AMERICAN TECHNOLOGIES

NETWORK, CORP.

atn pvs7-3A

ATN PVS7-3A available with a quality

made 3rd generation image intensifier tube.

The ATN

PVS7-3A

dependable, high performance night vision

goggle. This model is identical to AN/PVS7

model adopted as a standard issue to US

Army ground troops, designed to assist

viewing and provide reliable service in the

most unfavorable conditions. Full U.S. Mil

Spec body with goggle assembly, soft

carrying case, demist shield, sacrificial filter

for

objective

lenses,

head-mount assembly with 3 brow pads,

lens tissue, neck cord and front lens cap.

OPTICAL

Field of View: 40°

Min. Focus Range: 20 cm

Objective:

Focal Length: 26 mm

F-Number: 1.17

T-Number: 1.3

Eyepiece:

Diopter Adjustment: +2 to -6

Eye Relief: 15 mm

Interpupillary Adjustment 55 mm to 71 mm

MECHANICAL

(Standard goggle without Afocal)

Weight:(Goggle w/Mask Assy): 650 grams/ 1.4 lbs

Dimensions: 140.8 mm long x 155.6 mm wide/

5.54" x 6.12 lbs

ELECTRICAL

Power Source: 2 - AA Batteries (Alkaline) or

1 - BA-5567/U (Lithium)

Battery life: 50 hours

ENVIRONMENTAL

Operating Temperature: - 40 °C to + 50 °C

Storage Temperature: - 50 °C to + 70 °C

Humidity: 90% up to +65 °C for 240 hours

Immersion: 1 meter for 30 minutes

Export Warning: These products are subject to one or more of the export control laws and regulations of the U.S. Government. Pending the model these products are under the control

jurisdiction of either the US Department of State or the US Bureau of Industry and Security US Department of Commerce. Export without proper licensing or consent is strictly prohibited.

American Technologies Network Corp.

1341 San Mateo Avenue, South San Francisco, CA 94080

800-910-2862, 650-989-5100, FAX 650-875-0129

full

robust,

shoulder

strap,

•

Adjustable head mount

•

IR illuminator

•
