VOLVO

WIRING DIAGRAM

S60/S60R
TP 3997202
2007

Advertisement

Table of Contents
loading

Related Manuals for Volvo S60

Summary of Contents for Volvo S60

  • Page 1: Wiring Diagram

    VOLVO WIRING DIAGRAM S60/S60R TP 3997202 2007...

  • Page 2: Vehicles With Srs (Airbag)/Sips Bag/Ic (Inflatable Curtain)

    2. Damage or malfunction of the SRS/SIPS bag/IC system. Work involving the SRS/SIPS bag/IC systems or other components in the vehicle that may affect the SRS/SIPS bag/IC systems must always be performed by an authorized Volvo workshop. In case of doubt, consult the SRS and SIPS bag/IC service manual.

  • Page 3: Table Of Contents

    Tow hitch cable harness, 4-pin ........83 Engine management system, 5-cyl. Turbo 1:2 .... 44 Tow hitch cable harness, 7-pin ........84 Engine management system, Bi-Fuel 1:2....46 Tow hitch cable harness, 13-pin ........85 Engine management system, 5-cyl. Diesel 1:3.... 48 TP 3997202 S60/S60R 2007...
  • Page 4 Roof harness ..............167 Trunk lid/tailgate harness..........168 Central locking ............111 Door harness ..............169 Power windows............112 Bi-Fuel harness............170 Power sunroof............113 Component illustrations ......171 Index 1:2 ........... 217 List of components 1:6 ......219 TP 3997202 S60/S60R 2007...

  • Page 5: Explanations

    = Light Green = Israel = Orange = Japan = Pink = Korea = Red = Norway = Black = Netherlands = Violet = Sweden = White = United States of America = Yellow = Western Europe TP 3997202 S60/S60R 2007...

  • Page 6: How To Use The Wiring Diagrams 1:2

    The end of the manual contains a section in which Service/diagnostics component appearance and location is described in Contact reel numeric order. On the EWD disc, components are Meter linked to the relevant diagram. Ignition component/shunt Converter Optics Ground connection Branching point Connector TP 3997202 S60/S60R 2007...

  • Page 7: How To Use Wiring Diagrams 2:2

    31/98 31/83 = LIN communication = DIN cable, coaxial cable, etc. = Data communication 10/1-2 = CAN communication = Connection with distribution = Further connection to... = Connector between cable harnesses = Connector connected in component TP 3997202 S60/S60R 2007...

  • Page 8: Overview

    4/46B:42 R-SB GN-Y GN-Y 6/104:2 GN-Y 2/90 2/91 2/182 FST1 FST2 FST3 1(86) 3(30) 1(86) 3(30) 1(86) 3(30) 11L/1 2(85) 5(87) 4(87a) 2(85) 5(87) 4(87a) 2(85) 5(87) 4(87a) 4/56C:3 GN-SB 4/56C:25 GR-SB 6/1:2 53/331 4/56C:4 6/1:1 TP 3997202 S60/S60R 2007...
  • Page 9 4/56 C:14 C:13 B:24 BL-R 16/65:1 C:13 BL-R 3/157:2 D:16 B:16 BL-R BL-R 53/443 BL-R C:14 4/9B:28/56 D:15 F3, 5-10, D:60 17-23, 31-32 ,34 F1-38 F1-2, 11, 13-16, 54/40D 26-30, 33 Bi-Fuel A:13 D:35 D:50 31/53 TP 3997202 S60/S60R 2007...

  • Page 10: Fuses

    Fuses Engine compartment 11A/1-5 11A Fuses in the engine compartment Fuse function 4/109 Glow plug control module 20/22-26 Glow plug 4/109 6/29 Motor, cooling fan 4/71 TP 3997202 S60/S60R 2007...

  • Page 11: Engine Compartment 11B/1-12

    Cooling fan, electrics box, engine compartment 7/51 Accelerator pedal sensor Electromagnetic clutch, climate control system 2/22 7/17 Mass airflow sensor (MAF), Diesel 4/46 Engine Control Module (ECM), Gasoline 7/17 Mass airflow sensor (MAF), Gasoline 8/6-11 Injectors, Gasoline continues TP 3997202 S60/S60R 2007...

  • Page 12: Engine Compartment 11B/13-15

    Solenoid, variable valve timing exhaust 9/32 PTC resistor, crankcase ventilation 4/109 Glow plug control unit (GCU), Diesel 6/143 Turbo control motor, Diesel 8/64 Solenoid valve, engine mounting, Diesel 8/113 Bypass valve, EGR cooling, Diesel 8/120 EGR valve, Diesel continues TP 3997202 S60/S60R 2007...

  • Page 13: Engine Compartment 11B/16-20

    Main relay, engine management system 4/46 Engine Control Module (ECM) 10/11 Front left running/parking light 4/56 10/12 Front right running/parking light 4/56 10/71 Side running light, front left 4/56 10/73 Side running light, front right 4/56 TP 3997202 S60/S60R 2007...

  • Page 14: Passenger Compartment 11C/1-6

    Upper Electronic Module (UEM) 4/76 Remote control unit for garage door opener 4/70 7/149 Rain Sensor Module (RSM) 4/70 10/114 Left-hand vanity mirror lighting 4/70 10/115 Right-hand vanity mirror lighting 4/70 10/150 Rear reading light 4/70 continues TP 3997202 S60/S60R 2007...

  • Page 15: Passenger Compartment 11C/7-13

    3/254 Steering Wheel Module (SWM) 4/68 Steering Wheel Angle Sensor Module (SAS) 3/254 17/13 Data link connector 16/1 Audio Module (AUM) 16/93 Control module, mobile phone handsfree 16/2 Amplifier 16/46 RTI display 16/60 Phone Module (PHM) TP 3997202 S60/S60R 2007...

  • Page 16: Battery 11E-11L

    Central Electronic Module (CEM) Main fuse for: F3, F5-F10, F17-F23, F31-F32, F34 11C/1-5 Fuses in passenger compartment fuse box 11C/6-13 Fuses in passenger compartment fuse box 11L Fuse, Diesel Fuse function 11B/10-15 Fuses in engine compartment fuse box 2/32 TP 3997202 S60/S60R 2007...

  • Page 17: Central Electronic Module (Cem) F1-F15

    Damper Motor Module (DMM), floor/ventilation 7/93 Occupant Weight Sensor (OWS) 7/159 Air Quality Sensor (AQS) Front 12V outlet 9/25 Rear 12V outlet Right-hand headlight wiper motor Left-hand headlight wiper motor 4/16 Brake Control Module (BCM) continues TP 3997202 S60/S60R 2007...

  • Page 18: Central Electronic Module (Cem) F16-F34

    Audio Module (AUM) 16/46 RTI display 16/93 Control module, mobile phone handsfree 27/3 Left Camera Module (LCM) 27/4 Right Camera Module (RCM) 6/114 Vacuum pump 8/84 Right-hand headlight wiper motor Left-hand headlight wiper motor 6/127 Washer motor TP 3997202 S60/S60R 2007...

  • Page 19: Rear Electronic Module (Rem) F1-F13

    3/86 Rear right door power window switch 6/93 Motor, rear right power window 3/86 3/85 Rear left door power window switch 6/92 Motor, rear left power window 3/85 8/85 Thermostatic switch and fuel filter heating continues TP 3997202 S60/S60R 2007...

  • Page 20: Rear Electronic Module (Rem) F17-F38

    Converter, direction indicators & brake lights, USA - running lights - direction indicator, left 4/110 Trailer Module (TRM) - brake lights - fog lights - right-hand direction indicator Main fuse for: F37-F38 Heated rear window 16/16 Heated rear window 16/16 TP 3997202 S60/S60R 2007...

  • Page 21: Relays

    A = Corresponds to the position on the back of the relay box (wiring side) B = Corresponds to the position on the relay. C = An old designation that may be found on 1(86) 3(30) the relay. 2(85) 5(87) 4(87a) TP 3997202 S60/S60R 2007...

  • Page 22: Engine Compartment Fma1-Fst3

    2/35 Starter motor FMA3 2/32 Main relay, engine management system FMI2 2/22 Relay, climate control system FST1 2/90 Relay, windshield wiper, low/high speed FST2 2/91 Relay, intermittent wiping FST3 2/182 Relay, high pressure headlight washer motor TP 3997202 S60/S60R 2007...

  • Page 23: Other Relays

    Other relays Accessory relays Relay function Engine 2/64 Relay, auxiliary lights compart- ment Cargo 2/191 Relay, remote parking heater start, radio signal compart- ment Front 2/192 Relay, electric engine heater member Dashboard 2/238 Relay, audio disconnection TP 3997202 S60/S60R 2007...

  • Page 24: Ground Connections Overview

    Ground connections Overview TP 3997202 S60/S60R 2007...
  • Page 25 31/10 A-post, right-hand side 4/31 Fan control module, LHD 4/56 Central Electronic Module (CEM), RHD 4/84 Suspension Module (SUM) Front 12V outlet 9/25 Rear 12V outlet 31/44 Left-hand side member, lower engine compartment 31/4 Ground connection TP 3997202 S60/S60R 2007...
  • Page 26 Occupant Weight Sensor (OWS) 8/52 Front right side airbag igniter 9/13 Seat Heating Module (SHM), right 9/34 Right-hand heated door mirror 10/16 Direction indicator, right door mirror 10/149 Right-hand rearview mirror lighting 27/4 Right Camera Module (RCM) TP 3997202 S60/S60R 2007...
  • Page 27 8/89 Front left solenoid, fuel tank, Bi-Fuel 8/90 Front right solenoid, fuel tank, Bi-Fuel 10/17 Lamp housing, rear right 10/128 Lighting, cargo compartment, right-hand side 10/218 Remote start indicator light, accessory 17/19 12V outlet, cargo compartment TP 3997202 S60/S60R 2007...
  • Page 28 16/46 RTI display 16/60 Phone Module (PHM) 16/93 Control module, mobile phone handsfree, accessory 17/13 Data link connector 31/88 Engine, ignition coils, group 1 20/3 Spark plug and ignition coil 20/4 Spark plug and ignition coil TP 3997202 S60/S60R 2007...
  • Page 29 Auxiliary heater 10/1 Left-hand front lamp housing 10/5 Front left fog light 10/11 Front left running/parking light 10/13 Front left direction indicator 10/71 Side running light, front left 16/10 Horn 1 16/11 Horn 2 20/16 Capacitor TP 3997202 S60/S60R 2007...
  • Page 30 7/122 Mass Movement Sensor Module (MMS), front 7/149 Rain Sensor Module (RSM) 10/19 Auxiliary brake light 10/115 Right-hand vanity mirror lighting 10/150 Rear reading light 31/83 Ground connection 31/102 Front member 2/192 Relay, electric engine heater TP 3997202 S60/S60R 2007...
  • Page 31 Traffic Message Channel module (TMC) 16/145 Satellite radio receiver 17/37 4-pin outlet, tow hitch cable harness 17/38 7-pin outlet, tow hitch cable harness 17/39 13-pin outlet, tow hitch cable harness 26/4 Converter, direction indicators & brake lights, USA TP 3997202 S60/S60R 2007...

  • Page 32: Control Modules Overview Of Locations

    Control modules Overview of locations PDM/ 4/31 4/71 DDM/ 17/13 TP 3997202 S60/S60R 2007...

  • Page 33: Overview Of Designations

    Suspension Module (SUM) 3/254 Steering Wheel Module (SWM) 4/28 Transmission Control Module (TCM) 4/110 Trailer Module (TRM) 4/70 Upper Electronic Module (UEM) 4/31 4/31 Fan control module 4/71 4/71 Cooling fan control module 17/13 17/13 Data link connector TP 3997202 S60/S60R 2007...

  • Page 34: Central Electronic Module (Cem) 1:2

    MAN (M66) D:23 BL-W 8/134:3 BL-W 3/156A:3 54/10 BLIS BL-R BL-R 6/62:4 54/11 BLIS BL-R BL-R 6/63:4 W/O DIESEL C:14 BL-R 4/46B:37 DIESEL BL-R 4/46B:41 Bi-Fuel 4/58A:13 4/118A:1 A:12 A:29 54/10 GN-W 6/62:12 54/11 GN-W 6/63:12 TP 3997202 S60/S60R 2007...
  • Page 35 10/2A:3/A:2, 10/12:1, 10/73:1 6/3:2 B:19 6/4:2 54/24 A:19 9/12:4 54/25 A:18 9/13:4 A:16 54/36:5 D:43 54/36:3 D:44 54/36:1 D:45 54/36:2 D:29 7/12:4 D:30 7/12:1 D:42 7/12:5 B:25 16/35:1 16/1A:2 A:22 54/25 GN-R 3/27:3 54/24 GN-R 3/27:3 31/6 31/10 TP 3997202 S60/S60R 2007...

  • Page 36: Rear Electronic Module (Rem) 1:2

    B:31 17/19:2 54/20 GN-BN GN-BN 3/85:5 A:19 3/85:1 3/85:3 54/21 54/43 GN-BN GN-BN GN-BN 3/86:5 B:30 3/86:1 3/86:3 54/20 3/76:2 3/76:5 A:27 3/76:8 A:24 3/76:6 A:23 3/76:4 D:26 GN-W D:31 7/100 A:32 D:12 53/602 31/47 31/72 TP 3997202 S60/S60R 2007...
  • Page 37 GN-R 4/110A:11 GN-Y 4/110A:9 4/110B:1 13 POLE 17/39:9 4/110B:5 GN-W 4/110B:3 4/110B:4 13 POLE / 7POLE 10A:7 USA 4-POLE 4/110A:7, 4/110A:8 13 POLE 17/39:8 7 POLE Y-SB 4/110A:2, 17/38:2 7 POLE 53/735 BL-Y 13 POLE 17/39:10 TP 3997202 S60/S60R 2007...

  • Page 38: High Speed Can Data Communication

    4/82 HCM AWD/ FOUR-C 53/584 AWD W/O FOUR-C W/O HCM AWD W/O FOUR-C W/O HCM 54/74 7/164 4/16 2WD HCM D:47 D:32 2WD HCM 54/3.1 DSTC DSTC 2WD W/O HCM DSTC DSTC 2WD W/O HCM 54/3.1 TP 3997202 S60/S60R 2007...

  • Page 39: Low Speed Can Data Communication

    D:54 4/70 16/60 54/13 53/433 D:38 D:53 53/434 3/127 PDM/DDM 54/11 D:34 D:49 LS CAN High D:40 4/52 D:55 54/24 LHD 54/25 RHD D:36 D:51 4/58 D:35 C:14 D:50 C:13 4/78 D:30 D:19 16/45 D:20 D:21 TP 3997202 S60/S60R 2007...

  • Page 40: Lin Data Communication 1:2

    54/13 16/35 4/70 7/149 54/16 27/4 54/11 GN-W GN-W 3/111 27/3 54/10 GN-W GN-W 4/56 C:16 D:24 54/9 D:41 GN-W C:32 GN-W D:58 GN-W SWSL 3/254 18/4 4/46 54/1B GN-W GN-W A:88 GN-W 3/131 SWSR DIESEL TP 3997202 S60/S60R 2007...
  • Page 41 53/460 9/13 6/48 LHD 6/96 54/25 6/102 9/12 7/159 LHD 54/24 7/100 4/58 D:26 GN-W D:32 GN-W 4/86 A:12 4/118 10/2 10/1 54/3.1 54/3.1 54/23 54/22 GN-W GN-W GN-W GN-W LHCU RHCU LIN ABL LIN ABL TP 3997202 S60/S60R 2007...

  • Page 42: Group 23 Fuel System Engine Management System, 5-Cyl. 1:2

    53/309 A:30 GN-W 31/88 53/328 53/360 20/5 A:28 9/32 A:29 GN-GR GN-W 20/6 A:51 GN-W 20/7 A:50 6/120 A:35 BL-R 31/89 GN-Y A:36 A:43 A:25 GN-SB A:34 53/314 A:52 A:53 53/326 A:54 A:62 A:17 31/96 BL-R TP 3997202 S60/S60R 2007...
  • Page 43 LHD 2 / RHD 5 B:17 BN-SB LHD 1 / RHD 6 GR-W LHD 5 / RHD 2 B:25 BL-W 6/44 LHD 6 / RHD 1 BL-R LHD 4 / RHD 3 53/329 53/397 BL-R 53/305 31/93 BL-R 31/48 TP 3997202 S60/S60R 2007...

  • Page 44: Engine Management System, 5-Cyl. Turbo 1:2

    GN-W 20/4 Y-SB A:67 A:30 A:48 7/25 GN-W 31/88 A:66 20/5 53/328 A:50 4/71:4 GN-W 20/6 A:52 GN-W 20/7 A:51 6/120 BL-R A:36 31/89 GN-Y A:19 A:59 A:35 A:20 GN-SB A:53 53/326 A:54 A:63 31/96 BL-R TP 3997202 S60/S60R 2007...
  • Page 45 LHD 2 / RHD 5 B:17 BN-SB LHD 1 / RHD 6 GR-W LHD 5 / RHD 2 B:25 BL-W 6/44 LHD 6 / RHD 1 BL-R LHD 4 / RHD 3 53/329 53/397 BL-R 53/305 31/93 BL-R 31/48 TP 3997202 S60/S60R 2007...

  • Page 46: Engine Management System, Bi-Fuel 1:2

    20/4 A:30 GN-W 53/360 31/88 53/328 20/5 A:28 A:29 GN-W 20/6 A:51 GN-W 20/7 9/32 A:50 31/89 4/50 4/71:4 A:56 BL-R GN-Y A:38 A:37 HISPEED A:55 A:36 A:53 53/326 A:54 A:62 31/91 31/96 BL-R GN-GR GN-GR TP 3997202 S60/S60R 2007...
  • Page 47 8/90 8/88 B:44 GN-W 2/22:4 54/54 54/3.1 B:46 5/1:2 B:48 54/7 B:32 P-SB P-SB B:50 53/604 7/51 GR-R BN-SB B:17 6/105 GR-W B:25 BL-W BL-R 6/44 53/329 BL-R 53/305 53/397 31/93 BL-R GN-GR 31/73 GN-GR 31/48 TP 3997202 S60/S60R 2007...

  • Page 48: Engine Management System, 5-Cyl. Diesel 1:3

    GN-GR 10 9 7 6 BN-SB 4/109 A:21 GN-W A:88 6/26B:1 4 3 2 1 GN-SB A:64 7/162 GN-Y A:65 GN-W A:19 Y-SB A:87 7/165 A:85 A:82 A:15 20/22 20/23 BL-R 20/24 GN-SB 20/25 GN-W 20/26 TP 3997202 S60/S60R 2007...
  • Page 49 GN-OR 2/35:2 B:44 BL-OR 2/35:4 7/123 B:12 B:40 B:32 GN-W 2/22:4 B:35 B:23 B:22 7/73 7/51 BN-SB 6/33 B:24 GR-W B:15 GR-R B:47 BL-W BL-R GN-SB GN-SB 53/329 53/394 BL-R 53/397 53/305 GN-SB 31/93 31/48 31/73 TP 3997202 S60/S60R 2007...
  • Page 50 BL-SB BL-Y A:33 8/98 GR-R A:23 A:93 7/166 BN-GR A:34 BN-SB A:36 VO-W A:42 6/118 GR-R A:81 VO-W BN-P A:40 BN-SB A:52 6/120 A:24 GN-SB A:72 A:67 BN-SB GN-R A:18 VO-W A:11 8/111 A:47 GR-R A:94 TP 3997202 S60/S60R 2007...

  • Page 51: Emission Control, 5-Cyl

    GN-GR BL-GN 54/34 5 CYL W/O T B:40 7/15 53/304 Bi-Fuel A:69 GN-BN GN-BN A:18 BL-R BL-SB A:42 GN-R A:41 7/82 GN-BN A:11 A:24 53/319 BN-SB A:61 BN-SB Bi-Fuel A:57 7/172 Bi-Fuel A:65 Bi-Fuel A:47 B:13 TP 3997202 S60/S60R 2007...

  • Page 52: Emission Control, 5-Cyl. Turbo

    A:13 54/34 8/18 5 CYL T GN-GR B:40 BL-SB BL-SB 7/15 A:18 GN-BN A:42 A:41 GN-SB A:28 BL-SB GN-R A:24 B:13 7/82 GN-R GN-BN A:61 A:62 7/172 53/375 53/304 A:29 A:65 53/376 A:47 7/173 A:27 BL-SB TP 3997202 S60/S60R 2007...

  • Page 53: Group 26 Cooling System Cooling Fan

    53/332 A:39 VO-W VO-W B:13 4/71 4/46 54/1B Bi-Fuel / 5 CYL W/O T 5 Cyl W/O T Bi-Fuel 7/16 A:40 GR-R 53/319 A:61 BN-SB BN-SB 6/29 BN-SB A:21 BN-GR A:58 VO-W VO-W 53/332 B:13 31/2 TP 3997202 S60/S60R 2007...

  • Page 54: Cooling Fan, Diesel

    Group 26 Cooling system Cooling fan, Diesel 11A/2 4/46 DIESEL 7/16 A:60 GR-R A:56 BN-SB A:76 BN-SB A:79 BN-GR A:43 VO-W 4/71 B:58 B:23 B:22 6/29 31/96 TP 3997202 S60/S60R 2007...

  • Page 55: Group 27 Engine Control Cruise Control

    5CYL W/O T A:36 GN-Y 5CYL W/O T A:43 5CYL W/O T A:25 5CYL W/O T 5CYL W/O T GN-SB BL-R 53/305 BL-R A:56 GN-Y A:38 A:37 53/329 A:55 4/50 53/397 Bi-Fuel GN-SB Bi-Fuel 31/91 31/93 31/84 TP 3997202 S60/S60R 2007...

  • Page 56: Cruise Control, Diesel

    D:31 D:46 11B/11 4/46 53/438 B:23 B:42 7/123 B:22 B:12 B:40 DIESEL 7/51 B:24 GR-W 6/120 BN-SB B:15 GR-R A:24 B:47 BL-W A:72 GN-SB BN-SB A:67 GN-R A:18 VO-W A:11 BL-R 53/305 53/329 53/397 31/93 31/84 TP 3997202 S60/S60R 2007...

  • Page 57: Group 32 Generator And Voltage Regulator Power Supply

    Group 32 Generator and voltage regulator Power supply 4/58 C:14 C:13 4/56 D:50 D:35 D:49 D:34 54/1B C:16 GN-W C:21 C:22 4/46 B:23 DIESEL A:88 GN-W B:22 DIESEL 31/53 17/17 TP 3997202 S60/S60R 2007...

  • Page 58: Group 33 Starting System Starting System

    GR-R A:53 DIESEL B:23 B:33 DIESEL 7/123 B:12 B:29 PETROL B:15 PETROL PETROL B:44 53/324 DIESEL B:23 B:40 DIESEL B:22 4/28 54/57.1 AUTO B:34 53/331 AUTO TF-80SC B:13 DIESEL A:14 S60R AUTO 53/397 53/329 31/53 31/93 TP 3997202 S60/S60R 2007...

  • Page 59: High And Low Beam (Bi-Xenon) & Daytime Running Lights

    GN-W D:58 D:41 GN-W BL-R B:27 B:28 3/254 3/111 B:23 53/398 54/22 54/23 53/438 BL-GN BL-GN BL-Y BL-Y Bi-X Bi-X Bi-X Bi-X 10/1 10/2 MAIN MAIN BIFUNC BIFUNC 54/22 54/23 53/301 53/303 53/397 31/93 31/94 31/84 TP 3997202 S60/S60R 2007...

  • Page 60: Active Headlights (Abl)

    53/425 D:32 11B/17 11B/16 GN-W D:58 D:41 GN-W 3/254 BL-R D:46 D:29 D:31 3/111 D:42 7/12 18/4 4/68 7/91 4/118 GN-W GN-W 54/3.1 54/3.1 54/22 54/23 10/2 10/1 LHCU RHCU LIN ABL LIN ABL 53/438 31/84 TP 3997202 S60/S60R 2007...

  • Page 61: Fog Lights

    53/438 D:49 D:41 GN-W B:18 B:17 D:35 A:15 D:50 10/5 4/58 C:13 C:13 C:14 A:18 GN-Y 53/303 10/18 10/17 53/301 10/46 10/53 A:3 A:2 A:1 A:1 A:2 A:3 53/397 53/604 53/601 31/73 31/72 31/84 31/93 31/94 TP 3997202 S60/S60R 2007...

  • Page 62: Brake Lights

    Group 35 Lighting Brake lights 11E/1 11E/5 4/56 54/40D D:49 B:11 D:34 C:34 D:35 54/13 A:15 D:50 10/19 4/58 C:13 53/503 A:18 C:14 54/13 10/17 10/18 10/50 53/601 53/604 10/43 31/72 31/73 31/98 31/83 TP 3997202 S60/S60R 2007...

  • Page 63: Reversing Lights

    Group 35 Lighting Reversing lights 4/28 11E/1 B:13 B:14 4/56 4/58 A:15 A:18 GN-Y C:22 C:21 C:28 Y-GR D:35 C:14 D:50 C:13 3/10 B:23 53/329 10/18 10/17 53/397 53/601 53/604 10/55 10/48 31/93 31/72 31/73 TP 3997202 S60/S60R 2007...

  • Page 64: Running/Parking Lights, Tail Lights & License Plate Lighting

    MAIN 4/58 BIFUNC BIFUNC C:14 C:13 F:10 GR-GN 10/71 10/73 10/3 GR-W 54/22 54/23 54/22 3/35 53/301 53/303 GR-W 10/17 10/18 BL-BN 53/604 53/397 10/51 10/44 53/438 10/45 10/52 10/49 10/42 31/84 31/93 31/72 31/73 31/94 TP 3997202 S60/S60R 2007...

  • Page 65: Follow-Me-Home Lighting

    Group 35 Lighting Follow-me-home lighting 11C/5 11C/4 4/70 16/59 54/10 54/11 3/126 3/127 B:12 B:12 DDM/PDM PDM/DDM VO-SB 53/514 53/515 6/62 6/63 10/148 10/149 54/10 54/11 53/501 31/66 31/67 TP 3997202 S60/S60R 2007...

  • Page 66: Interior Lighting

    54/20 GN-Y 10/114 BL-R 10/128 54/10 54/21 54/11 A:10 B:12 3/126 DDM/PDM 53/514 53/501 VO-W 54/10 53/583 53/505 3/74 3/76 54/13 54/13 53/503 53/601 53/604 53/405 54/20 53/500 31/6 31/67 31/98 31/83 31/72 31/73 31/66 31/46 TP 3997202 S60/S60R 2007...

  • Page 67: Beam Length Adjustment

    54/23 6/38 6/39 GN-R GN-R Bi-Xenon 4/58 54/32 7/120 W/O SUM C:11 GN-R BL-R W/O SUM GR-W W/O SUM BN-W 53/301 C:13 53/303 53/438 C:14 4/84 54/107 A:25 A:28 A:23 53/397 A:15 A:16 31/93 31/94 31/84 TP 3997202 S60/S60R 2007...

  • Page 68: Auxiliary Lights

    Group 35 Lighting, Accessories Auxiliary lights 3/112 3/60 11B/5 C°/F° 4/56 D:50 D:35 A:11 BN-W 54/8 BN-W 2/64 10/69 10/65 31/70 TP 3997202 S60/S60R 2007...

  • Page 69: Group 36 Additional Electrical Equipment Rain Sensor

    Group 36 Additional electrical equipment Rain sensor 11C/7 11C/6 3/254 54/13 4/70 7/149 54/16 53/505 VO-W VO-W VO-W W-BL 4/56 54/13 D:11 C:31 D:58 53/503 D:53 D:38 D:34 D:49 53/331 53/397 31/93 31/83 31/98 TP 3997202 S60/S60R 2007...

  • Page 70: Direction Indicator And Hazard Warning Flashers

    D:14 10/15 6/63 10/16 54/22 54/10 54/11 54/23 10/14 10/13 10/11 10/12 4/58 A:18 A:13 A:20 A:21 54/22 B:11 B:10 GN-W C:14 C:13 10/17 10/18 10/54 10/47 53/601 53/604 31/94 31/67 31/66 31/93 31/72 31/73 31/6 TP 3997202 S60/S60R 2007...

  • Page 71: Wiper/Washer, Windshield

    D:50 D:35 GN-W D:58 D:34 54/40D D:49 C:10 GN-Y B:29 C:31 BL-W B:21 B:30 2/91 FST2 1(86) 3(30) 2(85) 5(87) 4(87a) 6/127 GN-Y 2/90 1(86) 3(30) FST1 2(85) 5(87) 4(87a) GR-SB 53/331 53/302 53/397 31/93 31/1 TP 3997202 S60/S60R 2007...

  • Page 72: Wiper/Washer, Headlights

    Group 36 Additional electrical equipment Wiper/washer, headlights 3/254 4/56 11E/5 11E/4 11E/1 D:50 D:35 D:58 GN-W D:34 54/40D D:49 C:10 GN-Y B:29 B:21 B:19 B:30 6/127 53/331 53/302 53/397 31/93 31/1 TP 3997202 S60/S60R 2007...

  • Page 73: High Pressure Headlight Washer

    Group 36 Additional electrical equipment High pressure headlight washer 11B/3 3/254 4/56 2/182 FST3 5(87) 4(87a) 1(86) D:58 D:50 GN-W D:35 3(30) 2(85) D:34 D:49 C:25 GN-SB C:10 GN-Y 6/104 53/302 31/1 TP 3997202 S60/S60R 2007...

  • Page 74: Horn

    Group 36 Additional electrical equipment Horn 11C/7 11C/9 11E/5 11E/4 53/425 3/254 3/37 18/4 54/40D 4/56 D:17 D:58 16/10 B:15 R-SB R-SB R-SB D:50 54/4 D:35 16/11 R-SB D:34 53/382 D:49 54/4 53/438 53/331 53/397 31/84 31/93 TP 3997202 S60/S60R 2007...

  • Page 75: Electronic Immobilizer

    Group 36 Additional electrical equipment Electronic immobilizer 11C/8 11C/7 4/46 B:13 B:23 DIESEL B:22 4/56 16/65 C:22 C:21 BL-R 53/443 D:34 D:57 D:49 D:56 53/400 31/83 TP 3997202 S60/S60R 2007...

  • Page 76: Anti-Theft Alarm

    3/78 54/21 16/59 GR-W 54/43 54/4 54/13 54/11 3/62 54/10 3/126 54/3.1 DDM/PDM 53/503 53/382 16/35 54/4 53/602 A:12 A:13 54/13 54/20 54/21 3/74 53/331 53/500 53/501 53/303 53/397 31/72 31/93 31/46 31/67 31/98 31/83 31/94 TP 3997202 S60/S60R 2007...

  • Page 77: Parking Assistance

    C:1/ C:6/ C:1/ C:6/ C:1/ C:6/ C:6/ C:7/ C:7/ C:10/ C:7/ C:10/ C:7/ C:10/ C:10/ C:8/ C:8/ C:11/ C:8/ C:11/ C:8/ C:11/ C:11/ C:12 C:12 C:12 C:12 7/131 7/132 7/133 7/134 LR/O LR/I RR/I RR/O 31/72 TP 3997202 S60/S60R 2007...

  • Page 78: Accessory Electronic Module (Aem) 1:2

    Group 36 Additional electrical equipment, Accessories Accessory Electronic Module (AEM) 1:2 11E/1 4/78 4/58 D:30 D:19 B:22 C:13 C:14 53/604 4/56 D:35 D:50 D:49 D:34 31/73 TP 3997202 S60/S60R 2007...
  • Page 79 B:15 Alarm signal Output signal B:16 Alarm signal Output signal B:30 Antenna amplifier, audio Feed Output signal B:33 Alarm signal Output signal RTI Japan Steering, X-feed B:34 Alarm signal Output signal Reverse gear signal, RTI Japan TP 3997202 S60/S60R 2007...

  • Page 80: Group 37 Wiring And Fuses Diagnostics System

    D:31 LOSPEED D:40 HISPEED D:46 LOSPEED D:55 HISPEED D:32 HISPEED D:47 LOSPEED D:34 LOSPEED D:49 LOSPEED D:35 LOSPEED D:50 LOSPEED D:36 LOSPEED D:51 LOSPEED D:37 LOSPEED D:52 LOSPEED D:38 LOSPEED D:53 LOSPEED D:39 LOSPEED D:54 31/84 TP 3997202 S60/S60R 2007...

  • Page 81: 12V Outlet

    Group 37 Wiring and fuses 12V outlet 11E/1 11E/4 54/40D 4/56 A:17 D:12 D:50 D:35 D:34 D:49 10/161 53/406 9/25 31/10 TP 3997202 S60/S60R 2007...

  • Page 82: 12V Outlet, Cargo Compartment

    Group 37 Wiring and fuses, Accessories 12V outlet, cargo compartment 11E/1 4/58 C:14 B:31 C:13 17/19 31/73 TP 3997202 S60/S60R 2007...

  • Page 83: Tow Hitch Cable Harness, 4-Pin

    Group 37 Wiring and fuses, Accessories Tow hitch cable harness, 4-pin 11E/1 4/110 17/37 Stop/Turn Right Stop/Turn Left A:11 Position A:10 Stop/Turn Signal A:12 Left Stop/Turn Signal Right 26/4 4/58 C:13 C:14 31/120 TP 3997202 S60/S60R 2007...

  • Page 84: Tow Hitch Cable Harness, 7-Pin

    Group 37 Wiring and fuses, Accessories Tow hitch cable harness, 7-pin 11E/1 4/110 Turn Left 53/735 17/38 Fog Light Turn Right 53/734 Y-SB Position A:11 Stop Lights A:10 53/733 A:12 4/58 Reverse Lights EXT. D6 C:13 C:14 31/120 TP 3997202 S60/S60R 2007...

  • Page 85: Tow Hitch Cable Harness, 13-Pin

    Tow hitch cable harness, 13-pin 11E/1 4/110 Turn Left Fog Light Turn right 53/734 Y-SB Position Stop Lights A:11 A:10 A:12 4/58 17/39 Reverse Lights EXT. D6 C:13 C:14 53/733 RESERVE: INDICATION TRAILER RESERVE: CHARGING COMMON RETURN 31/120 TP 3997202 S60/S60R 2007...

  • Page 86: Group 38 Instruments

    Group 38 Instruments Seat belt reminder 54/24 3/93 A:25/25 A:26/26 OR-SB B:25/53 B:23/51 B:24/52 3/94 54/25 B:26/54 C:25/81 C:26/82 OR-SB 4/70 4/16 7/32 7/31 BN-P BN-GR Y-GR TP 3997202 S60/S60R 2007...

  • Page 87: Driver Information Module

    5CYL W/O T BL-W A:68 B:13 7/35 5CYL T BL-W A:40 6/31 6/33 BN-SB 53/332 5CYL T A:39 VO-W VO-W 7/130 7/143 5CYL W/O T A:58 VO-W B5244T4/T5, B525T2 USA, B5254T4, B5254T2 KOR 31/93 31/83 31/1 TP 3997202 S60/S60R 2007...

  • Page 88: Driver Information Module, Diesel

    4/46 54/3.1 7/16 B:37 A:60 GR-R A:56 BN-SB B:35 53/400 7/73 6/33 7/130 7/143 DIESEL 54/100 7/25 53/329 A:77 GR-R GR-R A:53 53/397 53/302 B:22 7/166 BN-GR A:34 B:23 A:36 BN-SB A:42 VO-W 31/93 31/83 31/1 TP 3997202 S60/S60R 2007...

  • Page 89: Driver Information Module, Bi-Fuel

    D:44 54/54 7/11 A:14 C:10 A:18 54/36 54/3.1 4/46 A:39 B:46 BN-SB 7/73 6/33 7/156 53/400 7/143 7/16 GR-R A:40 53/329 BN-SB BN-SB A:61 A:55 53/319 A:37 7/25 53/397 53/302 A:48 A:66 B:13 31/93 31/1 31/83 TP 3997202 S60/S60R 2007...

  • Page 90: Group 39 Other

    54/40D 53/448 A:6 VO A:12 D:37 D:52 31/84 54/144 D:58 GN-W MELBUS 16/9 AM/FM RTI/TV BL-W + ANT 16/16 16/68 16/67 54/145 A:10 GR-R + CS 16/26 A:11 - CS 3/131 4/16 3/254 18/4 SWSL SWSR TP 3997202 S60/S60R 2007...
  • Page 91 Audio with auxiliary amplifier 2:2 16/2 B:11 GR-W AMPLIFIER B:12 GR-R GR-R GR-W 54/14 6 5 12 11 54/11 10 9 54/10 GR-W 53/525 53/524 GR-W 53/526 53/523 54/20 54/21 16/17 16/6 16/4 16/55 16/56 16/3 16/5 16/18 TP 3997202 S60/S60R 2007...

  • Page 92: Audio

    + LF - LF 16/6 54/20 53/523 GR-W GR-W GR-W + LR - LR 53/524 16/17 GR-W BL-W 16/9 16/16 + ANT AM/FM RTI/TV 16/67 54/145 16/68 A:12 3/131 3/254 18/4 SWSL SWSR 4/56D:58 4/16 31/84 TP 3997202 S60/S60R 2007...

  • Page 93: Mobile Phone

    Group 39 Other Mobile phone 11C/11 11C/13 16/78 54/24 LHD 54/25 RHD GR-R 16/77 16/60 16/63 16/64 54/143 16/62 GSM/GPS HANDSET 4/56 D:52 D:37 53/438 D:19 D:58 3/131 3/254 18/4 SWSL SWSR GN-W 31/84 TP 3997202 S60/S60R 2007...

  • Page 94: Road Traffic Information Module (Rti)

    D:58 54/40D 16/9 16/16 16/71 AM/FM RTI/TV 16/68 16/67 16/45 16/46 16/36 B:10 53/423 A:13 A:15 C:10 B:10 TV-TUNER 53/602 16/1 53/448 16/47 31/84 31/72 3/131 3/135 3/254 54/10 54/11 18/4 SWSL SWSR 4/56D:58 16/4 16/3 TP 3997202 S60/S60R 2007...

  • Page 95: Road Traffic Information Module (Rti) & Cd Changer

    Group 39 Other, Accessories Road Traffic Information module (RTI) & CD changer 4/56 4/58 11E/4 D:58 11E/1 D:37 D:35 C:14 D:52 D:50 C:13 54/40D D:20 D:21 16/15 16/1 16X/1A CHANGER BL-W A:10 GR-R A:11 A:12 16/45 16/46 53/736 53/737 TP 3997202 S60/S60R 2007...

  • Page 96: Turn-By-Turn Navigation System

    Group 39 Other, Accessories Turn-by-turn navigation system 16/45 16/49 16/68 16/67 C2:10 C2:12 C2:11 MS3200 MT5011 4/58 FUSE 5A EXT. D6 FUSE 5A REVERSE 4/56 SPEED D:59 W-SB 2/238 16/26 W-BN RELAY GN-SB 16X/26 BL-Y BL-GN GN-SB 16/46 31/120 TP 3997202 S60/S60R 2007...

  • Page 97: Handsfree

    Group 39 Other, Accessories Handsfree 16/1 (54/14) 16X/1A BL-W GR-R A:10 A:11 A:12 16X/1B, 54X/14 GR-R GR-R GR-R GR-R GR-W B:11 GR-W B:12 16/93 UNIVERSAL 4/78 B:11 GR-W 16/127 16/64 16/126 TP 3997202 S60/S60R 2007...

  • Page 98: Handsfree Max

    Group 39 Other, Accessories Handsfree MAX 16/1 (54/14) 16X/1A BL-W GR-R A:10 A:11 A:12 16X/1B, 54X/14 GR-R GR-R GR-R GR-R GR-W B:11 GR-W B:12 16/93 4/78 B:11 GR-W GR-SB GR-SB 16/127 16/126 16/64 TP 3997202 S60/S60R 2007...

  • Page 99: Cd Changer

    Group 39 Other, Accessories CD changer 11E/4 11E/1 11E/1 11C/10 11C/11 4/58 4/56 54/40D D:37 D:52 C:14 D:35 C:13 D:50 16/15 16/1 CHANGER A:12 16/45 D:1 R-W 16X/45D 53/602 53/448 31/72 31/120 31/84 TP 3997202 S60/S60R 2007...

  • Page 100: Mp3 Player

    Group 39 Other, Accessories MP3 player 4/58 11E/1 D:21 D:20 C:14 C:13 16/149 16/1 16/45 16X/45D 53/602 31/72 TP 3997202 S60/S60R 2007...

  • Page 101: Satellite Radio

    Group 39 Other, Accessories Satellite radio 11E/1 4/58 D:20 D:21 C:13 C:14 16/153 B:27 16/145 SDARS BL-R A:15 16/1 W/O RTI 16/45 31/120 TP 3997202 S60/S60R 2007...

  • Page 102: Group 43 Transmission Automatic Transmission Aw55-51Sn/Aw51 Awd

    C:21 D:32 54/40D D:47 B:13 C:28 BL-Y B:20 VO-W EXT. D2 4/28 AW 55-51 SN AW51 AWD 8/37 PRNDL SW ENC 54/3.1 53/303 C PA 7/62 7/61 7/74 3/71 3/156 3/155 53/397 BN-SB 53/331 31/93 31/94 TP 3997202 S60/S60R 2007...

  • Page 103: Automatic Transmission Tf-80Sc Awd

    SLC3G B:22 A:14 53/353 HISPEED 8/71 SLTG 8/40 SLUG C:21 C:22 4/56 C:28 8/38 D:16 A:11 C:13 BL-R 8/39 GN-W D:47 D:32 D:23 A:25 EXT. D2 8/36 3/156 3/155 VO-W BL-W GN-W 53/329 54/3.1 53/397 31/93 TP 3997202 S60/S60R 2007...

  • Page 104: Automatic Transmission Tf-80Sc/Tf-80Sc Awd Diesel

    B:22 A:14 53/353 HISPEED 8/71 SLTG 8/40 SLUG C:21 C:22 4/56 8/38 D:16 A:11 C:13 BL-R BL-R 8/39 GN-W GN-W D:47 D:32 D:23 A:25 EXT. D2 8/36 3/156 3/155 VO-W BL-W GN-W 53/329 54/3.1 53/397 31/93 TP 3997202 S60/S60R 2007...

  • Page 105: Geartronic

    Group 43 Transmission Geartronic 11E/5 54/40D 4/56 C:22 C:21 D:32 D:23 BL-W D:47 A:25 VO-W EXT. D2 B:20 EXT. D2 3/156 4/28 A:35 VO-W B:13 54/3.1 B:21 GN-W GN-W B:14 A:54 A:53 53/303 31/94 TP 3997202 S60/S60R 2007...

  • Page 106: Shift Lock

    C:34 BL-W D:23 A:3 A:1 3/156 4/28 54/3.1 AUTO AUTO B:21 GN-W GN-W AUTO 8/36 AUTO AUTO B:13 B:14 A:53 A:54 54/3.1 AUTO AUTO MAN (M66) 53/329 MAN (M66) 8/134 MAN (M66) 53/397 53/303 31/93 31/94 TP 3997202 S60/S60R 2007...

  • Page 107: Differential Electronic Module (Dem)

    Group 43 Transmission Differential Electronic Module (DEM) 11E/1 4/16 4/56 C:21 C:22 D:32 D:47 4/28 4/46 B:13 B:23 DIESEL D:35 B:22 D:50 B:14 B:13 4/58 C:13 C:14 A:14 4/82 54/74 BL-R 31/46 TP 3997202 S60/S60R 2007...

  • Page 108: Group 59 Brake System Brake Control Module (Bcm)

    18/4 7/124 7/91 7/129 54/55 (RHD DSTC) GN-BN 4/68 GN-W 53/331 GR-W DSTC GN-BN DSTC GN-W DSTC GR-W 7/139 53/397 54/56 (RHD DSTC) BL-BN 53/438 OR-W GR-OR DSTC BL-BN DSTC OR-W DSTC 31/95 31/84 31/93 GR-OR TP 3997202 S60/S60R 2007...

  • Page 109: Group 64 Steering Electronic Power Steering

    Group 64 Steering Electronic power steering 11E/1 11E/4 54/40D 4/56 6/71 4/99 C:17 GN-W B:23 C:22 53/398 C:21 D:34 53/329 D:49 53/397 31/93 TP 3997202 S60/S60R 2007...

  • Page 110: Group 76 Shock Absorbers Four-C

    7/88 53/354 7/118 A:12 A:27 7/119 53/355 Y-VO A:17 7/89 A:19 53/570 A:13 A:15 53/569 A:16 8/23 54/107 GN-GR GN-GR A:23 7/121 A:14 A:25 7/120 A:28 8/22 GN-GR GN-GR 3/225 A:24 A:26 A:11 A:29 A:21 31/10 TP 3997202 S60/S60R 2007...

  • Page 111: Group 83 Doors And Openings Central Locking

    B:12 B:12 C:12 DDM/ PDM/ D:28 BL-BN BN-R D:29 B:24 A:12 A:12 53/514 A:13 A:13 53/515 A:11 A:11 3/80 3/82 54/43 54/11 54/21 54/20 54/10 3/74 3/75 3/76 3/77 53/500 54/21 53/501 54/20 31/66 31/46 31/67 TP 3997202 S60/S60R 2007...

  • Page 112: Power Windows

    A:23 A:24 A:16 A:19 A:23 A:24 A:16 C:13 6/60 6/58 GN-BN GN-BN A:19 B:30 53/515 53/514 54/43 54/20 54/21 54/10 54/11 GN-BN GN-BN 3/85 3/86 53/501 10/152 10/151 54/20 53/500 54/21 31/67 6/92 6/93 31/46 31/66 TP 3997202 S60/S60R 2007...

  • Page 113: Power Sunroof

    Group 83 Doors and openings Power sunroof 11C/7 3/25 5 1 3 3/117 4/70 C:11 VO-W 4/33 53/503 53/505 VO-W 54/13 54/13 A:10 53/583 54/13 6/15 53/405 31/6 31/98 31/83 TP 3997202 S60/S60R 2007...

  • Page 114: Group 84 Exterior Decorative Elements Etc

    54/11 3/126 3/127 B:12 B:12 PDM/DDM DDM/PDM A:26 A:27 A:28 A:29 A10 A25 53/514 A:26 A:27 A:28 A:29 A10 A25 53/515 54/11 54/10 6/62 6/63 MEM Y MEM Y MEM X MEM X 53/501 31/66 31/67 TP 3997202 S60/S60R 2007...

  • Page 115: Heated Door Mirrors

    Heated door mirrors 11C/5 11C/4 11E/4 54/40D 3/112 C°/F° 4/56 54/10 54/11 A:10 A:11 54/11 BL-R 54/10 3/126 3/127 B:12 B:12 DDM/PDM PDM/DDM B:11 B:11 6/62 6/63 9/33 27/3 9/34 27/4 53/515 53/514 54/11 54/10 53/501 31/67 31/66 TP 3997202 S60/S60R 2007...

  • Page 116: Heated Rear Window

    Group 84 Exterior decorative elements etc. Heated rear window 11E/1 3/112 4/56 C°/F° D:35 D:50 A:11 4/58 C:13 A:16 C:14 A:15 16/16 16/71 W/O RTI 31/5 TP 3997202 S60/S60R 2007...

  • Page 117: Power Door Mirrors With Camera Function

    Group 84 Exterior decorative elements etc. Power door mirrors with camera function 11E/4 54/40D GN-W 54/11 GN-W GN-W 4/56 54/10 53/515 D:24 53/514 6/62 6/63 27/4 27/3 54/10 54/11 54/10 54/11 BL-R BL-R 53/501 31/66 31/67 TP 3997202 S60/S60R 2007...

  • Page 118: Group 85 Interior Equipment Power Driver's Seat

    RHD 2 VO-W C:10 VO-SB C:11 FORWARD BACK 6/18 LHD 2 RHD 1 LHD 1 BL-Y RHD 2 C:16 Y-SB FORWARD BACK C:12 6/17 C:13 E:10 BL-SB DOWN E:11 BL-R C:14 E:12 C:15 BL-SB DOWN 31/46 31/67 TP 3997202 S60/S60R 2007...

  • Page 119: Power Passenger Seat

    Group 85 Interior equipment Power passenger seat 11E/4 11C/2 54/40D 3/27 4/56 6/65 BL-SB DOWN 6/66 Y-SB DOWN A:22 6/20 VO-SB FORWARD BACK 6/64 GN-SB FORWARD 54/25 LHD STOP LOGIC BACK 54/24 RHD GN-R BL-R 53/501 53/500 31/67 31/46 TP 3997202 S60/S60R 2007...

  • Page 120: Heated Seats

    11E/4 11E/1 4/56 D:49 54/40D D:34 A:19 A:18 3/112 3/91 A:10 C°/F° A:11 54/132 3/92 A:12 GN-W GN-W GN-W GN-W 54/24 54/25 9/12 9/13 9/16 9/17 7/110 7/111 9/18 9/19 54/24 54/25 53/500 53/501 31/46 31/67 TP 3997202 S60/S60R 2007...

  • Page 121: Group 87 Climate Control System

    Group 87 Climate control system Relay, electric engine heater 11E/1 4/58 B:22 4/78 D:19 D:30 2/192 RELAY 53/604 31/102 31/73 TP 3997202 S60/S60R 2007...

  • Page 122: Climate Control System 1:2

    5 CYL W/O T A:61 BN-SB BN-SB 53/319 BN-SB B:13 A:21 BN-GR A:58 VO-W VO-W 53/332 A:55 A:37 5 CYL W/O T B:11 3/112 C°/F° 4/31 6/28 7/41 54/132 A:13 EVAP A:10 7/10 A:11 31/10 31/6 TP 3997202 S60/S60R 2007...
  • Page 123 7/12 Y-GN D:42 C:22 C:21 D:32 6/96 D:47 EXT. D1 A:10 RHD MCC 53/461 Y-GN 6/102 53/458 53/460 53/459 6/48 54/132 Y-GN 3/112 C°/F° 6/69 6/103 Y-GN 7/159 A:12 GN-W Y-GN VO-W GN-W A:16 53/438 31/84 TP 3997202 S60/S60R 2007...

  • Page 124: Climate Control System Diesel 1:2

    53/305 2/22 2(85) 5(87) 54/1B 4/46 B:32 GN-W B:42 7/16 A:60 GR-R A:56 BN-SB DIESEL A:76 BN-SB A:79 BN-GR A:43 VO-W B:22 B:23 3/112 C°/F° 4/31 6/28 7/41 54/132 A:13 EVAP A:10 7/10 A:11 31/10 31/6 TP 3997202 S60/S60R 2007...
  • Page 125 7/12 Y-GN D:42 C:22 C:21 D:32 6/96 D:47 EXT. D1 A:10 RHD MCC 53/461 Y-GN 6/102 53/458 53/460 53/459 6/48 54/132 Y-GN 3/112 C°/F° 6/69 6/103 Y-GN 7/159 A:12 GN-W Y-GN VO-W GN-W A:16 53/438 31/84 TP 3997202 S60/S60R 2007...

  • Page 126: Parking Heater, Auxiliary Heater

    7/143 D:45 7/130, 7/143, GND 54/40D EXT. D1 B:10 D:49 D:34 C:21 C:22 C:32 54/9 GN-W GN-W VO-W VO-W BL-SB 6/73 W-SB 54/9 54/3.1 6/35 9/30 OVERHEAT FLAME TEMP GLOW 54/9 53/501 53/331 53/397 31/93 31/67 TP 3997202 S60/S60R 2007...

  • Page 127: Parking Heater, Remote Start

    Group 87 Climate control system, Accessories Parking heater, remote start 11E/1 4/58 D:30 D:19 B:22 53/604 4X/78A 4/78 4/106 10/218 2/191 31/73 TP 3997202 S60/S60R 2007...

  • Page 128: Parking Heater, Call Start

    Group 87 Climate control system, Accessories Parking heater, Call start 11E/1 4/58 B:22 4/78 D:19 D:30 53/604 4/107 31/73 TP 3997202 S60/S60R 2007...

  • Page 129: Short Stop Heater

    Group 87 Climate control system, Accessories Short stop heater 11B/4 11E/1 11E/5 4/56 54/36 D:43 7/130 D:44 7/143 D:45 7/130, 7/143, GND 54/40D EXT. D1 B:10 D:49 D:34 C:21 C:22 C:32 54/9 GN-W GN-W VO-W VO-W 6/73 54/9 53/331 53/397 31/93 TP 3997202 S60/S60R 2007...

  • Page 130: Group 88 Internal Equipment Supplemental Restraint System (Srs)

    A:28/28 GN-OR 8/66 VO-W A:21/21 A :22/22 OR-SB 7/109 C:27/83 C:28/84 GN-OR 8/67 USA/CDN C:21/77 7/178 54/4 C:22/78 OR-SB 54/3.1 USA/ GN-OR GN-OR GN-OR B:21/49 B:20/48 7/179 USA/ B:18/46 OR-SB OR-SB B:19/47 OR-SB B:23/51 B:25/53 31/67 TP 3997202 S60/S60R 2007...

  • Page 131: Electrically Adjustable Head Restraint

    Group 88 Internal equipment Electrically adjustable head restraint 3/112 11E/1 3/113 C°/F° A:10 A:11 4/58 C:14 C:13 B:28 A:25 8/59 8/60 53/500 53/604 31/46 31/73 TP 3997202 S60/S60R 2007...

  • Page 132: Remote Garage Door Opener

    Group 88 Internal equipment Remote garage door opener 11C/7 11C/6 54/13 4/70 10/114 4/76 53/505 VO-W VO-W 53/583 54/13 53/405 53/503 31/6 31/83 31/98 TP 3997202 S60/S60R 2007...

  • Page 133: Connectors

    GN-SB 11B/13:2 Fuse in engine compartment GN-SB (ETM) fuse box 53/314 Branching point 54/1C 1-pin gray Engine compartment harness Diesel engine harness 11A/1 Main fuse in engine 4/109:11 Glow plug control unit (GCU) compartment fuse box TP 3997202 S60/S60R 2007...
  • Page 134 Body Sensor Cluster Stability 4/16:25 Brake Control Module (BCM) Sensor (BSC) 7/164:2 Body Sensor Cluster Stability 4/16:29 Brake Control Module (BCM) Sensor (BSC) 7/164:3 Body Sensor Cluster Stability 4/16:6 Brake Control Module (BCM) Sensor (BSC) continues TP 3997202 S60/S60R 2007...
  • Page 135 Engine compartment harness 54/34:1 Connector GN-GR 11B/15 Fuse in engine compartment fuse box 54/34:2 Connector GN-R 4/46B:34 Engine Control Module (ECM) GN-R 54/34:3 Connector 4/46B:40 Engine Control Module (ECM) 54/34:4 Connector BL-SB 4/46B:7 Engine Control Module (ECM) BL-SB TP 3997202 S60/S60R 2007...
  • Page 136 Engine compartment harness Accessories harness 11B/5:2 Fuse in engine compartment R-SB 2/64:2 Auxiliary lights harness, fuse box accessories, signal ground 2/64:4 Auxiliary lights harness, accessories, 30-feed 4/56C:9 Central Electronic Module BN-W 2/64:1 Auxiliary light (accessory) relay BN-W (CEM) TP 3997202 S60/S60R 2007...
  • Page 137 Left-hand front door speaker GR-R 54/14:1 Connector 16/1B:2 Audio Module (AUM) 16/4:2 Left-hand front door speaker 54/14:2 Connector 31/66 Ground connection 53/514 Branching point 4/56D:24 Central Electronic Module GN-W 27/3:5 Left Camera Module (LCM) GN-W (CEM) 54/11:12 Connector TP 3997202 S60/S60R 2007...
  • Page 138 4/9B:11/39 Supplemental Restraint System OR-SB 8/31:2 Passenger side airbag igniter (SRS) 4/9B:14/42 Supplemental Restraint System GN-OR 8/32:2 Igniter, passenger side airbag (SRS) stage 2 4/9B:13/41 Supplemental Restraint System 8/32:1 Igniter, passenger side airbag (SRS) stage 2 TP 3997202 S60/S60R 2007...
  • Page 139 Amplifier 54/11:9 Connector GR-R 16/2B:5 Amplifier GR-R 54/11:10 Connector 16/2B:6 Amplifier 53/523 Branching point GR-W 16/2B:7 Amplifier GR-W 53/524 Branching point 16/2B:8 Amplifier 9-10 53/525 Branching point GR-W 16/2B:11 Amplifier GR-W 53/526 Branching point 16/2B:12 Amplifier TP 3997202 S60/S60R 2007...
  • Page 140 Rear Electronic Module (REM) 3/76:6 Left-hand rear door lock unit 4/58A:23 Rear Electronic Module (REM) 3/76:4 Left-hand rear door lock unit 53/500 Branching point 3/76:1 Left-hand rear door lock unit 3/85:2 Rear left door power window switch TP 3997202 S60/S60R 2007...
  • Page 141 Left-hand front lamp housing (CEM) 4/56C:12 Central Electronic Module GN-R 6/38:2 Left-hand headlight level GN-R (CEM) adjustment motor 4/56B:27 Central Electronic Module 10/1A:1 Left-hand front lamp housing (CEM) 4/56B:31 Central Electronic Module 10/13:1 Front left direction indicator (CEM) continues TP 3997202 S60/S60R 2007...
  • Page 142 Branching point 10/12:3 Front right running/parking light 10/14:2 Front right direction indicator 10/73:2 Side running light, front right 6/39:1 Right-hand headlight level adjustment motor 10/2A:4 Right-hand front lamp housing 54/3.1:25 Connector GN-W 10/2A:7 Right-hand front lamp housing TP 3997202 S60/S60R 2007...
  • Page 143 Branching point, LHD seat 4/52A:2 Power Seat Module (PSM) 4/52B:4 Power Seat Module (PSM) 4/9A:25/25 Supplemental Restraint 3/93:1 Switch, left-hand seat belt System (SRS) buckle 4/9A:26/26 Supplemental Restraint OR-SB 3/93:2 Switch, right-hand seat belt System (SRS) buckle TP 3997202 S60/S60R 2007...
  • Page 144 4/9C:26/82 Supplemental Restraint System OR-SB 3/94:2 Switch, right-hand seat belt (SRS) buckle 31/67 Ground connection, front seat 7/93:D Occupant Weight Sensor riser, right-hand side, USA (OWS), USA 53/437 Branching point VO-W 7/93:G Occupant Weight Sensor (OWS), USA TP 3997202 S60/S60R 2007...
  • Page 145 Central Electronic Module 6/33:2 Fuel pump (CEM) 6/33:E Fuel pump 31/48 Ground connection 6/33 Fuel pump 53/579 Branching point 4/56A:16 Central Electronic Module 6/33 Fuel pump (CEM) 53/578 Branching point 54/3.1:8 Connector 4/83:1 Fuel pump control module TP 3997202 S60/S60R 2007...
  • Page 146 Engine Control Module (ECM) BN-SB 7/24:1 Front knock sensor 4/46A:64 Engine Control Module (ECM) 7/24:2 Front knock sensor 4/46A:45 Engine Control Module (ECM) 7/23:1 Rear knock sensor 4/46A:67 Engine Control Module (ECM) Y-SB 7/23:2 Rear knock sensor TP 3997202 S60/S60R 2007...
  • Page 147 (TCM) (CEM) 4/28A:5 Transmission Control Module 4/46B:34 Engine Control Module (ECM) (TCM) 4/28A:6 Transmission Control Module 53/353 Branching point (TCM) 4/28A:14 Transmission Control Module 53/352 Branching point (TCM) 4/28A:9 Transmission Control Module 53/329 Branching point (TCM) TP 3997202 S60/S60R 2007...
  • Page 148 Front fuel tank harness, Bi-Fuel 4/58B:25 Rear Electronic Module (REM) 8/89:1 Front left solenoid, fuel tank 54/54:7 Connector 8/90: 1 Front right solenoid, fuel tank 53/604 Branching point 8/89:2 Front left solenoid, fuel tank 8/90:2 Front right solenoid, fuel tank TP 3997202 S60/S60R 2007...
  • Page 149 Temperature sensor, evaporator 3/112A:13 Climate Control Module (CCM) 7/41:3 Temperature sensor, evaporator 3/112A:7 Climate Control Module (CCM) GN-W 53/460 Branching point GN-W 54/25:4 Connector 6/96:2 Damper Motor Module (DMM), right-hand side, RHD 53/438 Branching point 53/459 Branching point TP 3997202 S60/S60R 2007...
  • Page 150 (PAM) 4/86B:8 Parking Assistance Module 54/1300:2 Connector (PAM) 4/86B:7 Parking Assistance Module 54/1300:3 Connector (PAM) 4/86B:6 Parking Assistance Module 54/1300:4 Connector (PAM) 4/86B:5 Parking Assistance Module 54/1300:5 Connector (PAM) 4/86B:1 Parking Assistance Module 54/1300:6 Connector (PAM) TP 3997202 S60/S60R 2007...

  • Page 151: Branching Points

    5 CYL W/O T, Bi-Fuel 5 W/O T, Bi-Fuel BN-SB 7/81:2 5 CYL W/O T, Bi-Fuel P204_53-304 P204_53-319 53/305 53/324 11B/11 7/123:4 BL-R 7/51:6 54/3.1 4/46B:4 53/324 53/305 BL-R BL-R 7/51:1 2/22:2 EB-FAN BL-R BL-R 2/22:3 6/44:1 P205_53-305 P204_53-324 TP 3997202 S60/S60R 2007...
  • Page 152 53/332 5 CYL T VO-W VO-W 7/165:3 7/8:3 7/87:2 7/119:3 5 CYL T Bi-Fuel VO-W VO-W 4/46A:39 7/201:1 53/355 54/3.1 VO-W VO-W 7/81:3 4/46A:58 5 CYL W/O T, Bi-Fuel 5 CYL W/O T, Bi-Fuel P204_53-332 P204_53-355 TP 3997202 S60/S60R 2007...
  • Page 153 P204_53-376 P204_53-397 53/382 53/398 4/56 16/10:2 16/11:2 B:23 54/4 3/62:2 54/22 53/382 ECPS 4/99:4 53/398 54/23 P204_53-382 P204_53-398 53/384 53/399 Bi-Fuel 15/31_A1:1 53/399 20/16:1 53/384 BN-SB BN-SB 4/16:47 4/16:16 11B/1 11B/2 11B/17 11B/16 31/95 P204_53-384 P205_53-399 TP 3997202 S60/S60R 2007...
  • Page 154 10/29:2 3/254:8 10/126:4 17/13:16 53/425 3/111:1 31/6 P204_53-405 P204_53-425 53/406 SUM 53/430 4/56D:31 53/406 4/84C:2 9/1:1 4/56D:32 4/56C:21 53/430 31/10 P204_53-406 P204_53-430 53/408 53/431 4/56D:8 4/56D:46 3/157:1 3/1:6 53/408 4/56C:22 4/9B:27 4/56D:47 4/9:55 53/431 P204_53-408 P204_53-431 TP 3997202 S60/S60R 2007...
  • Page 155 6/103:1 P204_53-436 P204_53-458 53/437 53/459 4/56 6/95:3 6/48:3 A:10 53/459 EXT. D1 6/96:3 54/132 VO-W 54/24 7/159:3 6/102:3 53/437 VO-W VO-W 3/112A:1 54/25 6/69:3 6/103:3 VO-W VO-W 5/1:3 54/132 USA / CDN VO-W 54/25 P204_53-437 P204_53-459 TP 3997202 S60/S60R 2007...
  • Page 156 53/500 53/515 3/127B:5 31/46 P204_53-500 P204_53-515 53/501 53/516 6/35:2 54/11 4/56D:38 54/21 4/56D:37 54/25 53/501 53/516 4/56D:39 31/67 P204_53-501 P204_53-516 53/503 53/517 10/19:5 54/16 4/56D:53 53/503 7/122:5 4/56D:52 53/517 4/70:20 54/13 4/56D:54 4/33A:5 31/98 P204_53-503 P204_53-517 TP 3997202 S60/S60R 2007...
  • Page 157 GR-W GR-W 16/18:1 54/21 54/3.1 7/89:2 53/570 53/525 P204_53-525 P204_53-570 53/526 53/578 16/1B:12 54/14 4/83:2 54/21 16/18:2 54/36 6/33:8 53/526 53/578 P204_53-526 P204_53-578 53/567 SUM 53/579 4/83:3 4/84A:16 54/36 4/56D:32 53/579 53/584 6/33:12 53/567 P204_53-567 P204_53-579 TP 3997202 S60/S60R 2007...
  • Page 158 4/58D:20 P205_53-585 P204_53-664 53/601 53/733 17/37:4 10/18A:4 17/38:3 4/110A:10 10/127:4 10/18B:6 53/601 17/39:13 17/39:3 53/733 31/120 31/72 P204_53-601 P204_53-733 53/602 53/734 Y-SB 4/110A:4 4/58D:12 17/38:5 17/38:7 16/45D:5 7/100:5 53/602 17/39:5 17/39:7 4/86A:8 53/734 31/72 P204_53-602 P204_53-734 TP 3997202 S60/S60R 2007...
  • Page 159 Branching points 53/735 - 53/737 53/735 53/737 16/46 16/15:1 17/38:2 4/110A:2 16/45D:5 BL-Y Y-SB 4/58E:F 53/737 4/58E:H 53/735 31/120 P204_53-735 P204_53-737 53/736 16/46 16/15:2 16/45D:1 53/736 4/58B:8 P204_53-736 TP 3997202 S60/S60R 2007...

  • Page 160: Cable Harness Routing In Vehicle Engine Harness, Gasoline

    Cable harness routing in vehicle Engine harness, Gasoline 53/332 53/314 53/315 54/1B 53/326 53/328 53/319 53/304 53/376 53/309 53/375 W/O Turbo 53/375 53/376 W/O Turbo 53/360 54/7 Bi-Fuel 54/53 Turbo TP 3997202 S60/S60R 2007...

  • Page 161: Engine Harness, Diesel

    Cable harness routing in vehicle Engine harness, Diesel 53/335 54/1B 54/100 54/1C TP 3997202 S60/S60R 2007...

  • Page 162: Engine Compartment Harness, Lhd

    Cable harness routing in vehicle Engine compartment harness, LHD 53/303 53/302 53/355 53/324 53/354 53/398 54/23 54/3.1 54/7 Bi-Fuel 54/1B 53/394 54/3.2 54/57.1 53/329 53/384 53/397 53/395 53/301 53/352 54/4 53/331 54/9 54/22 54/1C 54/8 53/353 TP 3997202 S60/S60R 2007...

  • Page 163: Engine Compartment Harness, Rhd

    Cable harness routing in vehicle Engine compartment harness, RHD 54/3.1 53/303 53/302 53/355 53/324 53/354 53/398 54/55 54/23 54/7 54/56 Bi-Fuel 53/394 54/57.1 53/329 53/384 53/397 53/301 53/331 53/395 53/353 53/352 54/4 54/22 54/9 54/8 54/1C TP 3997202 S60/S60R 2007...

  • Page 164: Passenger Compartment Harness, Lhd

    53/525, 53/526 54/32 53/433, 53/434 54/14 54/74 53/501 53/406 53/567, 53/568 54/11 54/20 54/132 53/448 53/425 54/13 54/12 53/415 53/423 53/403 53/408 54/24 53/438 53/405 53/500 53/400 54/3.1 53/584, 53/585 54/10 54/3.2 53/569, 53/570 53/523, 53/524 TP 3997202 S60/S60R 2007...

  • Page 165: Passenger Compartment Harness, Rhd

    54/107 54/11 53/437 53/501 54/32 53/433 54/74 54/132 53/408 53/567, 53/568 54/25 54/14 54/3.1 54/20 53/448 53/438 53/525, 53/526 54/13 53/443 54/24 53/405 54/12 53/434, 53/433 54/10 53/406 53/400 53/500 53/524, 53/523 53/584, 53/585 53/570 53/569 TP 3997202 S60/S60R 2007...

  • Page 166: Cargo Compartment Harness

    Cable harness routing in vehicle Cargo compartment harness 53/604 53/601 54/54 53/602 54/106 54/35 54/43 54/36 54/40D 53/578 54/40C 53/579 TP 3997202 S60/S60R 2007...

  • Page 167: Roof Harness

    Cable harness routing in vehicle Roof harness 53/503 53/583 53/505 54/16 54/13 TP 3997202 S60/S60R 2007...

  • Page 168: Trunk Lid/Tailgate Harness

    Cable harness routing in vehicle Trunk lid/tailgate harness TP 3997202 S60/S60R 2007...

  • Page 169: Door Harness

    Cable harness routing in vehicle Door harness 53/515 53/514 54/11 54/10 54/20 54/21 TP 3997202 S60/S60R 2007...

  • Page 170: Bi-Fuel Harness

    Cable harness routing in vehicle Bi-Fuel harness 54/54 54/106 TP 3997202 S60/S60R 2007...

  • Page 171: Component Illustrations

    2/32 2-32_97 2-182_97 2/191 Relay, remote parking heater start, radio signal 2/35 Starter motor relay FST3 FMA3 FMA2 FST2 FMA1 FST1 2/35 2-35_97 2-191_97 2/64 Auxiliary light (accessory) relay 2/192 Relay, electric engine heater 2-192_97 2-64_97 TP 3997202 S60/S60R 2007...
  • Page 172 3-4_97 3-25_97 Hazard warning flasher switch 3/26 Switch unit, power driver’s seat 3-6_97 3-26_97 Switch, heated rear window/door mirrors 3/27 Switch unit, power passenger seat 3-8_97 3-27_97 Brake light contact 3/35 Trunk handle switch 3-9_97 3-35_97 TP 3997202 S60/S60R 2007...
  • Page 173 3/59 Headlight adjustment control 3/75 Right-hand front door lock unit 3-59_97 3-75_97 3/60 Auxiliary light switch 3/76 Left-hand rear door lock unit 3-60_97 3-76_97 3/62 Hood alarm contact 3/77 Right-hand rear door lock unit 3-62_97 3-77_97 TP 3997202 S60/S60R 2007...
  • Page 174 3/93 Switch, left-hand seat belt buckle 3-82_97 3-93_97 3/85 Rear left door power window switch 3/94 Switch, right-hand seat belt buckle 3-85_97 3-94_97 3/86 Rear right door power window switch 3/95 Spin control switch 3-86_97 3-95_97 TP 3997202 S60/S60R 2007...
  • Page 175 3-131_97 3/113 Rear adjustable head restraint relay 3/135 RTI switch 3-113_97 3-135_97 3/155 Mode selector, automatic transmission 3/117 Switch unit, dome light 3-117_97 3-155_97 3/126 Driver/Passenger Door Module (DDM)/(PDM) 3/156 Gear Selector Module (GSM) 3-126_97 3-156_97 TP 3997202 S60/S60R 2007...
  • Page 176 3/173 Switch, trunk lid private lock Supplemental Restraint System (SRS) 3-173_97 4-9_97 3/174 Switch, reduced alarm 4/16 Brake Control Module (BCM) 3-174_97 4-16_97 3/225 Switch unit, Continuously Controlled Damping (CCD), S60R 4/28 Transmission Control Module (TCM) COMFORT SPORT ADVANCED 3-225_97 4-28_97 TP 3997202 S60/S60R 2007...
  • Page 177 4/33 Sunroof Module (SRM) 4/56 Central Electronic Module (CEM) 4-56_97 4-33_97 4/46 Engine Control Module (ECM) 4/58 Rear Electronic Module (REM) 4-58_97 4-46_97 4/46 Engine Control Module (ECM), Diesel 4/58A-G Rear Electronic Module (REM) 4-58_A-G_97 4-46_DIESEL_97 TP 3997202 S60/S60R 2007...
  • Page 178 Cooling fan control module 4/83 Fuel pump control module 4-71_97 4-83_97 4/71 Cooling fan control module, Diesel 4/84 Suspension Module (SUM) 4-71_DIESEL_97 4-84_97 4/76 Remote control unit for garage door opener 4/86 Parking Assistance Module (PAM) 4-76_97 4-86_97 TP 3997202 S60/S60R 2007...
  • Page 179 4-106_97 5-1_97 4/107 Control module, parking heater, Call start Windshield wiper motor 4-107_97 6-1_97 4/109 Glow plug control unit (GCU) Right-hand headlight wiper motor 4-109_97 6-3_97 4/110 Trailer Module (TRM) Left-hand headlight wiper motor 4-110_97 6-4_97 TP 3997202 S60/S60R 2007...
  • Page 180 Driver seat motor, up/down front edge 6/26 Alternator Control Module (ACM) 6-17_97 6-26_97 6/18 Driver seat motor, up/down rear edge 6/28 Motor, passenger compartment fan 6-18_97 6-28_97 6/19 Driver seat motor, forward/backward 6/29 Motor, cooling fan 6-19_97 6-29_97 TP 3997202 S60/S60R 2007...
  • Page 181 6/35 Fuel pump, auxiliary heater 6-35_97 6-48_97 6/37 Lock motor, fuel filler cover 6/58 Motor, front left power window 6-37_97 6-58_97 6/38 Left-hand headlight level adjustment motor 6/60 Motor, front right power window 6-38_97 6-60_97 TP 3997202 S60/S60R 2007...
  • Page 182 Passenger seat motor, backrest angle 6-71_97 6-64_97 6/65 Passenger seat motor, up/down front edge 6/73 Coolant pump, auxiliary heater 6-65_97 6-73_97 6/66 Passenger seat motor, up/down rear edge 6/92 Motor, rear left power window 6-66_97 6-92_97 TP 3997202 S60/S60R 2007...
  • Page 183 Damper Motor Module (DMM), temperature, right 6/114 Vacuum pump 6-96_97 6-114_97 6/102 Damper Motor Module (DMM), defroster 6/118 Regulator motor, swirl throttle 6-102_97 6-118_97 6/103 Damper Motor Module (DMM), floor/ventilation 6/120 Throttle body motor 6 5 4 6-103_97 6-120_97 TP 3997202 S60/S60R 2007...
  • Page 184 6-127_97 7-8_97 6/143 Regulator motor, turbo 7/10 Interior temperature sensor 7-10_97 6-143_97 Brake fluid level sensor 7/11 Outside temperature sensor 7-4_97 7-11_97 7/12 Solar sensor, twilight sensor and indicator alarm Washer fluid level sensor 7-5_97 7-12_97 TP 3997202 S60/S60R 2007...
  • Page 185 7-15_DIESEL_97 7/16 Coolant temperature sensor 7/25 Impulse sensor, Diesel DIESEL 7-25_97 7-16_97 7/17 Mass airflow sensor (MAF) 7/31 Left-hand front ABS sensor 7-31_97 7-17_97 7/23 Rear knock sensor 7/32 Right-hand front ABS sensor 7/23 7-23_97 7-32_97 TP 3997202 S60/S60R 2007...
  • Page 186 7-41_97 7-61_AWD_97 7/51 Accelerator pedal sensor 7/62 Output speed sensor 7/62 7-51_97 7-62_97 7/56 Left-hand rear ABS sensor 7/62 Output speed sensor, TF-80SC/AWD 7-56_97 7-62_AWD_97 7/57 Right-hand rear ABS sensor 7/73 Coolant level sensor 7-57_97 7-73_97 TP 3997202 S60/S60R 2007...
  • Page 187 7-91_97 7-91_97 7-91_97 7-91_97 7-91_97 7-91_97 7-91_97 7-91_97 7-91_97 7-81_97 7-91_97 7/82 Rear heated oxygen sensor 7/93 Occupant Weight Sensor (OWS) 7-82_97 7-93_97 7/87 Acceleration sensor, Four-C, front left 7/100 Inclination Sensor Module (ISM) 7-87_97 7-100_97 TP 3997202 S60/S60R 2007...
  • Page 188 7/109 Right-hand rear side impact sensor 7-109_97 7-118_97 7/119 Acceleration sensor, shock absorber, Four-C, front right 7/110 Left-hand seat temperature sensor 7/110 7-110_97 7-119_97 7/120 Rear left angle sensor, Four-C/ Bi-Xenon 7/111 Right-hand seat temperature sensor 7/111 7-111_97 7-120_97 TP 3997202 S60/S60R 2007...
  • Page 189 7-131_7-134_97 7/123 Clutch pedal sensor 7/139 Brake pressure sensor 1 7-123_97 7-139_97 7/124 Brake pedal sensor 7/143 Fuel level sensor, pump side 7-124_97 7-143_97 7/129 Brake pressure sensor 2 7/149 Rain Sensor Module (RSM) 7-129_97 7-149_97 TP 3997202 S60/S60R 2007...
  • Page 190 7/156 Pressure and temperature sensor, Bi-Fuel 7/166 Oil level sensor, Diesel 7-156_Bi-Fuel_97 7-166_97 7/159 Air Quality Sensor (AQS) 7/172 Camshaft position sensor, intake side 7-172_97 7-159_97 7/173 Camshaft position sensor, exhaust side 7/162 Fuel rail pressure sensor, Diesel 7-162_DIESEL_97 7-173_PETROL_97 TP 3997202 S60/S60R 2007...
  • Page 191 7/178 Front impact sensor, right RF/O RF/I LF/I LF/O 7-178_97 7-204_7-207_97 Electromagnetic clutch, climate con- trol system 7/179 Front impact sensor, left 8-3_97 7-179_97 7/190 Temperature sensor, exhaust gases upstream of particle filter 8/6-11 Injectors 7-190_97 8-6-8-11_PETROL_97 TP 3997202 S60/S60R 2007...
  • Page 192 Solenoid, variable valve timing intake 8/28 Turbo control valve 8-19_97 8-28_97 8/20 Shock absorber, Four-C, front left 8/30 Driver’s side airbag igniter 8-20_97 8-30_97 8/21 Shock absorber, Four-C, front right 8/31 Passenger side airbag igniter 8-21_97 8-31_97 TP 3997202 S60/S60R 2007...
  • Page 193 Front right seat belt tensioner igniter 8/38 Shift solenoid 1, AW55-51/51 AWD 8-34_97 8-38_AW55-50_97 8/36 Shift lock solenoid 8/39 Shift solenoid 2, TF-80SC/AWD 8-36_97 8-39_AWD_97 8/37 Automatic transmission, TF-80SC/AWD 8/39 Shift solenoid 2, AW55-51/51 AWD 8-37_AWD_97 8-39_AW55-50_97 TP 3997202 S60/S60R 2007...
  • Page 194 Rear right belt tensioner igniter 8-56_97 8-41_AW55-50_97 8/46 Archive unit, DSTC 8/59 Rear left head restraint solenoid 8/59 8/46 8-46_97 8-59_97 8/51 Front left side airbag igniter 8/60 Rear right head restraint solenoid 8/60 8-51_97 8-60_97 TP 3997202 S60/S60R 2007...
  • Page 195 Solenoid valve, engine mounting, Diesel 8/72 Shift solenoid 3, AW55-51SN/AW51 AWD 8-64_97 8-72_97 8/66 Left-hand inflatable curtain igniter 8/73 Shift solenoid 4, AW55-51SN/AW51 AWD 8-66_97 8-73_97 8/67 Right-hand inflatable curtain igniter 8/74 Shift solenoid 5, AW55-51SN/AW51 AWD 8-67_97 8-74_97 TP 3997202 S60/S60R 2007...
  • Page 196 Switch, vacuum pump 8/98 Fuel pressure control valve, Diesel 8-84_97 8-98_97 8/85 Thermostatic switch and fuel filter heating 8/111 High-pressure solenoid valve, Diesel 8-85_97 8-111_97 8/88 Rear solenoid, fuel tank, Bi-Fuel 8/113 Bypass valve, EGR cooling 8-88_97 8-113_97 TP 3997202 S60/S60R 2007...
  • Page 197 8/142 Linear pressure solenoid SLB1 TF-80SC/AWD Heated rear window 9-2_97 8-142_AWD_97 8/143 Linear pressure solenoid SLC1 TF-80SC/AWD 9/12 Seat Heating Module (SHM), left 8-143_AWD_97 9-12_97 8/144 Linear pressure solenoid SLC2 TF-80SC/AWD 9/13 Seat Heating Module (SHM), right 8-144_AWD_97 9-13_97 TP 3997202 S60/S60R 2007...
  • Page 198 Left-hand seat heating element 9/33 Left-hand heated door mirror 9/33 9/18 9-18_97 9-33_97 9/19 Right-hand seat heating element 9/34 Right-hand heated door mirror 9/34 9/19 9-19_97 9-34_97 9/25 Rear 12V outlet 10/1 Left-hand front lamp housing 9-25_97 10-1_97 TP 3997202 S60/S60R 2007...
  • Page 199 Front left fog light 10/14 Front right direction indicator 10-5_97 10-14_97 10/6 Front right fog light 10/15 Direction indicator, left door mirror 10-6_97 10-15_97 10/11 Front left running/parking light 10/16 Direction indicator, right door mirror 10-11_97 10-16_97 TP 3997202 S60/S60R 2007...
  • Page 200 10-44_97 10/19 Auxiliary brake light 10/45 Right-hand tail light lamp 2 10-19_97 10-45_97 10/29 Glove compartment lighting 10/46 Fog light, rear right 10-29_97 10-46_97 10/42 Rear right running/parking light 10/47 Right-hand rear direction indicator 10-42_97 10-47_97 TP 3997202 S60/S60R 2007...
  • Page 201 10-54_97 10/50 Left brake light 10/55 Left-hand reversing light 10-50_97 10-55_97 10/51 Left-hand tail light lamp 1 10/64 Right-hand high beam 10-51_97 10-64_97 10/52 Left-hand tail light lamp 2 10/65 Auxiliary light, front right 10-52_97 10-65_97 TP 3997202 S60/S60R 2007...
  • Page 202 10/69 Auxiliary light, front left 10/115 Right-hand vanity mirror lighting 10-69_97 10-115_97 10/70 Left-hand low beam 10/125 Left-hand front courtesy lighting 10-70_97 10-125_97 10/71 Side running light, front left 10/126 Right-hand front courtesy lighting 10-126_97 10-71_97 TP 3997202 S60/S60R 2007...
  • Page 203 10/148 Left-hand rearview mirror lighting 21 17 13 18 14 10 10-148_97 11B_97 11C/no. Fuses in passenger compartment fuse box 10/149 Right-hand rearview mirror lighting 10-149_97 11C_x_97 10/150 Rear reading light 11E/no. Main fuses at battery 11E/7 11E/1 10-150_97 11E_97 TP 3997202 S60/S60R 2007...
  • Page 204 16/5 Right-hand rear door speaker 16-5_97 15-31_97 16/1 Audio Module (AUM) 16/6 Left-hand rear door speaker 16-1_97 16-6_97 16/2 Amplifier 16/9 Window antenna 16/9 16-2_97 16-9_97 16/3 Right-hand front door speaker 16/10 Horn 1 16-3_97 16-10_97 TP 3997202 S60/S60R 2007...
  • Page 205 16/16 Window antenna amplifier 16/36 TV receiver 16-16_97 16-36_97 16/17 Left-hand speaker, rear shelf 16/45 Road Traffic Information module (RTI) 16-17_97 16-45_97 16/45 Road Traffic Information module (RTI), Turn-by-turn 16/18 Right-hand speaker, rear shelf 16-18_97 16-45_TBT_97 TP 3997202 S60/S60R 2007...
  • Page 206 16-46_TBT_97 16-60_97 16/47 GPS antenna RTI 16/62 Hand unit, mobile phone 16-47_97 16-62_97 16/49 Traffic Message Channel module (TMC) 16/64 Antenna, mobile phone 16-64_97 16-49_97 16/65 Antenna ring/ignition switch illumination 16/55 Left-hand front tweeter 16-55_97 16-65_97 TP 3997202 S60/S60R 2007...
  • Page 207 16/126 Holder, mobile phone handsfree 16-68_97 16-126_97 16/71 Window antenna amplifier 1, right 16/127 Microphone, mobile phone handsfree 16-71_97 16-127_97 16/77 Microphone, mobile phone 16/145 Satellite radio receiver 16-77_97 16-145_97 16/78 Speaker, mobile phone 16/149 MP3 player 16-78_97 16-149_97 TP 3997202 S60/S60R 2007...
  • Page 208 18/4 Contact reel 18-4_97 17-17_97 17/19 12V outlet, cargo compartment 20/3-8 Spark plug and ignition coil 17-19_97 20-3-8_97 17/37 4-pin outlet, tow hitch cable harness 20/16 Capacitor 20/16 FST3 FMA3 FMA2 FST2 FMA1 FST1 17-37_97 20-16_97 TP 3997202 S60/S60R 2007...
  • Page 209 Left Camera Module (LCM) 31/5 Ground connection, right D-post 31-5_97 27-3_97 31/6 Ground connection, driver’s side 27/4 Right Camera Module (RCM) A-post 31-6_97 27-4_97 31/1 Ground connection, right MacPherson strut tower 31/10 Ground connection, right side A-post 31-1_97 31-10_97 TP 3997202 S60/S60R 2007...
  • Page 210 31/70 Ground connection, left side member, riser lower engine compartment 31-47_97 31-70_97 31/48 Ground connection, rear right seat 31/72 Ground connection, cargo riser compartment 31-48_97 31-72_97 31/73 Ground connection, rear right seat riser 31/53 Ground connection, firewall 31-53_97 31-73_97 TP 3997202 S60/S60R 2007...
  • Page 211 1 MacPherson strut tower 31-88_97 31-95_97 31/89 Ground connection, Engine ignition 31/96 Ground connection, right coil group 2 MacPherson strut tower 31-89_97 31-96_97 31/98 Ground connection, upper windshield member 31/91 Ground connection, engine 31-91_97 31-98_97 TP 3997202 S60/S60R 2007...
  • Page 212 54/3.1 Connector 1 10 9 18 31-120_97 54-3.1_97 53/no. Branching point 54/3.2 Connector DIESEL DIESEL 4/46B:23 54/57.1 4/28A:6 4/56C:22 TF-80SC (AWD) 53/353 4/46B:1 53-NR_97 54-3.2_97 54/1 Connector 54/4 Connector 54-1_97 54-4_97 54/1B Connector 54/7 Connector 54-7_97 54-1B_97 TP 3997202 S60/S60R 2007...
  • Page 213 Component illustrations 54/8 - 54/22-23 54/8 Connector 54/14 Connector 54-8_97 54-14_97 54/9 Connector 54/16 Connector 54-9_97 54-16_97 54/10-11 Connector 54/20 Connector 54-10-11_97 54-20_97 54/12 Connector 54/21 Connector 54-12_97 54-21_97 54/13 Connector 54/22-23 Connector 54-13_97 54-22-23_97 TP 3997202 S60/S60R 2007...
  • Page 214 Component illustrations 54/24 - 54/53 54/24 Connector 54/36 Connector 54-24_97 54-36_97 54/25 Connector 54/40C Connector 54-40C_97 54-25_97 54/32 Connector 54/40D Connector 54-32_97 54-40D_97 54/34 Connector 54/43 Connector 54-34_97 54-43_97 54/35 Connector 54/53 Connector 54-35_97 54-53_97 TP 3997202 S60/S60R 2007...
  • Page 215 Component illustrations 54/54 - 54/1300 54/54 Connector 54/100 Connector 54-54_97 54-100_97 54/55 Connector 54/106 Connector 54-55_97 54-106_97 54/56 Connector 54/107 Connector 54-56_97 54-107_97 54/57.1 Connector 54/132 Connector 54-132_97 54-57.1_97 54/74 Connector 54/1300 Connector 54-74_97 54-1300_97 TP 3997202 S60/S60R 2007...
  • Page 216 Component illustrations 54/1400 54/1400 Connector 54-1400_97 TP 3997202 S60/S60R 2007...

  • Page 217: Index 1:2

    Overview of control module locations ........22 ........8 Engine compartment FMA1 - FST3 Overview of electrical distribution ........ 162 Engine compartment harness ............55 Engine control, Group 27 ............161 Engine harness, Diesel ..............77 Parking assistance TP 3997202 S60/S60R 2007...

  • Page 218: Table Of Contents

    Road Traffic Information module (RTI) and CD ..................95 changer ............. 72 ................167 Wiper/washer, headlights Roof harness ............. 71 Wiper/washer, windshield Running/parking lights, tail lights & license plate ..........80 ..................64 Wiring and fuses, Group 37 lighting TP 3997202 S60/S60R 2007...

  • Page 219: List Of Components 1:6

    3/111 Light Switch Module (LSM) 4/109 Glow plug control unit (GCU) 3/112 Climate Control Module (CCM) 4/110 Trailer Module (TRM) 3/113 Rear adjustable head restraint relay 4/118 Headlamp control module (HCM) 3/117 Switch unit, dome light TP 3997202 S60/S60R 2007...
  • Page 220 Acceleration sensor, Four-C, front right 6/103 Damper Motor Module (DMM), floor/ ventilation 7/89 Acceleration sensor, Four-C, rear left 6/104 High pressure headlight washer motor 7/91 Steering angle sensor 6/105 Fuel distributor, gas 7/93 Occupant Weight Sensor (OWS) TP 3997202 S60/S60R 2007...
  • Page 221 8/6-10 Injectors, Diesel 8/144 Linear pressure solenoid SLC2 8/18 EVAP valve TF-80SC/AWD 8/19 Solenoid, variable valve timing intake 8/145 Linear pressure solenoid SLC3 8/20 Shock absorber, Four-C, front left TF-80SC/AWD 8/21 Shock absorber, Four-C, front right TP 3997202 S60/S60R 2007...
  • Page 222 Rear left running/parking light 16/4 Left-hand front door speaker 10/50 Left brake light 16/5 Right-hand rear door speaker 10/51 Left-hand tail light lamp 1 16/6 Left-hand rear door speaker 10/52 Left-hand tail light lamp 2 16/9 Window antenna TP 3997202 S60/S60R 2007...
  • Page 223 7-pin outlet, tow hitch cable harness tower 17/39 13-pin outlet, tow hitch cable harness 31/98 Ground connection, upper windshield member 18/4 Contact reel 31/102 Ground connection, front member 31/120 Ground connection, cargo compartment 20/3-8 Spark plug and ignition coil TP 3997202 S60/S60R 2007...
  • Page 224 54/10-11 Connector 54/56 Connector 54/12 Connector 54/57.1 Connector 54/13 Connector 54/74 Connector 54/14 Connector 54/100 Connector 54/16 Connector 54/106 Connector 54/20 Connector 54/107 Connector 54/21 Connector 54/132 Connector 54/22-23 Connector 54/1300 Connector 54/24 Connector 54/1400 Connector TP 3997202 S60/S60R 2007...
  • Page 225 TP 3997202 (US English). Printed in Sweden, Gothenburg 06-2006...

This manual is also suitable for:

S60r2007 s602007 s60r

Table of Contents
