MULTI-PURPOSE SYSTEM
ATNs PVS14 are rugged, lightweight and versatile night vision monoculars,
designed for the most demanding of nighttime applications. The PVS14
can be handheld, head/helmet-mounted for hands-free usage or adapted
to cameras/camcorders. Originally designed for the U.S. military, these
units are of the highest quality in optics, design and functionality. The ATN
PVS14 is an outstanding choice for professional night vision applications.
The industry leading ITT Pinnacle™ Image Tubes utilize a gated power
supply providing truly outstanding performance in high-light or light-
polluted areas. The Pinnacle™ Tubes with gated power supply minimize
any "Halo" effects.
THE PVS-14 BASIC KIT
Head Mount Assembly — Allows for hands-free operation
Brow Pad — Changeable pad for secure head mount fit
Helmet/Head Mount Adapter — Allows the user to position the monocular in
front of either eye
Eye Cup — Prevents the emission of stray light or facial reflections
Soft Carrying Case — Provides convenient storage of PVS14 and accessories
Shoulder Strap — Attaches to the PVS14 carrying case for easy portability
Lens Paper — Used to lightly clean the objective and eyepiece glass surfaces
Day Light Filter — Filters excessive light. Protects objective lens from the
elements
Diopter Lens Cap — Protects diopter lens from the elements
Operator's Manual — Instructional user's guide
Batteries — One 1.5V AA size
INCLUDED
ACCESSORIES
Export Warning: These products are subject to one or more of the export control laws and regulations of the U.S. Government. Pending the model these products are under the control jurisdiction of
either the US Department of State or the US Bureau of Industry and Security US Department of Commerce. Export without proper licensing or consent is strictly prohibited.
1341 San Mateo Ave,
South San Francisco, CA 94080.
HEAD MOUNT
HELMET MOUNT
ASSEMBLY
ASSEMBLY
www.atncorp.com
e-mail: sales@atncorp.com, info@atncorp.com
PVS14-3P
US Military design
ITT Pinnacle™ Image Intensifier Tubes
Multi-Purpose unit
Handheld monocular
Hands-free goggle (optional helmet mount)
Mil-Spec headgear
Manual Variable Gain Control
Limited Two-Year Warranty
SPECIFICATIONS
Magnification
1x
Lens System
F1.2, 26 mm
Proshield Lens Coating
Yes
FOV
40°
Range of Focus
0.25 m to infinity
Diopter Adjustment
-5 to +2
Controls
Direct
Manual Gain Control
Yes
Automatic Brightness Control
Yes
Bright Light Cut-off
Yes
Automatic Shut-off System
Yes
Infrared Illuminator
Yes
IR Indicator
Yes
Low Battery Indicator
Yes
Power Supply
1 x 1.5 V AA type battery
Battery Life
50 hrs
Environmental Rating
Waterproof
MIL-STD-810
Complies
Operating Temperature
-40 to +50 °C
Storage Temperature
-50 to +70 °C
Dimensions
114x56x50 mm / 4.5"x2,2"x2"
Weight
0.3 kg / 0,68 lbs
TUBE SPECIFICATIONS
HIGH QUALITY 3P GEN IMAGE INTENSIFIER TUBE
DESCRIPTION
GENERATION
PHOTOCATHODE TYPE
RESOLUTION, lp/mm *
SIGNAL-TO-NOISE RATIO*
FIGURE OF MERIT
PHOTOCATHODE SENSITIVITY
EXPORT
Pinnacle is a registered trademark of ITT Night Vision
* Specifications are provided for informational purposes only. Actual values may vary
Tel: 800-910-2862, 650-989-5100,
Pinnacle™
3
Thin-Filmed/Auto-Gated
64 - 72
24 typical
1800 typical
2000-2800
N/A for export
fax: 650-875-0129
