Connect the board cable to the connector of the machine.
5
Installing the memory
If the memory is not supplied in the printer upgrade kit (AL-10PK), proceed to the "Replacing
the cabinet cover and board cover" subsection.
Before installing the memory, be sure to read the precautions on page 4.
1
Remove the memory from the protective bag.
2
Check the orientation of the connector on the memory board and the connector on
3
the machine, and connect them securely.
Replacing the cabinet cover and board cover
Reattach the board cover in the direction indicated by the arrow.
1
INSTALLING THE OPTIONAL PRINTER UPGRADE KIT
