Page 1: Table Of Contents
FLOOR STANDING TYPE AIR CONDITIONER AP500PF SERVICE Manual AIR CONDITIONER CONTENTS 1. Installation 2. Operating instructions and Installation 3. Disassembly and reassembly 4. Troubleshooting 5. Exploded Views and Parts List 6. Refrigerating Cycle Block Diagram 7. PCB Diagrams 8. Wiring Diagrams 9.
Page 2: Installation
1. Installation 1-1 Refrigerant Refill Procedure Refill an air-conditioner with refrigerant when refrigerant has been leaked at installing or using 1. Purge air(for new installation only). 2. Turn the 3-way valve clockwise to close, connect the pressure gauge(low pressure side) to the service valve, and open the 3-way valve again.
Page 3 1-2 “Pump down” Procedure Pump down' shall be carried out when an evaporator is replaced or when the unit is relocated in another area. 1. Remove the caps from the each valve. 2 Turn the 3-way valve clockwise to close and connect a pres- sure gauge(low pressure side) to the service valve, and open the 3-way valve again.
Page 4: Operating Instructions And Installation
2. Operating instructions and Installation 2-1 Operating Instructions 2-1-1 Control system chart Operation Main switch operation Operation of auto, cool and fan Operation of remote Operation of turbo, auto, cool, and fan controller Function selection Auto mode Control of fan motor step according to current temperature Control of cool according to the difference between current Cool mode and desired temperature...
Page 5 2-1-2 Key type and functions 2-1-2(a) PANEL key type and functions Key name Key operating function Key type On/off Start and stop of operation TACT - ON 1 time = operation start, ON again = operation stop. - No continued operation Mode selection Change of the operation mode TACT...
Page 6 2-1-2(b) LED display operating spec. Lamp name Operating spec. Operation lamp - When the power is applied, the lamp goes on and off in an interval of 0.5 seconds. - If the operation is changed to “on”, the lamp stops turning on and off and continues to remain on.
Page 7: Disassembly And Reassembly
3. Disassembly and reassembly 3-1 Indoor unit Parts Procedure Remark Indoor unit Inlet grille 1) Open the inlet grille and remove the connection ring. Main PCB 1) Separate the PCB connect wire after separating the control box cover. 2) Separate the connection wire to separate the front cover and duct.
Page 8 Parts Procedure Remark Front cabi 1) The front cabi should be separated by giving strength downward after loosening 2 screws at the lower end. Plate top 1) The plate top should be separated by loosening screws.
Page 9 Parts Procedure Remark Ass’y grille out 1) First loosen screws at left and right sides of grille out. 2) Then the ass’y grille out should be separated by giving strength upward (↑). & Ass’y duct 1) First loosen the 4 screws at left and right sides. 2) Then the ass’y duct should be separated by lifting it.
Page 10 Parts Procedure Remark Evaporator 1) First separate the cover after loosening the screws fixed at evap cover R. 2) Ten separate the 3 screws fixed at cabinet BKT of evaporator BKT. 3) Evaporator should be separated by flinging ahead.
Page 11 Parts Procedure Remark Motor 1) When the ass’y duct should be separated from the motor, the 2 bracket should be separated first. 2) Then the bolts fixed at the blower and motor shaft should be separated. 3) Then the screws binding the holder top blower and duct should be separated.
Page 12 Parts Procedure Remark 6) Then the motor should be separated. 7) The bracket fixed at the motor should be separated. Panel PCB 1) Should be separated after loosening the insulating material and binders at the back of the front side.
Page 13 3-2 Outdoor Unit Parts Procedure Remark Outdoor unit 1) Packaged air conditioner outdoor unit 2) The binders of the front side should be separated. 3) The flank and the binders should be separated from each other. Control box 1) Connect distributed wires in the control box.
Page 14: Troubleshooting
4. Troubleshooting Troubleshooting First, Items to be checked first Second, Check the corrective actions in the case of occurrence of self-diagnosis mode Third, When the trouble is not related to the 1st or 2nd items above, check the troubled area in detail in accordance with the fault analysis method by symptom.
Page 15: Fault Diagnosis By Symptom
4-3 Fault Diagnosis by Symptom 4-3-1 No power (no display) 1) Checkpoints (1) Is the voltage of the power source normal?(AC 187V - AC 253V) (2) Is the power line in good contact? (3) Check the power fuse(F701, F702) and PCB fuse(F101) for open. (4) Are the primary and secondary sides of the power-trans in good contact with the connector? (5) Is the output voltage of REG1(KA7812) normal?(DC 11.5V - DC 12.5V) (6) Is the output voltage of REG2(KA 7805) normal?(DC 4.5V - DC 5.5V)
Page 16 4-3-2 When the indoor fan motor does not operate. 1) Checkpoints (1) Is the voltage of the power source normal?(AC 187V-AC 253V) (2) Is the indoor fan connector (CN71) in good contact? (3) Is the starting condensor of the fan motor in good contact with the terminal? (4) Is the resistance at both ends of the relay coil approximately 400Ω? 2) Checking procedures(after checking the checkpoints of clause 1) Turn off the power, and then turn it on in 5 seconds.
Page 17 4-3-3 When the compressor does not operate 1) Checkpoints (1) Is the voltage of the power source normal?(AC 187V - AC 253V) (2) Is the desired temperature set at a higher level than the current temperature at the time of “Cool”...
Page 18 4-3-4 When the Remote Controller Does not Operate 1) Checkpoint The sounds “beep” when it receives the signal of the remote control. 2) Checking procedures Turn off the power, and then turn it on in 5 seconds. Is room temperature displayed on the temperature Refer to the checkpoint when the indicator and does the operation start when pressing the power is not supplied.
Page 19: Pcb Inspection
4-4 PCB inspection 4-4-1 Inspection precautions 1) Be sure to check whether the AC sub power switch is removed when removing the main PCB or panel PCB. 2) Do not hold the outside of the main PCB or panel PCB with the hand or apply excessive force to it. 3) When connecting or removing the connector to the main PCB or panel PCB, do not pull the lead wire, but hold the entire assembly with the hand.
Page 20 MEMO...
Page 21: Exploded Views And Parts List
5. Exploded Views and Parts List 5-1 Indoor Unit...
Page 22 Parts List Q’TY CODE NO Description Specification Remark AP500PF DB70-10271A PLATE-TOP SECC-P, -, -, -, -, SC-94445T DB90-10561A ASS’Y-CABI IN AP-1100 DB90-20171B ASS’Y-BASE IN SAH-2017, 2517, SECC-P(20/20) DB91-90012B ASS’Y-DRAIN PART AP-1604CR, - • DB90-40113L ASS’Y-CABI FRONT AP-500PF 5~12 ASS’Y DB90-10175A ASS’Y-CABI FRONT IN...
Page 23 5-2 Outdoor Unit...
Page 24 Parts List Q’TY CODE NO Description Specification Remark AP500PF DB90-10565A ASS’Y-CABI OUT AIR WELD GUARD FAN DB63-30028C GUARD-INLET SC-91438T, - DB67-50067A FAN-PROPELLER AS+GF20, D495, 4BLADE DB95-20137A ASS’Y-MOTOR OUT AP-1100, OSM-6508SRC DB95-20137B ASS’Y-MOTOR OUT AP-1100, OSM-6508SRC WIRE DB90-30028E ASS’Y-MOUNT MOTOR OUT...
Page 25 5-2-2 Control Box-Out Parts List CODE NO Description Specification Q’TY Remark DB93-40272D ASS'Y CONTROL BOX OUT SGCC-M, Z(Z=22) DB47-90004A CAPACITOR START 330VAC 130~156MFD 2501-001098 CAPACITOR OUT 450VAC 40/4uF 2501-001098 CAPACITOR OUT 450VAC 4uF DB34-90057B MAGNET-CONTACTOR DB69-20117B TERMINAL BOARD 600V 35, 15A DB34-90053C MAGNET-CONTACTOR DB26-30001A...
Page 26 5-3 Remote Control Parts List CODE NO Description Specification Q’TY Remark DB93-30026Q ASS’Y-REMOCON AR-C60 DB61-10022A CASE-REMOCON(UPP) DB61-10011A CASE-REMOCON(LW) DB73-20013A RUBBER(BT) DB93-10463A ASS’Y-REMOCON PCB AP-500PF DB64-40008J WINDOW-REMOCON PC T1.5 DB63-10081A COVER BATTERY...
Page 27 MEMO...
Page 28: Refrigerating Cycle Block Diagram
6. Refrigerating Cycle Block Diagram 6-1 Micro Computer Block Diagram Indoor indicators Time condensor INDOOR CONTROL PANEL •Temperature lamp •Cooling lamp Real temperature A/D transformer •Low-medium-high turbo lamp perception sensor(R-TH) •Timer lamp Remote control receiver •Power lamp Lamp examiner •Mode selector lamp: Auto, cool, fan Temperature controller •Outdoor unit motion lamp Compressor controller...
Page 29 6-2 Refrigerating Cycle Block Diagram INDOOR UNIT Heat exchanger (Evaporator) Capillary Heat exchanger Compressor (Condenser) High Pressure S/W OUTDOOR UNIT Additional supplementary amount per meter for extension: When you utilize more than 5m of the tube, you must supplement 50g of R-22 freezing catalyzer gas per additional meter.
Page 30 MEMO...
Page 31: Pcb Diagrams
7. PCB Diagrams 7-1 Ass’y Main PCB (Code No : PD-P500PF-00)
Page 32 Parts List DESIGN LOCATION Description Specification AP-500PF Remark HEAT SINK(L) AL6063 T16.8 W23.5 L30 SPARK-KILLER PCRC420 F701, F702 FUSE FST 250V 5A 20mm F101 FUSE FST 250V 2.0A 20mm VAR1 VARISTOR INR1-D471-SVC471D-10A RY1-RY6 RELAY UT205-12S 250V3A C701 X-CAP 100NK 275VAC CN11 CONNECTOR-WAFER SMW250-03 RED...
Page 33 7-2 Ass’y Panel PCB(Code No : PE-P500PF-P1)
Page 34 Parts List DESIGN LOCATION CODE NO Description Specification Q’ty Remark 2001-000065 R-CARBON RD 1/4 T 103-J CE 04 C 16V 470-M 2401-003107 C-ELECT 2201-000144 C-CERAMIC CK OA 50V T 104-Z DB32-50023A MODULE REMOCON TSOP-1238 TB1 D1-04 DB47-90011A DIODE SW 1N4148 1.2V DB07-10050A LED LAMP LTL-4212 RED T P10.0...
Page 35 MEMO...
Page 36: Wiring Diagrams
8. Wiring Diagrams 8-1 Indoor Unit INDOOR UNIT WIRING DIAGRAM MARK NAME SPARK KILLER VAR1 VARISTOR FAN MOTOR ROOM THERMISTOR SWING MOTOR COMP. DRIVE RELAY SM DRIVE RELAY FAN MOTOR DRIVE RELAY (HIGH) FAN MOTOR DRIVE RELAY (MED) FAN MOTOR DRIVE RELAY (LOW) FAN MOTOR DRIVE RELAY (TURBO)
Page 37 8-2 Outdoor Unit • 3 phase 3 wire 220V MARK NAME COMP MAGNET SWITCH FM1,2 FAN MOTOR C1,2 FAN MOTOR CAPACITOR HIGH PRESSURE SWITCH CRANK CASE HEATER S1,S2 COMP O.L.P BOARD(600V/60A,4P+15A,3P) BOARD (600V/60A,1P+15A,2P) WIRE COLOR...
Page 38 MEMO...
Page 39: Schematic Diagrams
9. Schematic Diagrams 9-1 Indoor Unit...
Page 40 9-2 Remote Control...
Page 41 ELECTRONICS...
