SPECIFICATIONS
1201URX/AB - 1201URX/Si - 1201URX/VM
RF Carrier Frequency Range
Noise Reduction
Effective Operating Range
Frequency Response
RF Sensitivity
Adjacent Channel Selectivity
Image Rejection
IF Rejection
Audio THD
Audio Output
40dBm ± 40kHz Deviation (-20dBm ± 40kHz Deviation for 1201URX\Si)
Output Impedance
Signal/Noise Ratio
Power Requirements
Dimensions
Operating Temperature Range
Weight
1201BT
Output Power
Max Modulation Sensitivity
MIC Level / Imped.
Power Requirements
Dimensions
Weight w/Battery
1201XT
Output Power
Max Modulation Sensitivity
MIC Level / Imped. (Dynamic)
Phantom Power
Power Requirements
3V DC (2 "AA" Alkaline) @ < 180mA - 290 mA w/Phantom Power ON
Dimensions
Weight w/Battery
Due to constant improvements, specifications are subject to change without notice.
Licensing
Licensing of this, or any Azden wireless equipment is the user's responsibility. The ability to receive a license depends largely on the user's classification, applica-
tion and frequency. Contact the appropriate agency (FCC in the USA) for further information.
Azden Corporation, 147 New Hyde Park Road, P.O. Box 10, Franklin Square, NY 11010
tel - 516.328.7500 • fax - 516.328.7506 • email - sales@azdencorp.com
© 2010 Azden Corporation
188 steps ~ 638.125 - 661.875 MHz
MicroComputer Controlled PLL Synth.
Expander (THAT)
200 - 300 ft ~ 60 - 100m
50 - 15kHz (± 1.5dB)
(12dB SINAD) 1.2μV
> 70dB (± 250kHz)
600Ω (300Ω for 1201URX\Si)
> 62dB (± 5kHz Deviation) "A" Weighted
11 - 15V DC @ 220mA (10 - 17V DC @ 200mA for 1201URX\Si)
68W x 84H x 18D mm- 1201URX/Si insertion
93W x 119H x 49D mm - 1201URX/AB
82W x 150H x 60D mm - 1201URX/VM
-50
- +122
F ~ -10
0
0
8.8 ounces ~ 250g for 1201URX/Si
15.87ounces ~ 450g for 1201URX/AB
26.45ounces ~ 750g for 1201URX/VM
-56dBm (± 5kHz Deviation)
3V DC (2 "AA" Alkaline) @ < 150mA
2.48 (W) x 3.86 (H) x 1.12 (D) inches
63 (W) x 98 (H) x 28.5 (D) mm
6.35 ounces ~ 180g
+20dBM ~ 0dBm
-60dBm / 2.2kΩ (± 5kHz Dev.)
48V ±2V @ 2mA
1.57 (W) x 4.49 (H) x 1.57 (D) inches
40 (W) x 114 (H) x 40 (D) mm
6.35 ounces ~ 180g
Printed in USA
User's Guide
> 93dB
> 93dB
< 0.8%
1201URX/AB • 1201URX/VM • 1201URX/Si
ENHANCED BROADCAST PERFORMANCE
- +50
C
0
0
30mW
-4dBm
30mW
P1030-02
1201BT • 1201XT
UHF WIRELESS SYSTEM
