INTERFACE
REAR VIEW
⑤ USB 2.0
4-pin USB 2.0 I/O Connector
⑥ Power on/off switch
⑦ DC In
AC Adapter Connector
Pin
1
2
3
4
5
Using vertical drive stand
The supplied vertical drive stand can be used if desired to mount the unit vertically as
shown in the accompanying illustration. When using the vertical drive stand, either the right
or left side of the drive unit can be oriented downward in the stand.
8
En
Name
Ground
Ground
+12 V
+5 V
+5 V
POWER
Vertical drive stand
DC IN
