Vauxhall Meriva Quick Reference Manual

Vehicle features
Manual transmission: Automatic transmission:
Reverse: With vehicle stationary, P = Park
depress clutch pedal, press the R = Reverse
release button on the selector lever N = Neutral
and engage the gear. D = Drive
If the gear does not engage, set the Manual mode: Move selector lever
lever to neutral, release the clutch from D to the left.
+
pedal and depress again; then
= Higher gear
-
repeat gear selection.
= Lower gear
Do not grind the clutch
The selector lever can only be
unnecessarily.
moved out of P when the ignition is
When operating, depress clutch on and the brake pedal is applied.
pedal fully. Do not use the pedal as
To engage P or R, press the release
a foot rest.
button on the selector lever.
Electrical parking brake: Opening the bonnet:
Pull switch J, parking brake Pull release lever below instrument
operates automatically with panel on driver's side and return it
adequate force. For maximum to its original position.
force, e.g. when parking with trailer
Press the safety catch beneath the
attached or on inclines, pull switch
bonnet (located slightly to the right
J twice.
of centre) and raise the bonnet.
The parking brake can always be
activated, even if the ignition is off.
Before leaving the vehicle, check
parking brake status.
To release, switch on ignition, keep
brake pedal depressed and push
switch J.
Drive away function
Depressing clutch pedal or
engaging drive gear D (automatic
transmission) and then depressing
the accelerator pedal releases the
electrical parking brake.
Vehicle features
Starting the engine: Refuelling:
Turn key to position 1 Before refuelling, switch off engine
and any external heaters with
Move steering wheel slightly to
release steering wheel lock combustion chambers (identified
by sticker on fuel filler flap).
Manual transmission:
Depress clutch and brake pedal
Switch off mobile phones.
Automatic transmission in P or N
Fuel is flammable and explosive.
with brake pedal depressed
No smoking! No naked flames or
Do not accelerate
sparks.
Diesel engines: turn key to
If you can smell fuel in your vehicle,
position 2 for preheating and
have the cause of this remedied
wait for ! to extinguish
immediately by a workshop.
Turn key to 3 and release
Tyre pressure:
Check tyre pressures, including the spare, every 14 days and prior to any long journey; tyres should be
checked when cold. This also applies to vehicles with tyre pressure monitoring system.
Always inflate the spare tyre to the value specified for full load.
The ECO tyre pressure serves to achieve the smallest amount of fuel consumption possible.
Tyre pressures are shown on a label on the front left door frame.
Tyre pressure data applies to both summer and winter tyres. Incorrect tyre pressures will impair safety, vehicle
handling, comfort and fuel economy and will increase tyre wear.
Refer to Owner's Manual for approved tyres.
Tyre pressure (psi)
Comfort setting for load of
upto 3 people
Secure the bonnet in the upright
Engine Tyres Front Rear
position using the support rod
A14XER All tyres
located at the front of the engine
A14NEL, All except below 33
compartment.
A14NET 225/40 R18
A13DTC All tyres
Closing the bonnet:
Before closing bonnet, press
A17DT All except below 36
support rod into its holder.
225/40 R18
Lower bonnet and allow it to drop
All Temporary spare 61
into the catch. Check bonnet is
engaged.
*KTA-2692*
Fuel filler flap is located at right Engine oil:
rear side of vehicle. The engine oil level is checked
automatically and a vehicle
The fuel filler flap can only be
message (Code 79) appears in the
opened if the vehicle is unlocked.
Driver Information Center (DIC) to
Pull flap at the recess and open.
warn that engine oil needs topping
The fuel filler cap can be retained in
up immediately.
the bracket on the filler flap.
However, check engine oil level
Wipe off any overflowing fuel
manually every 300 miles or prior to
immediately.
long journeys, to prevent damage
Petrol engines - use unleaded fuel
to the engine.
that complies with DIN EN 228.
Check with vehicle on a level
Diesel engines - use diesel fuel that surface. Engine must be at
complies with DIN EN 590. operating temperature and
switched off for at least 5 minutes.
Fuel tank capacity - 54 litres.
Pull out dipstick, wipe it clean,
insert to the stop on the handle,
pull out and read engine oil level.
Insert dipstick to stop on handle
and make half a turn.
Caution: It is the owner's
responsibility to maintain the
correct level of an appropriate
quality oil in the engine.
Tyre pressure (psi) Tyre pressure (psi)
ECO setting for load of For full load
upto 3 people
Engine Tyres Front Rear Engine Tyres
33 30 A14XER All tyres 41 38 A14XER All tyres
30 A14NEL, All tyres 41 38 A14NEL, All except below 36
36 33 A14NET A14NET 225/40 R18
33 30 A13DTC All tyres 41 38 A13DTC All tyres
33 A17DT All tyres 43 41 A17DT All except below 39
39 36 225/40 R18
All Temporary spare - -
61 All Temporary spare 61
-
= Do not use ECO tyre pressure
setting for this tyre.
Meriva

Quick Reference Guide

Refer to Owner's Manual for detailed information.
Illustrations may depict left-hand drive vehicles.
Operation is similar for right-hand drive vehicles.
1. Light switch, fog lights, 11. Infotainment system
headlight range adjustment, 12. Sensor for climate control
instrument illumination 13. Info-Display
2. Side air vents 14. Central locking system,
3. Turn signals, headlight flash, hazard warning flashers,
low beam, high beam, control indicator for airbag
exit lighting, parking lights deactivation
4. Cruise control 15. Traction Control,
5. Instruments Electronic Stability Control,
6. Horn, driver airbag ultrasonic parking assist,
7. Driver Information Center Deflation detection system
8. Steering wheel controls 16. Front passenger airbag
Front Rear 9. Wiper and washer systems 17. Glovebox, fuse box
36 46 10. Centre air vents
46 Vehicle security
39 46
36 46
46
41 46
61
Unlocking To open the tailgate, push the
c
Press button to unlock doors, touchpad switch under the tailgate
load compartment and fuel flap. moulding.
Open doors by pulling the handles.
TS 1692-B-10 / KTA 2692
Depending on the model variant, special equipment
and accessories, the scope of equipment on your
vehicle may differ from the descriptions in this guide.
18. Climate control system
19. Selector lever
20. Electrical parking brake
21. Accelerator pedal
22. Ignition switch with
steering wheel lock
23. Brake pedal
24. Clutch pedal
25. Steering wheel adjustment
26. Storage compartment
27. Bonnet release lever
Locking
Close doors, load compartment
and fuel filler flap.
e
Press button to lock doors and
activate anti-theft alarm system.
e
Press button twice within
10 seconds to deadlock all doors.
Electronic immobiliser is activated
automatically when key is removed
from ignition switch.
February 2010
