttons
User Control Keys
Control buttons for CD/DVD playback functionality
Play / Pause
Stop / Eject
Next
Previous
Internet button
Expansion
Two PC Card slots support two Type II or one Type
III PC Cards
SVGA video port
TV-Output
PS/2™ mouse/keyboard port (Y-connector
supported)
Two Universal Serial Bus port
ECP parallel port
Headphone jack, Microphone port
RJ-11 port
RJ-45 port
Dimensions (LxWxH)
12.9" x 10.9" x 1.6" (15.0" models)
12.9" x 10.7" x 1.5" (13.3", 14.1" models)
Weight
7.74 lbs. (15.0" model)
7.30 lbs. (13.3", 14.1" models)
Power Supply
60W Autosensing External AC Adapter
100-240V input voltage
50-60Hz frequency
5.51"L x 2.95"H x 0.98"W, 0.7 lbs
Battery
Rechargeable, removable Lithium Ion battery
(10.8V, 4,000mAh)
2.0+ hours battery life
Recharge time: 3 hrs unit off, 4-10 hrs unit on
ACPI V1.0b support
Battery life may vary depending on applications,
power management settings and features utilized.
Recharge time varies depending on usage.
System Management
ACPI V1.0b Power Management
Toshiba Configuration Builder-customized software
image tool
Year 2000 Compliance: NSTL Hardware Tested
Security
Power-on password
Cable lock slot
SecureSleep (Screen Blank)
Keyboard Lock
Memory, HDD and Modem (by screw only)
Operating System
Microsoft® Windows Millennium Edition
Additional Software
Lotus® SmartSuite Millennium Edition (Retail
models only)
Customizable Toshiba/My Yahoo! Start Page
Microsoft Internet Explorer
MediaMatics DVDExpress
Toshiba Custom Utilities
Satellite Series Online Documentation
Toshiba VirtualTech
Toshiba Great Software Offer: With each Satellite
notebook, you will receive your choice of two
software titles. The software selection includes
titles from the following: Lotus® SmartSuite
Millennium Edition, productivity,
education/reference, creativity and entertainment
titles.
Warranty
1 year parts, labor and battery
Environmental Specifications
Temperature:
O O O
Operating: 5 to 35 C (41 to 95
O O
Non-operating: -20 to 65 C (-4
Thermal gradient:
O
Operating: 15 C per hour maximum
O
Non-operating: 20 per hour maximum
Relative Humidity:
Operating: 20% to 80% non-condensing
Non-operating: 10% to 95% non-condensing
Altitude (relative to sea level):
Operating: -60m to 3,000m (-197' to 9,842')
Non-operating: -60m to 10,000m (-197' to
32,808')
O
F)
O O
to 149 F)
