Venstar T2900SCH Specification

STANDARD FEATURES:
•
Weekday/weekend program designed for schools, very easy to program
•
Manual activation of program prevents conditioning of unoccupied rooms.
•
Automatically returns to energy saving setpoints at end of school day.
•
Auto changeover, 3-stage heat, 2-stage cool for use with gas/electric, heat pump, electric & hydronic heat
•
3 Security Levels with setpoint limiting.
•
Factory preset to security level "2". 0nly start and temperature buttons adjustable.
•
Can average up to 8 (wired or wireless) remote sensors
•
Control to, or monitor a second remote sensor
•
3 configurable outputs for maximum flexibility (MISC1, MISC2, MISC3)
•
Smart Fan (keeps the fan from running during unoccupied periods)
•
Display shows both heating an cooling setpoints and room temperature simultaneously
•
All programming and setpoints stored in non-volatile memory, and are never lost in power failure
•
Service filter and service UV lamp indicators
•
Red/Green LED shows whether thermostat is calling for heating or cooling
•
Thermoglow backlit electro-luminous display and backlit color coded keys and legends
•
Holiday programming (up to 99 days).
•
Adjustable unoccupied override timer, adjustable in 15 min. increments, up to 6 hours.
•
Morning warm-up feature - automatically heats or cools the room in the morning before occupancy.
•
On board dry contact closure available to force stat into occupied operation.
•
Accepts humidification/dehumidification control module (Venstar part number ACC0430)
•
Accepts accessory EZ Programmer (Venstar part number ACC0432)
•
For accessory locking cover use (Venstar part number ACC0620)
MODEL: T2900SCH
JOB NAME:
LOCATION:
BUYER:
ENGINEER:
Venstar School Thermostat
T2900SCH
QUANTITY: DATE:
BUYER P.O.#:
