Summary of Contents for Toyota FJ CRUISER 2009
- Page 2 Owner’s Manual and supplementary manuals so you will have a better understanding of your vehicle’s capabilities and limitations. Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new FJ Cruiser.
-
Page 3: Table Of Contents
VSC OFF button Windows Windshield wipers & washers Door locks SAFETY AND Seat belts Seat belts-Shoulder belt anchor EMERGENCY FEATURES Spare tire & tools Tire Pressure Monitoring (warning) System Visit your Toyota dealer for information on this and other customizable options. -
Page 4: Instrument Panel
OVERVIEW Instrument panel Steering wheel controls (if equipped) Instrument panel light control Rear differential lock button* Power rearview mirror controls* Active traction control switch* Clutch start cancel switch* Sub woofer ON-OFF button* Roll Sensing of Curtain shield Airbag OFF switch Power outlet Tilt steering lock release AUX audio jack... -
Page 5: Instrument Cluster
OVERVIEW Instrument cluster Airbag SRS warning Automatic Transmission fluid temperature warning Unengaged Park warning Low Tire Pressure Warning Engine immobilizer system indicator Front passenger occupant classification indicator Headlight high beam indicator Turn signal indicator Tachometer Automatic Transmission indicator Service indicators and reminder Speedometer Voltmeter Automatic Transmission indicator... -
Page 6: Fuel Tank Door Release And Cap
OVERVIEW Fuel tank door release and cap Hood release Pull up latch and raise hood NOTE: Tighten Turn until one click is heard. If the cap is Pull Pull not tightened enough, Check Engine “ ” indicator may illuminate. Engine maintenance Keyless entry (if equipped) Beep sound can be switched ON or OFF by customer. -
Page 7: Tilt Steering Wheel
FEATURES/OPERATIONS Automatic Transmission (if equipped) Four-wheel drive (if equipped) Part-time four-wheel drive models Park* Reverse Neutral Drive Fourth gear Third gear High speed (2WD) High speed (4WD) Second gear Shift to “H4” with speed below 50 mph. First gear Low speed (4WD) Stop vehicle, shift to “N”... -
Page 8: Parking Brake
FEATURES/OPERATIONS Parking brake Seats-Folding rear seats Release (2) Push (4) Pull up (1) Pull slightly Pull (1) Push (3) Lower (2) Remove (5) Push down Seat adjustments-Front (3) Stow (6) Fold-down Seats-Removing rear seats (2) Loosen (1) Pull up Seat position (forward/backward) Cushion angle (driver side only) Height crank (driver side only) Seatback angle... -
Page 9: Windshield Wipers & Washers
FEATURES/OPERATIONS Lights & turn signals Windows Headlights Driver side Windows lock switch Low beam Headlights High beam flasher Down Parking lights High beam Automatic down operation (driver side only) Push the switch completely -Automatic light cutoff system Automatically turns lights off after 30 down and release to fully open. - Page 10 FEATURES/OPERATIONS Audio RADIO Preset buttons Tune in the desired station and press a preset button (1-6) Type 1 until you hear a beep. Push desired preset button (1-6) to select. “SCAN” Push and hold “SCAN” to scan preset stations. Push again to hold Eject CD Preset buttons-functions in other selection.
-
Page 11: Air Conditioning/Heating
FEATURES/OPERATIONS Air Conditioning/Heating Cruise control (if equipped) Turning system ON/OFF Functions Resume /Increase Cancel speed System ON/OFF Set/Decrease speed The set speed may also be cancelled by depressing the brake pedal. The set speed may be resumed once vehicle speed exceeds 25 mph. Intuitive parking assist (if equipped) Fresh or recirculated cabin air Air Conditioning ON/OFF... -
Page 12: Vsc Off Button
FEATURES/OPERATIONS VSC OFF button Bottle holders-Rear seat VSC OFF button Cup holders The VSC OFF button is used to switch between modes related to the TRAC, VSC and Auto LSD functions. Automatic Manual Transmission models Transmission models Refer to Section 2-4 of the Owner’s Manual for more information. Power outlet-12V DC Instrument panel Rear console... -
Page 13: Seat Belts
SAFETY AND EMERGENCY FEATURES Seat belts Take up slack Too high Keep as low on hips as possible If belt is fully extended, then retracted even slightly, it cannot be re-extended beyond that point, unless fully retracted again. This feature is used to help hold child restraint systems securely. -
Page 14: Spare Tire & Tools
Correctly adjusting tire inflation will turn off the light after a few minutes. If the light does not turn off, have the system checked by your Toyota dealer. Refer to the Owner’s Manual for more details. - Page 15 MN 00505-QRG09-FJC Printed in the USA 7/08...
