Operation

Figure 2
C
A - Two Position On/Off Switch
(Figure 2)
The power switch controls the
electricity supply to the heater,
flame effect and pilot light. When
the switch is in the
the unit is ON and when the
switch is in the " O " position the
unit is OFF.
!
NOTE: When the pilot light is
lit but flames are not present,
power is still supplied to unit
and flame effect light bulb
should be replaced.
B - Low Heat On/Off Switch
The Low Heat On/Off Switch
supplies power to the heater fan
and the heater element. When the
switch is in the ON position the
heater operates on LOW.
C - High Heat Switch
The High Heat On/Off Switch
supplies power to the heater fan
and the heater element, when the
switch is in the ON position the
8
B
A
" I " position
heater operates on HIGH. The
B - Low Heat On/Off Switch must
also be in the ON position for the
high heat setting to operate.
CAUTION:
continuously cuts out, unplug the
unit and call customer service at
1-800-346-7539.
If the unit
