PAS Rapid Loader
Operator's Manual
MODEL
FOR MODELS:
Users of this equipment risk injury to themselves and others if the unit is used im-
properly and/or safety precautions are not followed. ECHO provides an operator's
manual. It must be read and understood for proper and safe operation. Failure to
do so could result in serious injury.
X7702273505
PAS R
APid
TM
99944200610
SRM-2100SB
SRM-2400SB
SRM-210SB/211SB/225SB
SRM-260SB/261SB
PAS-2100
PAS-2400
PAS-2601
PAS-210/211
PAS-225/225VP/225VPB
PAS-230/231
PAS-260/261
PAS-265/266
PAS-280
WARNING
L
T
TM
oAdeR
RiMMeR
o
PeRAToR
Trimmer Attachment
A
TTAchMenT
'
M
S
AnuAL
X770000335
04/13
1

Advertisement

Table of Contents
loading

Related Manuals for Echo 99944200610

Summary of Contents for Echo 99944200610

  • Page 1 Users of this equipment risk injury to themselves and others if the unit is used im- properly and/or safety precautions are not followed. ECHO provides an operator’s manual. It must be read and understood for proper and safe operation. Failure to do so could result in serious injury.

  • Page 2: Table Of Contents

    Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job- dependability. Read and understand this manual and the SAFETY MANUAL. You will find both easy to use and full of helpful operations tips and SAFETY messages.

  • Page 3: Safety

    PAS R APid oAdeR RiMMeR TTAchMenT PeRAToR AnuAL afeTy WARNING Refer to your Pro Attachment Series or Split Boom Operator's Manual for correct engine fueling, starting and stop- ping instructions. manual safeTy symbols and ImporTanT InformaTIon Throughout this manual and on the product itself, you will find safety alerts and helpful, informational messages pre- ceded by symbols or key words.

  • Page 4: Personal Condition And Safety Equipment

    personal CondITIon and safeTy equIpmenT WARNING Users of this product risk injury to themselves and others if the unit is used improperly and/or safety precautions are not followed. Proper clothing and safety gear must be worn when operating unit. Proper Clothing Physical Condition Wear snug fitting, durable clothing;...
  • Page 5 PAS R APid oAdeR RiMMeR TTAchMenT PeRAToR AnuAL Repetitive Stress Injuries It is believed that overusing the muscles and tendons of the fingers, hands, arms and shoulders may cause soreness, swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high risk for developing a Repetitive Stress Injury (RSI).

  • Page 6: Equipment

    Locate this safety decal on your attachment. Make sure the decal is legible and that you understand and follow the instructions on it. If it cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING instructions for specific information.

  • Page 7: Contents

    The ECHO product you purchased has been factory pre-assembled for your convenience. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts.

  • Page 8: Power Head Shaft/Attachment Lower Shaft Assembly

    power head shafT aTTaChmenT lower shafT assembly 1. Set Power Head/Shaft Assembly on a level surface. 2. Pull locator pin (A) and rotate counter clockwise 1/4 turn to lock out position. 3. Remove vinyl cap from attachment drive shaft. 4. Remove cardboard spacer, if necessary. 5.

  • Page 9: Nylon Line Head Installation/Removal

    ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOUR- SELF or have the ECHO Dealer do it, each maintenance task has been graded. If the task is not listed see your ECHO...

  • Page 10: Skill Levels

    2. Pull flexible cable from the drive shaft housing, wipe clean and re-coat with a thin coating [15 ml (1/2 oz.)] of LUBRICANTE ® ECHO 3. Slide the flexible cable back in the drive housing. DO NOT get dirt on the flex cable.

  • Page 11: Nylon Line Replacement

    PAS R APid oAdeR RiMMeR TTAchMenT PeRAToR AnuAL nylon lIne replaCemenT MODELS REQUIRED LINE SIZES SRM-2100SB SRM-210SB/211SB/225SB .080 - .105 in. Level 1. PAS-210/211/2100 PAS-225/225VP/225VBP PAS-230/231 Parts Required: Pre-cut Nylon Line SRM-2400SB .095 - .105 in. PAS -2400 1. Insert pre-cut 204 mm (8 in.) length of nylon cut- SRM-260SB/261SB ting line (recommended sizes 2.4 mm [.095 in.] PAS-2601...

  • Page 12: Warranty Statement

    The owner shall demonstrate reasonable care and use, and follow preventative maintenance, storage, fuel and oil usage as prescribed in the operator’s manual. Should a product difficulty occur, you must, at your expense, deliver or ship your ECHO unit to an authorized ECHO servicing dealer for warranty repairs (within the applicable warranty period), and arrange for pick-up or return of your unit after the repairs have been made.
  • Page 13 89 octane or higher. Gasohol which contains a maximum 10% ethanol (grain alcohol) or 15% MTBE (methyl/tertiary/butyl/ether) is also approved. The prescribed mixing ratio of gasoline to oil is listed on the ECHO oil label and covered in your operator’s manual.
  • Page 14 noTes...
  • Page 15 PAS R APid oAdeR RiMMeR TTAchMenT PeRAToR AnuAL noTes...

  • Page 16: Servicing Information

    ECHO Inc., 400 Oakwood Road, Lake Zurich, IL 60047 (800-673-1558). Always check the ECHO Web Site for updated information. Safety Videos are available from your Echo dealer. A $5.00 shipping charge will be required for each video. ECHO, INCORPORATED...
