Summary of Contents for Cambridge Audio AZUR 550C
- Page 1 Compact disc player User’s manual azur 550C/650C Your music + our passion...
-
Page 2: Table Of Contents
Contents Introduction Introduction ....................2 Thank you for purchasing this Cambridge Audio Azur 550C or 650C CD player. Like all Cambridge Audio products, the 550C and 650C adhere to three core principles – stunning performance, ease of use and Important safety instructions..............3 incredible value. -
Page 3: Important Safety Instructions
Environmentally-friendly design of Energy-related Products the apparatus. (2009/125/EC) Directives when used and installed according to this instruction manual. For continued compliance only Cambridge Audio 11. Only use attachments/accessories specified by the manufacturer. accessories should be used with this product and servicing must be referred to qualified service personnel. -
Page 4: Limited Warranty
Cambridge Audio product, Positioning it can be returned by your dealer to Cambridge Audio or an authorised Cambridge Audio service agent. You will need to ship this product in either Choose the installation location carefully. Avoid placing it in direct sunlight its original packaging or packaging affording an equal degree of or close to a source of heat. -
Page 5: Rear Panel Connections
Please ask you dealer for details. looped out of the Control Bus. Refer to the ‘Custom Installation’ section for more information. * For more information, see the DacMagic page on the Cambridge Audio website: www.cambridgeaudio.com/products.php... -
Page 6: Front Panel Controls
Front panel controls Standby/On Display functions Switches the unit between On and Standby mode. The blue LED will remain bright when the unit is on, becoming dim when the unit is in a special eco-friendly standby mode. The unit consumes less than one watt of power during standby. -
Page 7: Remote Control
Apple devices such as Press the relevant button to play, stop or pause the CD. Apple TV and Apple’s iPod/iPhone/iPad range when docked in a Cambridge Audio or Apple dock. Skip Press and hold the source button that corresponds to... -
Page 8: Operating Instructions
Operating instructions Loading and unloading discs 3. To repeat a specific track, press Repeat twice while the track is playing. ‘Repeat Track’ will appear on the display. Press Play and the 1. Press the Open/Close button. selected track will now repeat until the function is turned off. 2. - Page 9 azur 550C/650C Programming disc play 10. Pressing during playback will take you back to the ‘Program Mode’ stage. Pressing again at this point deletes the program. It is possible to program the 550/650C to play back in any order only the tracks you wish to listen to.
-
Page 10: Filters
Filter settings The 550C and 650C both use the WM8740 Digital to Analogue Converter (DAC) from Wolfson Microelectronics. The 550C uses one stereo DAC, whilst the 650C uses two DACs in dual differential (i.e. one per channel, in an internally balanced mode). These very high quality parts feature a selectable digital filter with two settings. -
Page 11: Custom Installation Use
If the button is held down for a further 12 seconds, an Amp “Mute Standby power consumption <1W Off” command is generated. Dimensions 85 x 430 x 305mm A full code table for this product is available on the Cambridge Audio (3.4 x 16.9 x 12.2”) website at www.cambridge-audio.com. Weight 4.8kg (10.6lbs) Troubleshooting... - Page 12 Cambridge Audio is a brand of Audio Partnership Plc Registered Office: Gallery Court, Hankey Place London SE1 4BB, United Kingdom Registered in England No. 2953313 www.cambridge-audio.com © 2010 Cambridge Audio Ltd...
