Samsung SGH-J210 Service Manual
Gsm telephone
Hide thumbs
Also See for SGH-J210:
- User manual (50 pages) ,
- User manual (50 pages) ,
- Quick start manual (7 pages)
Table of Contents
Advertisement
Quick Links
See also:
User Manual
Advertisement
Table of Contents
Related Manuals for Samsung SGH-J210
Summary of Contents for Samsung SGH-J210
-
Page 1: Table Of Contents
GSM TELEPHONE SGH-J210 GSM TELEPHONE CONTENTS Safety Precautions Specification Product Function Array course control Exploded View and Parts List Main Electrical Parts List Block Diagrams PCB Diagrams Flow Chart of Troubleshooting 10. Reference data 11. Disassembly and Assembly Instructions... - Page 2 China china.samsungportal.com Asia asia.samsungportal.com Mideast & Africa mea.samsungportal.com ⓒ This Service Manual is a property of Samsung Electronics Co.,Ltd. Samsung Electronics Co.,Ltd. Any unauthorized use of Manual can be punished under applicable International and/or domestic law. 2007. 11. Rev.1.0...
-
Page 3: Safety Precautions
● Don't use as you pleases after change other material than replacement registered on SEC System. Otherwise engineer in charge isn't charged with problem that you don't keep this rules. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 4 ● You must maintain electric contact between ESD and place due to be set up until ESD is connected completely to the proper place or a circuit board. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 5: Specification
2. Specification 2-1. GSM General Specification G SM 90 0 EG SM 9 00 DCS1800 PCS1900 Ph ase 1 Ph ase 2 Ph ase 1 Fr eq. 8 90~915 8 80~915 17 10~178 5 185 0~1910 Band[MHz] 9 35~960 9 25~960 18 05~188 0 193 0~1990 Uplin k/Down link... -
Page 6: Gsm Tx Power Class
Speclflcation 2-2. GSM Tx Power Class TX Power TX Power TX Power GSM900 DCS1800 PCS1900 control level control level control level 30±3 dBm 33±2 dBm 30±3 dBm 31±2 dBm 28±3 dBm 28±3 dBm 29±2 dBm 26±3 dBm 26±3 dBm 27±2 dBm 24±3 dBm 24±3 dBm 25±2 dBm... -
Page 7: Product Function
- WAP 2.0 / Java MIDP 2.0 - Speaker Phone Function - MP3, AAC+, MP4, 3GPP Decoding (Offline mode) - Video recording & Messaging - Mobile Tracker, My Menu, Living world SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 8 Product Function SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 9: Array Course Control
4. Array course control 4-1. Software Adjustments Jig Cable (GH80-00836A)1.5M Test Jig (GH80-03306A) (GH80-00834A)0.4M Serial Cable(CSA LL64151-A) Power Supply Cable RF CABLE (GH39-00397A) SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 10: Software Downloading
- if the binary file wanted, check only 'BIN' - if the tfs file wanted, check only 'TFS' - if all the files wanted, check 'BIN+TFS' SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 11 Array course control 3. Select the file(s) what you want to download SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 12 Array course control SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 13: Exploded View And Parts List
QMW02 QFR01 QKP01 QJK01 QMI03 QLC01 QME01 QMP01 QMI01 QCA01 QAN05 QSH01 QBR04 QAN02 QSP01 QMO01 QIF01 QCK01 QRE01 QVO01 QSD01 QCR76 QRF01 QBA01 QBA00 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 14: Cellular Phone Parts List
MICRO SPEAKER 3001-002221 QRE01 ASSY CASE-REAR GH98-06290A QCK01 PMO KEY-CAMERA GH72-44801A QIF01 PMO COVER-IF V2 GH72-43256A QSD01 PMO COVER-SD V2 GH72-43257A QVO01 PMO KEY-VOLUME GH72-42305A SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 15 VINYL-BOHO WINDOW GH74-36154A SPONGE GH74-36725A CBF SIGNAL-SPHA560 RF CABLE GH39-00397A 0.4M CBF INTERFACE-SGHT409 TEST CAB GH39-00834A 1.5M CBF INTERFACE-SGHT409 TEST CAB GH39-00836A INSTALL-TEST JIG BOX GH80-03306A SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 16 Exploded View and Parts List SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 17: Main Electrical Parts List
LED709 0601-002265 LED710 0601-002265 LED711 0601-002265 LED712 0601-002265 LED713 0601-002265 LED714 0601-002265 LED715 0801-003012 U100 IC-CMOS LOGIC 0801-003022 U300 IC-CMOS LOGIC 0801-003130 U503 IC-CMOS LOGIC SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 18 R-CHIP 2007-000148 R610 R-CHIP 2007-000157 R300 R-CHIP 2007-000157 R301 R-CHIP 2007-000157 R302 R-CHIP 2007-000157 R304 R-CHIP 2007-000157 R306 R-CHIP 2007-000157 R308 R-CHIP 2007-000157 R314 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 19 R-CHIP 2007-001298 R711 R-CHIP 2007-001298 R712 R-CHIP 2007-001298 R713 R-CHIP 2007-001298 R714 R-CHIP 2007-001298 R715 R-CHIP 2007-001319 R215 R-CHIP 2007-001319 R216 R-CHIP 2007-001333 R401 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 20 C-CER,CHIP 2203-000386 C634 C-CER,CHIP 2203-000425 C419 C-CER,CHIP 2203-000425 C422 C-CER,CHIP 2203-000438 C100 C-CER,CHIP 2203-000438 C107 C-CER,CHIP 2203-000438 C139 C-CER,CHIP 2203-000628 C217 C-CER,CHIP 2203-000628 C218 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 21 C-CER,CHIP 2203-001437 C501 C-CER,CHIP 2203-001437 C508 C-CER,CHIP 2203-003054 C637 C-CER,CHIP 2203-005050 C112 C-CER,CHIP 2203-005050 C113 C-CER,CHIP 2203-005050 C122 C-CER,CHIP 2203-005138 C318 C-CER,CHIP 2203-005138 C319 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 22 C-CER,CHIP 2203-006048 C603 C-CER,CHIP 2203-006208 C405 C-CER,CHIP 2203-006208 C407 C-CER,CHIP 2203-006208 C409 C-CER,CHIP 2203-006208 C411 C-CER,CHIP 2203-006208 C412 C-CER,CHIP 2203-006208 C529 C-CER,CHIP 2203-006208 C535 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 23 C-CER,CHIP 2203-006681 C420 C-CER,CHIP 2203-006681 C425 C-CER,CHIP 2203-006838 C209 C-CER,CHIP 2203-006838 C210 C-CER,CHIP 2203-006838 C640 C-CER,CHIP 2203-006838 C641 C-CER,CHIP 2203-006838 C642 C-CER,CHIP 2203-006838 C704 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 24 CONNECTOR-COAXIAL 3708-002222 CON600 CONNECTOR-FPC/FFC/PIC 3709-001453 T/SIM500 CONNECTOR-CARD EDGE 3710-002499 IFC500 SOCKET-INTERFACE 3711-006084 BATT500 HEADER-BATTERY 4202-001360 ANT100 ANTENNA-CHIP 4302-001181 C418 BATTERY-LI(2ND) GH59-04723A SW700 KEY FPCB-SGHJ200,JOG KEY SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 25 NPR-ANTENNA CONTACT V2 GH71-06570A L104 NPR-ANTENNA CONTACT V2 Please consult the GSPN website (Samsung Portal) for the most recent version of the product's part list. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 26 Main Electrical Parts List 6-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 27: Block Diagrams
7. Block Diagrams 7-1. Base Band Solution Block Diagram Camera Module MOTOR UXGA 13 round tpye 2M pixel LCD(SEHF-Korea) 176 x 220, 1.76"262K TFT RF Block Camera Module SIM CARD SI4221(RF IC) (MV3019) sliding Type, 3V AWT6172 (Power AMP) only Intenna LMG003W-5159A(FEM) PNX52... - Page 28 Block Diagrams 7-2. RF Solution Block Diagram...
- Page 29 Block Diagrams 7-3. BT Solution Block Diagram...
- Page 30 Block Diagrams...
-
Page 31: Pcb Diagrams
8. PCB Diagrams - Main top view SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 32 PCB Diagrams - Main bottom view SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 33: Flow Chart Of Troubleshooting
Resolder OSC400, C419, and C422 U404 14pin (CLK32K)=32KHZ C405(+VDD_IO_LOW) & Check the related circuit C406(+VDD_IO_HIGH) = "H"? +VDD_GSM_CORE Resolder L400 and L401 = 1.2V? Check the initial operation SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 34 Flow Chart of Troubleshooting SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 35 Flow Chart of Troubleshooting SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 36 UCP200 pin C11 (RSTON) ="H"? Replace UCP200 UCP200 pin Change PBA F1(RSTEXTn) or TP310 = "H" ? Check the 16bit data signal & memory CE SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 37 Flow Chart of Troubleshooting SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 38: Charging Part
U404 pin 34(AUX_ON) Resolder or Replace F501 or TP500 = "L"? Resolder R400, R403, and C402 Check the U404 pin 46 ≒ 1.4V Replace ZD400 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 39 Flow Chart of Troubleshooting SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 40 Flow Chart of Troubleshooting SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 41: Sim Part
Resolder or Replace T/SIM500 pin15 of T/SIM500 in a few After SIM card insert, Replace PBA T/SIM500 pin 13 = "H(SIM_RST)"? Check the SIM Card SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 42 Flow Chart of Troubleshooting HCVDD(44) SIMVCC(43) RF2VDD(42) U404 PCF50611HN/02/N2 9-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 43 Flow Chart of Troubleshooting 9-11 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 44: Microphone Part
Mic Active ? Replace C219 and C630 Resolder L600, L601, L700, L701, C632, Check MIC Connection C635, R610 and C634 Check the MIC Replace the MIC 9-12 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 45 Flow Chart of Troubleshooting 9-13 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 46 Flow Chart of Troubleshooting 9-14 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 47: Speaker Part
12(DBVDD), 28(AVDD) Does not work Ringtone and Mp3 ? Replace U601, U603, U605 Resolder C700, C701 and Is Speaker working? Replace ZD713, ZD714 Change Speaker(SPK700) 9-15 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 48 Flow Chart of Troubleshooting 9-16 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 49 Flow Chart of Troubleshooting 9-17 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 50: Key Data Input
Clear Between front and PBA pushed, MAIN_KEY_ON signal is OK? Resolder U400 When one of the keys is pushed, Replace the PBA Is it displayed on LCD? 9-18 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 51 Flow Chart of Troubleshooting 9-19 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 52 Set LCD Contrast on high level level in the Menu? Resolder R607, C623, C624 Is U604 pin 5, 10, 11, 12 Replace U604, IFC500 "H" ? Repalce LCD Module 9-20 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 53 Flow Chart of Troubleshooting 9-21 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 54: Key Back Light
, R711, R712, R713, R714, and R715 Replace LED701, LED702, LED702, LED703 , LED704, LED705, LED706, LED707 , LED708, LED709, LED710, LED711 , LED712, LED713, LED714, and LED715 9-22 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 55 Flow Chart of Troubleshooting 9-23 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 56: Camera Part
Reconnect the camera module connector Resolder C640, C641, C642 CON600 Pin 10,17,18 = H? Replace CON600 Is there another problem? Replace the camera module 9-24 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 57 Flow Chart of Troubleshooting 9-25 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 58: Radio Part
Is FM Sound Working ? Resolder C100, C102, L101, C103 Searching any Channel ? and L500 L100 > 2 V Resolder L100, C104, and C114 Check UCP200 9-26 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 59 Flow Chart of Troubleshooting 9-27 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 60 Flow Chart of Troubleshooting 9-28 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 61: Gsm Receiver
Resolder C115, C116, L111 pin 25 ≥ -70dBm Check & Resolder U104pin 11,12,16,29, U104 pin 4,5,6,7 C131,C134,C135 32,33,36 ≥2.8V ≥ 0.2Vp_p Resolder U104 Check UCP200 9-29 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 62: Gsm Transmitter
OK? Check VBAT or PAM control signal U104pin U104 pin 4,5,6,7 Check U104, 11,12,16,29 ≥ 0.2Vp_p C131,C134,C135 32,33,36 ≥2.8V Resolder U104 Check UCP200 9-30 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 63: Dcs Receiver
22 ≥ -70dBm pin 23 ≥ -70dBm U104pin11,12,16, U104 pin 4,5,6,7 Check & Resolder 29,32,33,36 ≥2.8V ≥ 0.2Vp_p C131,C134,C135 pin 10≥1.8V Resolder U104 Check UCP200 9-31 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 64: Dcs Transmitter
OK? Check +VBAT or PAM control signal U104pin11,12,16,29, Check & Resolder U104 pin 4,5,6,7 32,33,36≥2.8V C131,C134,C135 ≥ 0.2Vp_p pin 10≥1.8V Resolder U104 Check UCP200 9-32 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 65: Pcs Receiver
20 ≥ -70dBm pin 21 ≥ -70dBm U104pin11,12,16, U104 pin 4,5,6,7 Check & Resolder 29,32,33,36 ≥2.8V ≥ 0.2Vp_p C131,C134,C135 Resolder U104 Check UCP200 9-33 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... -
Page 66: Pcs Transmitter
OK? Check +VBAT or PAM control signal U104pin11,12,16,29, U104 pin 4,5,6,7 32,33,36≥2.8V Check & Resolder ≥ 0.2Vp_p pin 10≥1.8V C131,C134,C135 Resolder U104 Check UCP200 9-34 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 67 Flow Chart of Troubleshooting 9-35 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 68: Bluetooth Part
Check for the clock at Resolder C107 C107 check U104 pin8 =26MHz = 26MHz TP102,TP103, TP104,TP105 ≥1.8V check UCP200 Pin B4 ≥ 1.7V(32kHz) replace U101 9-36 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 69 Flow Chart of Troubleshooting 9-37 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 70 Flow Chart of Troubleshooting 9-38 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 71: Reference Data
― QPSK: Quadrature Phase Shift Keying ― RS : Reed-Solomon ― SI : Service Information ― TDM : Time Division Multiplexing ― TS : Transport Stream 10-1 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 72 Reference data 10-2 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 73: Disassembly And Assembly Instructions
MOTOR Braket's HOOK CAMERA 1) Be careful not to make scratch and molding damage! 1) Be careful not to make scratch and molding damage! 11-1 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 74 Sperate Braket from the main PBA. 1) Be careful not to make scratch and molding damage! 2) Beware that you do not damage CAMERA F-PCB. 11-2 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
-
Page 75: Assembly Instructions
1) Be careful not to make scratch and molding damage! 1) Arrange Speaker's WIRE not to be interfered 2) Beware that you do not damage CAMERA F-PCB. with other components. 11-3 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization... - Page 76 1) Set a PBA on the FRONT. 1) Be careful not to make scratch and molding damage! 1) Be careful not to make scratch and molding damage! 11-4 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 77 1) Be careful not to make scratch and molding damage! 2) Check GAP is exist after finish assembly. 2) 1 screw is different other screws. 11-5 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
- Page 78 Disassembly and Assembly Instructions 11-6 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
