Dimplex DF2608 Service Manual

26” self trimming fireplace

Hide thumbs Also See for DF2608:

Owner's manual (63 pages)

Practical user's manual (20 pages)

Service manual (17 pages)

Table Of Contents

Table of Contents

Quick Links

Summary of Contents for Dimplex DF2608

Page 1 1367 Industrial Road Cambridge ON Canada N1R 7G8 11879 Feb 12, 10 1-888-346-7539 www.dimplex.com In keeping with our policy of continuous product development, we reserve the right to make changes without notice. Jan 3.12 © 2011 Dimplex North America Limited 7400200000R03...
Page 2: Table Of Contents
Log Driver Controller Replacement (DF2608 only) ........
Page 3: Operation
Operation when first used. This odor is a normal condition caused by initial heating of internal heater parts and will not This section will explain the function of each convenient occur again. control (Figure 2). To access the controls, flip open the control panel cover Resetting The Temperature Cutoff Switch towards the bottom of the fireplace (Figure 1).
Page 4: Maintenance
Care must be taken when removing the Log set assembly as it contains LED’s Lay unit on it’s back and slide Front Glass back into and wires (DF2608 only). position and attach trim. Slide fireplace out of mantel.
Page 5: Exploded Parts Diagram - Df2608/Nbdf2608
Exploded Parts Diagram - DF2608/NBDF2608 Replacement Parts List Part Number 6904400359 Replacement Part: Log Set ......0439560100RP Single Light Holder .
Page 6: Wiring Diagram - Df2608 / Nbdf2608
Wiring Diagram - DF2608 / NBDF2608 Power Cord Remote Control Receiver Heater Switch 3-Position Switch Light Dimmer Control Log Set Driver Thermostat Heater Flame Speed Assembly Control...
Page 7: Exploded Parts Diagram - Df2622
Exploded Parts Diagram - DF2622 Replacement Parts List Part Number 6904400659 Replacement Part: Log Set ..... . . 0439560200RP Front Glass .
Page 8: Wiring Diagram - Df2622
Wiring Diagram - DF2622 Remote Control Receiver 3-Position Power Cord Switch Light Dimmer Control Heater Switch Heater Assembly Thermostat...
Page 9: Front Glass Replacement
Front glass Replacement Reflective Glass. ! IMPORTANT: Only handle the Log Set Assembly by CAUTION: If unit was operating prior to servicing allow the Ember Bed or plastic grate. at least 10 minutes for lights, heating elements and top ! NOTE: Log Set Assembly fits tightly into firebox, some panel to cool off to avoid accidental burning of skin.
Page 10: Heater Switch Replacement
Log Driver (DF2608). Wire 3: Grey wire Wire 2: Yellow wire from top terminal Wire 3 Wire 2 Wire 1...
Page 11: Flame Speed Control Replacement
cover to the rest of the firebox. There are: two (2) nut removed in step 5. screws on each side; two (2) screws on the back panel Disconnect one of the two (2) wire leads from the (you may have to tip the bottom of the firebox up if it is original control board (which are still connected to laying on its back), four (4) screws in the front directly parts within the firebox) and immediately connect it to...
Page 12: Flicker Motor/Flicker Rod Replacement
maintenance to reduce the risk of electric shock or damage Figure 12 to persons. Remove the firebox from the mantel. Lay unit on its back. Remove the 12 Philips screws that fasten the bottom cover to the rest of the firebox. There are: two (2) screws on each side;...
Page 13: Thermostat Control Replacement
wires (five (5) in total) as close to the Flicker Motor as at least 10 minutes for lights, heating elements and top possible. panel to cool off to avoid accidental burning of skin. Remove the rubber bushing from the motor shaft by WARNINg: Disconnect power before attempting any applying needle nose pliers to the motor shaft and twist maintenance to reduce the risk of electric shock or damage...
Page 14: Remote Control Replacement
Mounting Studs (4) panel) and the sheet metal of the bottom panel. Log Driver Controller Replacement Remote (DF2608 only) Control Receiver CAUTION: If unit was operating prior to servicing allow at least 10 minutes for lights, heating elements and top panel to cool off to avoid accidental burning of skin.
Page 15: Lower Light Harness Replacement
Reflective Glass Replacement procedure on page 9 to do Remove the firebox from the mantel. this. It is recommended to attempt to release the control Lay unit on its back. board without cutting mounting studs. Remove the 12 Philips screws that fasten the bottom Properly orient the replacement Log Driver board and cover to the rest of the firebox.
Page 16: Power Cord Replacement
Figure 18 Figure 21 Screws to Remove Flame Speed Control 3-Position Switch Power Cord Figure 19 Heater Heating Wire 2 Assembly Element Terminal Block Wire 1 Wire Clamp WARNINg: Disconnect power before attempting any Wire 4 Wires leading to maintenance to reduce the risk of electric shock or damage Wire 5 bottom assembly Wire 3...
Page 17: Troubleshooting Guide
Check wiring connections Defective Light Harness Replace Light Harness Log set dim, not glowing Loose wiring Check wiring connections (DF2608 Only) Defective Log Driver Controller Replace Log Driver Controller Defective Log Set Replace Log Set Flame Shutter Defective Flicker Motor...
Page 18 PROBLEM CAUSE SOLUTION Heater Heater is not turning off Improper operation Refer to Operation Section Defective Heater Switch Replace Heater Switch Defective Thermostat Replace Thermostat Heater is not turning on Improper operation Refer to Operation Section Loose wiring Trace wiring in unit Defective Heater Switch Replace Heater Switch Defective Thermostat...
