- Page 1 BitStorm 4800 Express Model 4821-A2 Installation Guide March 2006 Document Part Number: 4821-A2-ZN21-30...
-
Page 2: End User License Agreement (Zhone And Affiliates)
Further, Zhone Technologies reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of Zhone Technologies to notify any person of such revision or changes. - Page 3 Zhone from time to time to control access to or limit use of the Software; (d) sublicensed, rented, leased or lent to third parties; (e) imported or exported into any jurisdiction except in compliance with all applicable laws of the United States and such jurisdiction;...
- Page 4 227.7202-4, U.S. Government Users acquire the Software only with the rights set forth therein. Third Party Licensors. This Zhone End User License Agreement may be accompanied by differing or additional provisions applicable to portions of the Software provided by one or more Licensors ("Licensor Provisions").
- Page 5 Ensure that the four (4) rubber feet supplied with the product have been installed on the bottom of each unit prior to stacking any 26x1 units on top of one another. 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide...
- Page 6 This Class A digital apparatus meets all requirements of the Canadian interference-causing equipment regulations. Cet appareil numérique de la classe A respecte toutes les exigences du réglement sur le matérial brouilleur du Canada. BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30...
- Page 7 POTS splitter installation instructions for details. CE Marking When the product is marked with the CE mark on the equipment label, a supporting Declaration of Conformity may be downloaded from the Zhone World Wide Web site at www.zhone.com. Japan Class A ITE This is a Class A product based on the standard of the Voluntary Control Council for interference by Information Technology Equipment (VCCI).
- Page 8 BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30...
-
Page 9: Table Of Contents
Connecting a Terminal or PC to the Console Port .....29 Connecting a Modem to the Console Port........30 Ground ....................31 Connecting to Power ................32 Chapter 3- LEDs .........................33 LED Locations ..................33 LED Meanings ..................34 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... - Page 10 Chapter A- Connectors and Pin Assignments ..............43 Overview ....................43 DSL Ports Connectors ................44 Port 1 and Port 2 10/100BaseT Connectors ........45 Console Port Connector ...............46 Chapter B- Equipment List ....................47 Chapter C- Technical Specifications .................49 Index ..............................51 BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30...
-
Page 11: Document Purpose And Intended Audience
Provides part numbers for the BitStorm 4800 List Express and related products. Appendix C-, Technical Lists the technical characteristics of the Specifications BitStorm 4800 Express. Index Lists key terms, acronyms, concepts, and sections in alphabetical order. 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... -
Page 12: Related Product Documents
Documentation for the BitStorm 4800 Express IP DSLAM is available on the World Wide Web at www.zhone.com. Document Title BitStorm 4800 Express Model 4821-A2 Command Line Interface Reference Describes the Command Line Interface (CLI) used to configure and monitor the BitStorm 4800 Express. -
Page 13: Chapter 1- Installation
BitStorm 4800 Express IP DSLAM models and features are listed in Table 1, BitStorm 4800 Express Models and Features. Table 1: BitStorm 4800 Express Models and Features Number of Model Number Type Ports 4821-A2-417 ADSL 4821-A2-427 ADSL 4821-A2-447 ADSL 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... -
Page 14: Preparation
The BitStorm 4800 Express operates from a 90 to 265 VAC, 47 to 63 Hz power source. Cabling No cable except the power cable is provided with the BitStorm 4800 Express. See Table 2, Cable Descriptions, to determine what cables you need to procure before installation. BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30... -
Page 15: Cables Required
PC, but normally is a emulation program, or DB9 socket. The other connector A modem. depends on the serial port on your modem, but normally is a DB25 plug. A null modem (crossover) cable is required. 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... -
Page 16: Unpacking The Hardware
23-inch (584 mm) rack (including Bay Networks and Nortel) Hardware kit If anything is missing, notify your sales representative. Before installing the BitStorm 4800 Express, read the Important Safety Instructions in the beginning of this document. BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30... -
Page 17: Mounting Configurations
1 Locate the black screw nearest the front panel on each side of the unit, as shown. 2 Remove these two black screws (one from each side) before attempting to install the mounting brackets. 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... - Page 18 3 Identify six flat-head screws (for 19-inch racks) or six machine screws (for 23-inch racks) provided with the mounting brackets in the hardware kit. 4 Attach the brackets appropriate to your rack size. Tighten all screws firmly. BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30...
-
Page 19: Installing The Bitstorm 4800 Express Into A Rack
BitStorm 4800 Express will be fastened. 02-17070 2 Place the unit so that the brackets rest against the front of the rails. Insert screws in the bottom screw positions and hand-tighten them. 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... - Page 20 Installation 3 Insert and tighten the screws in the top screw positions, then tighten the bottom screws. BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30...
-
Page 21: Installing The Bitstorm 4800 Express On A Wall
3 Locate the supplied Right Side mounting bracket and fasten it to the right side of the unit. 4 Locate the supplied Left Side mounting bracket and fasten it to the left side of the unit. 5 Tighten all screws firmly. 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... - Page 22 The screws should freely slide into the top of the key slots in the brackets. Do not fasten the unit to the wall until after it is completely cabled and tested. BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30...
-
Page 23: Installing The Bitstorm 4800 Express On A Shelf Or Desktop
4 Turn the unit right side up and place it in position on a shelf or desktop. If the installation includes more than one unit, one can be stacked atop another. Up to five units can be stacked together. 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... - Page 24 Installation BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30...
-
Page 25: Chapter 2- Cabling
DSL Ports on page 26 10/100BaseT Uplink (Port 2) on page 27 Management Port on page 28 Console Port on page 29 Ground on page 31 Connecting to Power on page 32 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... -
Page 26: Dsl Ports
4 Tighten the cable tie around the connector and trim the excess. 02-17084 5 For a 48-port model, repeat Step 1 through Step 4, substituting DSL Ports 25–48 for DSL PORTS 1–24. BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30... -
Page 27: 10/100Baset Uplink (Port 2)
To use Port 2 as the uplink: 1 Connect an 8-position modular cable to Port 2. 2 Connect the other end of the cable to the uplink interface, such as an Ethernet switch. 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... -
Page 28: Management Port
2 If the BitStorm 4800 Express is in a rack, fasten the cable to a rail with a cable tie. 3 Connect the other end of the cable to your Ethernet switch or a network interface card in a PC. BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30... -
Page 29: Console Port
3 Connect the DB9 plug connector to the CONSOLE port socket. The CONSOLE port is ordinarily used only during installation, so do not fasten the connector. 4 Connect the other end of the cable to the serial port of your terminal or 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... -
Page 30: Connecting A Modem To The Console Port
Express is in a rack, dress the cable to the left and attach it to the rail with a cable tie. 4 Connect the other end of the cable to the serial port of your modem. BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30... -
Page 31: Ground
2 Remove the screw marked by the ground symbol ( ) at the right side of the front panel. 3 Fasten the ring terminal to the front panel using the same screw. 4 Attach the ground wire to an earth ground. 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... -
Page 32: Connecting To Power
3 Connect the other end of the power cord to a grounded AC power source. 4 Make sure the STATUS LED on the front panel is ON (green). See Chapter 3-, LEDs. BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30... -
Page 33: Chapter 3- Leds
LED Locations The locations of the System and DSL Port LEDs on the front panel of the BitStorm 4800 Express are shown in Figure 1, Front Panel LEDs. Figure 1: Front Panel LEDs 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... -
Page 34: Led Meanings
DSL ports 1–24 or 1–48) * The RJ45-type connectors for Port 1 and Port 2 bear two LEDs: the left one is the Link LED and the right one is the Activity LED. BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30... -
Page 35: Chapter 4- Configuration
This can be performed using the CLI, SNMP, or the web interface. For more configuration information, see the BitStorm 4800 Express Model 4821-A2 Command Line Interface Reference (for the CLI) and the online Help (for the web interface). 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... -
Page 36: Using The Cli
Enable administrator mode. restart Restart a unit. show Display configuration, statistics, and status. technical-support Display information for contacting technical support. test Test the system. Descriptions of some essential configuration commands follow. BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30... -
Page 37: Configure Management Default Gateway Address
(disabled). Do not configure inband and out-of-band management on the same subnet. subnet_mask – Specifies the subnet mask to be applied to the IP address. The default mask is 255.255.255.0. Example: PDYN# configure management inband address 137.90.127.3 255.255.255.0 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... -
Page 38: Configure Management Out-Of-Band Address
– Specifies the subnet mask to be applied to the IP address. The default mask is 255.255.255.0. Example: PDYN# configure management out-of-band address bootp PDYN# configure management out-of-band address 137.90.127.3 255.255.255.0 BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30... -
Page 39: Bitstorm 4800 Express Startup Procedure
Management Modes The startup procedure for the BitStorm 4800 Express system differs depending on the type of management used: Inband Management – Operates over the uplink. Out-of-Band Management – Operates over Port 1. 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... -
Page 40: Startup Procedure For Inband Management
Using the Web Interface on page Do not configure inband and out-of-band management on the same subnet. 3 Configure routers as necessary to route data from the NOC to the BitStorm 4800 Express. BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30... -
Page 41: Using The Web Interface
For security reasons, it is a good idea to change the default password the first time you use the system. To change the default password for user admin: 1 Click on the System menu tab, then click on Users. The folllowing screen appears. 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... -
Page 42: Configuration / Management / Snmp
System/Management/SNMP screen. To set SNMP parameters: 1 Click on the Configuration menu tab, then click on SNMP. The System/Management/SNMP screen appears. 2 Enter new SNMP parameters as desired. Click on Apply. BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30... -
Page 43: Chapter A- Connectors And Pin Assignments
The following sections provide pin assignments for: DSL Ports Connectors on page 44 Port 1 and Port 2 10/100BaseT Connectors on page 45 Console Port Connector on page 46 Figure 2: BitStorm 4800 Express IP Front Panel 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... -
Page 44: Dsl Ports Connectors
18, 43 19 or 43 19, 44 20 or 44 20, 45 21 or 45 21, 46 22 or 46 22, 47 23 or 47 23, 48 24 or 48 24, 49 BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30... -
Page 45: Port 1 And Port 2 10/100Baset Connectors
Port 1 and Port 2 are 8-pin unkeyed modular jacks for a 10/100BaseT interface. Table 6: Port 1 and Port 2 Pinouts Signal Pin 8 Pin 1 Transmitted Data + 97-15449 Transmitted Data – Received Data + Unused Unused Received Data – Unused Unused 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... -
Page 46: Console Port Connector
The CONSOLE port connector is a DB9 socket connector that supports an EIA-232-E circuit as shown in Table Table 7: Console Port Connector Directio RS-232 Signal Ground Receive Data Send Data Data Terminal Ready In Ground — Ground — Ground — BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30... -
Page 47: Chapter B- Equipment List
QUIPMENT Table 8: BitStorm 4800 Express Equipment List Description Model Number BitStorm 4800 Express Model 4821-A2 Command Line 4821-A2-GB21 Interface Reference (paper copy) BitStorm 4800 Express Model 4821-A2 SNMP Reference 4821-A2-GB22 (paper copy) BitStorm 4800 Express 24-Port IP DSLAM, with North... - Page 48 Equipment List BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30...
-
Page 49: Chapter C- Technical Specifications
Physical Height: 1.75″ (44.5 mm, or 1U as defined in Dimensions EIA-310-C) without feet Width: 17.2″ (437 mm) without mounting brackets Depth: 16.0″ (406 mm) with cables Power 90–265 VAC, 47–63 Hz 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... - Page 50 Model 4821-A2-417: 12 Watts Maximum Consumption Model 4821-A2-427: 26 Watts Maximum Model 4821-A2-447: 40 Watts Maximum Weight Model 4821-A2-417: 11.2 lbs (5.1 kg) Model 4821-A2-427: 11.2 lbs (5.1 kg) Model 4821-A2-447: 10.7 lbs (4.8 kg) BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30...
-
Page 51: Index
27 CO grounding screw 31 Command Line Interface (CLI) 36 earth ground 31 commands 36 EIA-232-E 46 community strings 42 Electromagnetic Compatibility (EMC) 49 configuration 35 EMS 39 CLI commands 37 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide... - Page 52 11 unit on wall 21 interfaces 49 package contents 16 part numbers 47 jack screw 26 password 39 changing 41 default 39 PC cabling and settings 29 physical dimensions 49 LEDs 33 BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30...
- Page 53 23 shipping carton 16 site preparation 14 site requirements 14, 49 SNMP, configuring parameters 42 specifications product 49 stacking 14 startup procedures 39 Status LED 34 synopsis of chapters 11 4821-A2-ZN21-30 BitStorm 4800 Express Model 4821-A2 Installation Guide...
- Page 54 BitStorm 4800 Express Model 4821-A2 Installation Guide 4821-A2-ZN21-30...
