Hotpoint HDA3500 Specification Sheet

HDA3500/3540N – Hotpoint Built-In Dishwasher
Dishwasher Dimensions (in inches)
25-3/4
24
MAX.
23-3/8
34 MIN.
adj. to 35
21-1/2
3-1/4
4 (Adjustable)
Electrical Rating
Voltage AC............................................... 120
Hertz........................................................
Total connected load amperage............. 8.6
Calrod heater watts max...................
®
For use on adequately wired 120-volt, 15-amp circuit
having 2-wire service with a separate ground wire.
This appliance must be grounded for safe operation.
Specification Created 4/07
450153
Wood Insert Cut-Out Dimensions (in inches)
GE/Hotpoint/RCA
Door insert
Access insert
24-3/4
B
When using GPF325
1/4" custom dishwasher
door and access panel kit.
When using GPF375
3/4" custom dishwasher
door and access panel kit.
Kit
GPF325
GPF375
60
* Bottom of panel must be notched 1-1/2" x 1/2" to clear across panel
500
** Adjustment required to match adjacent cabinet fronts due
to leveling leg adjustment, 4" nominal
Dishwashers Installation
(Pub. 1-G003 pg. 131B) May 12, 1993
Panel Thickness
A
3/4
Front
of
Panel
C
1-1/2
1/2
1/4
Thickness
A B C
18-7/8" 23-9/16" 3-11/16"
18-15/16" 23-5/8"* 4-1/4" to
3-3/4"**
This wall area
must be free of
90°
pipes or wires
24"
4
MIN.
5
Hot
water
34" to 34-3/4"
line on
6
Underside
left
of countertop
to floor
Plumbing and electrical
2
service must enter
inside shaded area
19" MIN. from wall
24" MIN.
Note: Dishwasher must not be installed more than
10 feet from sink for proper drainage. All plumbing
and electrical work must be in accordance with
Panel
local codes. Dishwasher includes drain hose and
leveling legs.
1/4"
Installation Information: Before installing, consult
3/4"
installation instructions packed with product for
current dimensional data.
As an EnErgy STAr
partner, gE has determined
that this product meets the
EnErgy STAr guidelines
for energy efficiency.
Countertop
90°
Electrical
4
wiring is
3" from
4
cabinet
5
Electrical
wiring on
6
right
24" From wall
®
Listed by
Underwriters
Laboratories
