ATEN ALTUSEN KW1000 Quick Start Manual

© 2005 ALTUSEN. All rights reserved. All Other trademarks are the property of their respective owners. PAPE-1214-A00
1
Package Contents
The complete KW1000 package consists of:
1
X
• KW1000 KVM over Wireless
• CS Custom KVM Cable Set
Control Unit
1
X
• Software CD • Quick Start Guide
• User Manual
KVM over Wireless (KW1000) QUICK START GUIDE
1 1
X
X
• Power Adapter
1
1
X
X
• Warranty Registration Card
2
System Requirements
This section details the required hardware components for successful installation and use
of the KW1000
Console
• Pentium 3 with 1 GHz processor or higher
• Screen resolution is at 1024 x 768 or higher
Computers
To use and access the KW1000 successfully, your computer requires the following:
• Windows – DirectX 7.0 or higher
• Java – Sunʼs Java 2 JRE 1.4 or higher
3
The KW1000 Unit ( Front View )
1. Reset / FW
2. Tx / Rx
3. Link LED
4. Power LED
5. WLAN
6. WLAN Reset
7. Antenna
1. 2. 3.
Reset / FW TX/AX LINK POWER
4
The KW1000 Unit ( Rear View )
1. PC / KVM
2. Local Console / Video
3. Local Console / Keyboard
4. Local Console / Mouse
5. Power Jack
4. 5. 6.
WLAN WLAN Reset
