Page 1: Air Conditioner
OWNER’S GUIDE READ AND SAVE THESE INSTRUCTIONS AIR CONDITIONER ELECTRONIC CONTROL P/N 309000834 (10/99) -
Page 2: Warranty
Your product is protected by this warranty Your appliance is warranted by White Consolidated Industries, Inc. WCI has authorized Frigidaire Consumer Services and their authorized servicers to perf o rm s e rvice under this warr a n t y. WCI authorizes no one else to change or add to any of these obligations under this warr a n t y. Any obligations for service and part s under this warranty must be perf o rmed by Frigidaire Consumer Services or an authorized Frigidaire serv i c e r. -
Page 3: Table Of Contents
On some models, remove the filter and look at the bottom edge of the air conditioner behind the front grille for the model and serial numbers. Reading these numbers may be easier by using a flashlight or by removing the cabinet front as instructed under “Care... -
Page 4: Important Safety Instructions
• If the air conditioner is to be installed in a window, you will probably want to clean both sides of the glass first. If the window is a triple-track type with a screen panel included, remove the screen completely before installation. - Page 5 4. Move handle in and out to be sure vent is operating properly. Installing the Front Frame Some models require installation of the front panel of the air conditioner included in a decorative kit. To assemble, follow these steps. Before installation, remove the tilt panel from the frame.
-
Page 6: Using Air Conditioner
IMPORTANT SAFETY INSTRUCTIONS before operating this appliance. To begin operating the air conditioner, follow these steps: 1. Plug in the air conditioner. (To prevent electrical hazards, do not use an extension cord or an adapter plug.) 2. Set the exhaust vent to the CLOSED position. - Page 7 Air Conditioner Feature s (continued) STEP 2 — TO CHANGE TEMPERATURE SETTING: Note: Tap or hold either up( ^ ) or down( v ) button until the desired temperature is seen on the screen. This temperature will be automatically maintained anywhere between 60F (15C) and 90F (32C). If you want the display to read the actual room temperature, see step 5.
- Page 8 Air Conditioner Feature s (continued) STEP 5 — TO OPERATE ON FAN ONLY: Note: Use this function only when cooling is not desired, such as for room air circulation or to exhaust stale air.(remember to open the vent during this function, but keep it closed during cooling for maximum cooling efficiency.) You can choose any fan speed you prefer.
- Page 9 Air Conditioner Feature s (continued) STEP 8 — TO INCREASE DELAYED START TIME: Note: Tap or hold the UP arrow( ^ ) to increase delayed start time by .5 hours (up to 10 hours), then in 1 hour increments up to 24 hours.
-
Page 10: Additional Things You Should Know
Figure 3 (VENT) Fresh Air Vent Control The Fresh Air Vent allows the air conditioner to recirculate inside air (OFF), draw air into the room (FRESH AIR) or exhaust stale air to the outside (VENT). See Figures 1, 2 & 3 for this operation. -
Page 11: Care And Cleaning
• Or, instead of washing you may vacuum the filter clean. Cabinet Cleaning • Be sure to unplug the air conditioner to prevent shock or fire hazard. The cabinet and front may be dusted with an oil-free cloth or washed with a cloth dampened in a solution of warm water and mild liquid dishwashing detergent. -
Page 12: Avoid Service Checklist
Window vibration — poor installation. Refer to installation instructions or check with installer. Improper installation. Tilt air conditioner slightly to the outside to allow water drainage. Refer to installation instructions — check with installer. Unit removing large quantity of moisture from humid room. This is normal during excessively...
