Hotpoint HDA3430ZWW Installation Information

HDA3430ZWW—Built-In Dishwasher
Dishwasher Dimensions (in inches)
24
25-1/8*
23-3/8*
34" MIN.
adj. to 35"
21-1/2*
3-1/4
4 (Adjustable)
Electrical Rating
Voltage AC.......................................................120
Hertz ..................................................................60
Total connected load amperage.......................8.6
Calrod ® heater watts.......................................500
For use on adequately wired 120-volt, 15-amp
circuit having 2-wire service with a separate
ground wire. This appliance must be grounded
for safe operation.
Created 8/97
Installation Information
(in inches)
Hot
24-3/4
water
34-1/2±1/4"
line on
Underside
left
of countertop
*Add 1/4" for
*rear insulation
Note: Dishwasher must not be installed more than 10' from sink
for proper drainage. All plumbing and electrical work must be in
accordance with local codes. Dishwasher includes drain hose
and leveling legs.
Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.
This wall area
must be free of
90°
pipes or wires
24"
4 4
MIN.
4
5 5
6
to floor
Plumbing and electrical
2
service must enter
inside shaded area
19" MIN. from wall 24" From wall
24" MIN.
Wood Insert Cut-Out
Dimensions (in inches)
Countertop
90°
Door insert
Electrical
wiring is
3" from
cabinet
Electrical
Access insert
wiring on
6
right
Models/Kits
GPF325 Kit
GPF375 Kit
*Bottom of panel must be notched 1-1/2" x 1/2" to clear
across panel
**Adjustment required to match adjcent cabinets fronts due to
leveling leg adjustment, 4" nominal.
For answers to your Monogram,
Performance Series,
Hotpoint and RCA appliance questions, call
GE Answer Center
R
A
C
B
Panel
A B C Thickness
18-7/8" 23-9/16" 3-11/16" 1/4"
4-1/4" to
18-15/16" 23-5/8"* 3-3/4"** 3/4"
® GE Profile
™ GE Profile, ™ GE,
® service, 800.626.2000.
Listed by
Underwriters
Laboratories
