QuickSpecs
Overview
1. 1. 1. 1. Monitor (sold separately)
2. 2. 2. 2. Optical Scroll Mouse (USB)
3. 3. 3. 3. HP Standard Keyboard (USB)
4. 4. 4. 4. Front I/O: (2) USB 2.0, headphone and microphone
5. 5. 5. 5. Not applicable with this model
6. 6. 6. 6. Not applicable with this model
At A Glance
At A Glance
At A Glance
At A Glance
Designed for long-term, networked deployment within medium and large organizations in commercial business,
finance and public sector industries
Created using industry leading Design for Environment standards. Recyclable and energy efficient
" Long purchase lifecycles and image stability for demanding enterprise environments
Support for new Intel technologies introduced in 2006: Intel® Q965 Express chipset
Value-added software
HP Remote Graphics Software (Receiver module)
Altiris Deployment Solution Agent
HP BIOS for better security, manageability and software image stability
Tool-less serviceability features for easier maintenance and repairs
NOTE:
NOTE:
NOTE:
NOTE: HP dc72 Blade Workstation Client is a factory preconfigured model. Vacant bays and slots found internally in the systems
are not supported for use with the preinstalled embedded operating system.
DA - 12705
Canada — Version 1 — February 12, 2007
HP dc72 Blade Workstation Client
HP dc72 Blade Workstation Client
HP dc72 Blade Workstation Client
HP dc72 Blade Workstation Client
7. 7. 7. 7.
Not applicable with this model
8. 8. 8. 8.
240-watt Active Power Factor Correction (PFC) power supply
9. 9. 9. 9.
Rear I/O: (6) USB 2.0, (1) standard serial port, (1) parallel
port, (2) PS/2, (1) RJ-45, (1) VGA, audio in/out
10. (2) low profile PCI slots, (1) low profile PCI Express x1 slot,
10.
10.
10.
(1) low profile PCI Express x16 slot standard
Page 1

Advertisement

Table of Contents
loading

Related Manuals for HP dc72

Summary of Contents for HP dc72

  • Page 1 NOTE: NOTE: NOTE: NOTE: HP dc72 Blade Workstation Client is a factory preconfigured model. Vacant bays and slots found internally in the systems are not supported for use with the preinstalled embedded operating system. DA - 12705 Canada — Version 1 — February 12, 2007...

  • Page 2: Standard Features

    NOTE 2: NOTE 2: NOTE 2: On-site service may be provided pursuant to a service contract between HP and an authorized HP third-party provider, and is not available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.
  • Page 3 QuickSpecs HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client Standard Features Ports Ports Ports Ports USB 2.0 USB 2.0 USB 2.0 USB 2.0 8 (2 front, 6 rear)
  • Page 4 QuickSpecs HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client Standard Features Graphics Graphics Graphics Graphics NVIDIA Quadro NVS 280 (64MB DH) PCI Graphics Card* NVIDIA Quadro NVS 285 (128MB DH) PCIe x16 Graphics Card*...
  • Page 5 Workstation Client Workstation Client Workstation Client Workstation Client Base unit Base unit Base unit Base unit HP dc72 Blade Workstation Client base unit RW853AW#ABA Localization kit Localization kit Localization kit Localization kit HP Blade Workstation Client country kit Processor Processor...

  • Page 6: After-Market Options (Availability May Vary By Region)

    Monitors Monitors TFTs TFTs TFTs TFTs HP L1506 15 TFT Flat Panel Monitor - Analog only PX848AA#ABA HP L1706 17 TFT Flat Panel Monitor - Analog only PX849AA#ABA HP L1740 17 TFT Flat Panel Display - Analog/Digital PL766AA#ABA HP L1755 17 TFT Flat Panel Display - Analog/Digital...
  • Page 7 NOTES: Dimensions (W x H x L): 13.5 x 4.4 x 14.4 inches; Weight: 5.9 lb Service and Support Service and Support The HP Care Pack service part numbers below covers the HP dc72 Blade Workstation Service and Support Service and Support...

  • Page 8: Technical Specifications

    QuickSpecs HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client Technical Specifications Unit Environment and Operating Conditions Unit Environment and Operating Conditions Unit Environment and Operating Conditions Unit Environment and Operating Conditions...
  • Page 9 PXE, remote configuration, remote control, and F10 Setup support for 12 languages. Stability - HP BIOS supports the HP stable product roadmap by releasing only critical BIOS changes to the factory and advanced change notification.
  • Page 10 QuickSpecs HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client Technical Specifications Flash Recovery with Video 5 Aux Power LED on System PCA Processor ZIF Socket for easy Configuration Record SW...

  • Page 11: Technical Specifications - Audio

    QuickSpecs HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client Technical Specifications - Audio High Definition Audio High Definition Audio High Definition Audio High Definition Audio Type Type Type...

  • Page 12: Technical Specifications - Communications

    QuickSpecs HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client Technical Specifications - Communications Integrated Intel 82566DM Integrated Intel 82566DM Integrated Intel 82566DM Integrated Intel 82566DM Connector Connector Connector...
  • Page 13 NOTE: NOTE: NOTE: NOTE: * Supported resolution is determined by the combination of HP Blade Workstation graphics driver, HP Blade Workstation Client administration software and client graphics driver. When used with multiple displays, orientation can be set in combinations of 1x2, 2x1, 1x3, 3x1, 1x4, 4x1, or 2x2 placement, each in landscape or portrait mode.
  • Page 14 NOTE: NOTE: NOTE: NOTE: * Supported resolution is determined by the combination of HP Blade Workstation graphics driver, HP Blade Workstation Client administration software and client graphics driver. When used with multiple displays, orientation can be set in combinations of 1x2, 2x1, 1x3, 3x1, 1x4, 4x1, or 2x2 placement, each in landscape or portrait mode.

  • Page 15: Technical Specifications - Input/Output Devices

    QuickSpecs HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client Technical Specifications - Input/Output Devices USB Standard Keyboard USB Standard Keyboard USB Standard Keyboard USB Standard Keyboard Physical Physical...
  • Page 16 QuickSpecs HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client Technical Specifications - Input/Output Devices PS/2 Standard Keyboard PS/2 Standard Keyboard PS/2 Standard Keyboard PS/2 Standard Keyboard Physical Physical...
  • Page 17 QuickSpecs HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client Technical Specifications - Input/Output Devices HP PS/2 Scroll Mouse HP PS/2 Scroll Mouse HP PS/2 Scroll Mouse HP PS/2 Scroll Mouse...
  • Page 18 QuickSpecs HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client Technical Specifications - Input/Output Devices HP PS/2 Optical Scroll HP PS/2 Optical Scroll HP PS/2 Optical Scroll HP PS/2 Optical Scroll...
  • Page 19 QuickSpecs HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client Technical Specifications - Input/Output Devices HP USB Optical Scroll HP USB Optical Scroll HP USB Optical Scroll HP USB Optical Scroll...

  • Page 20: Technical Specifications - Environmental Data

    QuickSpecs HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client HP dc72 Blade Workstation Client Technical Specifications - Environmental Data Eco-Label Certifications Eco-Label Certifications Eco-Label Certifications Eco-Label Certifications This product has received or is in the process of being certified to the following approvals and may be...
  • Page 21 RoHS Directive on a worldwide basis. From July 1, 2006, RoHS substances will be virtually eliminated (virtually = to levels below legal limits) for all HP electronic products subject to the RoHS Directive, except where it is widely recognized that there is no technically feasible alternative (as indicated by an exemption under the EU RoHS Directive).
  • Page 22 This information (product disassembly instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.
  • Page 23 Intel and Pentium are U.S. registered trademarks of Intel Corporation. Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
