- Page 1 OWNER’S INSTRUCTIONS & INSTALLATION MANUAL AP500PF FLOOR STANDING TYPE AIR CONDITIONER ( Cool ) E S DB68-00054A(1)
-
Page 2: Safety Precautions
Safety Precautions The following safety precautions must be taken when using your air conditioner. Make sure that the indoor unit is correctly ventilated at all times; do NOT place clothing or other materials over it. NEVER spill liquids of any kind into the indoor unit. Should this happen, turn the power switch off and contact your installation specialist. -
Page 3: Table Of Contents
Contents REPARING ONDITIONER Safety Precautions ......................View of the Indoor Unit & Outdoor Unit ................. Remote Control - Buttons ....................Control Panel ........................Getting Started ....................... Inserting the Remote Control Batteries ................. Setting the Time ......................PERATING ONDITIONER Operating Preparation ....................Using the Control Panel on the Indoor Unit .............. -
Page 4: View Of The Indoor Unit & Outdoor Unit
View of the Indoor unit and Outdoor unit AIR FLOW(DIRECTION) ADJUSTING BLADE AIR OUTLET CONTROL PANEL AIR FILTER AIR INLET GRILLE To disassemble the air inlet grille Loosen two fixing screws of left and right. Hold the upper part of the air inlet grille, and then pull it lightly forward. -
Page 5: Remote Control - Buttons
Remote Control - Buttons Temperature adjustment buttons Operating mode selection -AUTO COOL -COOL Fan speed adjustment -TURBO buttons -FAN Air flow swing button On/Off button Control Panel Fan Speed display Fan Speed Time/Temperature Remote control adjustment display Operating Light Sensor ON/OFF Button Power Light Time or Temperature adjustment... -
Page 6: Getting Started
Getting Started You have just purchased a packaged air conditioner and it has been installed by your installation specialist. Your Owner's Instructions contain much valuable information on using your air conditioner. Please take the time to read them as they will help you take full advantage of the unit's features. -
Page 7: Inserting The Remote Control Batteries
Inserting the Remote Control Batteries You must insert or replace the remote control batteries when: You purchase the air conditioner The remote control does not work correctly Use two LR03(AAA) 1.5V batteries. Do not use old batteries, or different kinds of batteries together. Batteries may be completely discharged after 12 months, even if they have not actually been used. -
Page 8: Setting The Time
Setting the Time You can set the time when you purchas the air conditioner. Be sure to reset the time when you change clocks from standard todaylight saving time and vice versa. Press the TIME/TEMP. SELECT button. Result: The TIME indicator flashes. To set the current time, press the TIME/TEMP. -
Page 9: Operating Preparation
Operating Preparation Look around the indoor and outdoor units. Confirm if any obstacles that may prevent the air flow are present near the air conditioner. Remove a protective cover of the outdoor unit. Turn the power switch on. To operate the unit, the power switch is fitted to the IMPORTANT wall must be set to ON. -
Page 10: Selecting The Automatic Operating Mode
Selecting the Automatic Operating Mode You can start the air conditioner in AUTO mode. If necessary, press the ON/OFF( ) button. Result: The power indicator on the control panel comes on. The indoor unit beeps twice. The operation mode previously set is displayed. The air conditioner starts up in the mode selected when the unit was last used. -
Page 11: Cooling Your Room
Cooling Your Room You must select the COOL mode if you wish to adjust the: Cooling temperature Fan speed when cooling If necessary, press the ON/OFF( ) button. Result: The power indicator on the control panel comes on. The indoor unit beeps twice. The operation mode previously set is displayed. -
Page 12: Changing The Room Temperature Quickly
Changing the Room Temperature Quickly The turbo function is used to cool your room as quickly as possible. Example: You have just come home and find that the room is very hot. You wish to cool it down as quickly as possible. The turbo function operates for 30 minutes with the maximum settings before returning automatically to the mode and temperature previously selected. -
Page 13: Airing Your Room
Airing Your Room If the atmosphere in your room is stale, you can air the room using the Fan feature. If necessary, press the ON/OFF( ) button. Result: The power indicator on the control panel comes on. The indoor unit beeps twice. The operation mode previously set is displayed. -
Page 14: Adjusting The Air Flow Direction Horizontally
Adjusting the Air Flow Direction Horizontally Depending on the position of the indoor unit, you can adjust the position of the air flow blades on the top of the unit, thus increasing the efficiency of the air conditioner. You can controll by using remote control. Remote control Press the AIR SWING button on the remote control. -
Page 15: Setting The Off Timer
Setting the Off Timer The Off Timer enables you to set the air conditioner to switch off automatically after a given period of time, by pressing one single button. The unit can be switched off automatically after one hour, two hours, three hours, four hours or five hours. -
Page 16: Recommendations
Operating Recommendation Here is a recommendation that you should follow when using your air conditioner. TOPIC RECOMMENDATION Power failure If a power failure occurs while the air conditioner is operating, it is switched off. When the power returns, you must press ON/OFF( ) to restart it. -
Page 17: Cleaning Your Air Conditioner
Cleaning Your Air Conditioner To get the best possible use out of your air conditioner, you must clean it regularly to remove the dust that accumulates on the air filter. IMPORTANT Before cleaning your air conditioner, ensure that you have switched off the breaker used for the unit. -
Page 18: Solving Common Problems
Solving Common Problems Before contacting the after-sales service, perform the following simple checks. They may save you the time and expense of an unnecessary call. Problem Explanation / Solution The air conditioner Check that the power switch is turned ON. does not operate at all Check that the power light on the control panel is on;... -
Page 19: Technical Specification
Technical Specification Indoor unit Outdoor unit MODEL ITEM AP500PF AX500PF Cooling Capacity BTU/h 49600 Moisture Removal Pts/h Performance 11.83 Ratings Indoor Air Flow (High) 1164.5 Sound rating Power Source ø/V/Hz 3/208-230/60 Power Consumption Electrical 5100 Data Operating Current Max. TD Fuse/Breaker Dimension Dimension W x H x D... - Page 20 THIS AIR CONDITIONER IS MANUFACTURED BY: ELECTRONICS Printed in Korea...
- Page 21 ETHOD NSTALLATION Note: For cooling mode, low ambient kit (ICM326H) must be used when the outside ambient temperature is 70 deg F or less. Be sure to read the installation manual carefully to ensure sufficient realization of the excellent performance of the unit. Be sure to drill a hole in the wall necessary for installation before attempting to install the unit.
-
Page 22: Accessory Parts List
ACCESSORY PARTS LIST ACCESSORY PARTS LIST Connection Parts Others Part Name Q.ty Remarks Part Name Q.ty Remarks Leg holder for indoor unit Insulation for piping Connecting pipe Screw TH M4X12 ø9.52mm TH M4X25 Option (3/8 inch) (Piping box) Connecting pipe Indoor unit fixing holder ø19.05mm (3/4 inch) -
Page 23: Selection Of Installation Place
SELECTION OF INSTALLATION PLACE SELECTION OF INSTALLATION PLACE Indoor Unit Install the unit at a place close to the wall facing the outside as Top view it is necessary to perform piping connection with the outdoor unit. - It is effective to install the unit at a window side to ensure uniform distribution of indoor temperature. -
Page 24: Electrical Work
ELECTRICAL WORK ELECTRICAL WORK The electrical work should be performed by a specialist qualified for the work. Use the three phase power supply, and be sure to install the sub power distributing board for exclusive use with the unit(separately purchased by the user). Avoid octopus-type wiring as it can cause a drop in voltage, thus resulting in poor performance of the automatic control circuit. - Page 25 ELECTRICAL WORK ELECTRICAL WORK When connecting 3Phase 3wires 208 ~ 230V AC 1. Remove cover of electric box on side panel of outdoor unit. 2. Connect electric input wires (R,S,T) to each terminal (R,S,T) of the electric box on outdoor unit respectively. (Input wires are purchased by the user separately.) 3.
-
Page 26: Installation Method
INSTALLATION METHOD INSTALLATION METHOD Installation Procedures 1. Open the inlet grille, and remove the flare nut. 2. Bend the connection pipe to an appropriate length using the spring bender depending upon the installation place. - Allowable pipe length : Maximum 25m(82ft) - Allowable pipe drop distance : Maximum 15m(49ft) - Make no more than ten bending points on the pipe When the pipe length is in excess of the standard pipe length of 5m(16ft 5 in), add the refrigerant... -
Page 27: Connection Of Refrigerant Piping
INSTALLATION METHOD INSTALLATION METHOD Connection of Refrigerant Piping Flare Processing 1. Cut the pipe using the pipe cutter. Oblique Roughness Burr 2. Insert the flare nut into the pipe, and then perform the flare processing. Outer Diameter ø 9.52 mm(3/8") 1.8 mm(7/100") ø... -
Page 28: Drilling A Hole In The Wall
Drilling a Hole in the Wall Drill a hole of 70mm(3 inch) in diameter to the outside. The drilling should be done at a distance of less than 150mm(6 inch) from the floor facing the indoor unit. ø70mm Less than (3 inch) 150mm (6 inch) -
Page 29: Indoor Unit
INSTALLATION METHOD INSTALLATION METHOD Indoor Unit In order to install drain hose through wall, adjust height (max. 150mm/5.91 inch) of the indoor unit using leg holder. Fixing to the floor When using the leg holder of the indoor unit. 1. Lie down the unit on flat floor. Leg holder of 2. -
Page 30: Air Purge
AIR PURGE AIR PURGE Be sure to perform the air purge of the indoor unit, and piping using the refrigerant of the outdoor unit at the time of installation. 1. Connect the charging hose of low pressure side of manifold gauge to the packed valve having a service Outdoor unit Indoor unit port (3/4"... -
Page 31: Refrigerant Charging
REFRIGERANT CHARGING REFRIGERANT CHARGING Air purge(at the time of new installation only) Close the gas pipe side valve by turning it clockwise. Connect the pressure gauge to the low pressure side service valve, and then open the gas pipe side valve again. Connect it to the refrigerant filling tank. -
Page 32: Check And Test Operation
CHECK AND TEST OPERATION CHECK AND TEST OPERATION Check Be sure to check the following again after completion of installation. 1. Check the piping connection area for any gas leakage. Outdoor connection area Indoor connection area 2. Is the drain hose properly connected? Drain hose Indoor and outdoor connection... -
Page 33: Test Operation
CHECK AND TEST OPERATION CHECK AND TEST OPERATION Test Operation After checking, read the owner’s instructions carefully, and perform a test operation. Then deliver the unit to the customer. (When delivering the unit, be sure to read carefully and follow the contents of the owner’s instructions.) CAUTION 1. - Page 34 MEMO MEMO...
