LED
ACT (Activity)
USB
CSM
WLAN
WAN1/2
DoS
VPN
QoS
LED on Connector
WAN 1/2
(Giga)
GigaLAN
1/2/3/4
Vigor2920 Series Quick Start Guide
r 2 9 2 0 n
r 2 9 2 0 n
Status
Blinking
Off
On
Blinking
On
On
Blinking
On
Blinking
On
Blinking
On
On
Left LED On
(Green)
Off
Blinking
Right LED On
(Green)
Off
Left LED On
(Green)
Off
Blinking
Right LED On
(Green)
Off
Explanation
The router is powered on and running normally.
The router is powered off.
USB device is connected and ready for use.
The data is transmitting.
The profile(s) of CSM (Content Security
Management) for IM/P2P, URL/Web Content Filter
application can be enabled from Firewall
>>General Setup. (Such profile must be
established under CSM menu).
Wireless access point is ready.
It will blink slowly while wireless traffic goes
through.
If ACT and WLAN LEDs blink quickly and
simultaneously when WPS is working, and it will
return to normal condition after two minutes. (You
need to setup WPS within 2 minutes.)
The WAN1 or WAN2 connection is ready.
It will blink while transmitting data.
The DoS/DDoS function is active.
It will blink while deleting an attack.
The VPN tunnel is active.
The QoS function is active.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 1000Mbps.
The port is disconnected with 10/100Mbps.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 1000Mbps.
The port is disconnected with 10/100Mbps.
