  • Page 1: Quick Start Guide

    ™ Dolphin 6000 Quick Start Guide Aller à www.honeywellaidc.com pour le français. Vai a www.honeywellaidc.com per l'italiano. Für Deutsch gehe zu www.honeywellaidc.com. Ir a www.honeywellaidc.com para español. Para Português, acesse www.honeywellaidc.com.br. Перейти на русскоязычный сайт www.honeywellaidc.com. Pro češtinu jdi na www.honeywellaidc.com. Pre slovenčinu choď...
  • Page 2 Out of the Box Verify that your carton contains the following items: • Dolphin 6000 mobile terminal • Main battery pack (3.7V, Li-ion) • AC power supply • Quick Start Guide Note: If you ordered accessories for your terminal, verify that they are also included with the order.

  • Page 3: Front Panel

    Front Panel Indicator LED Front Speaker Volume Control Touch Panel Buttons Display Picture/Video Button Navigation Keys SCAN Key Orange FN Key Blue FN Key BKSP g hi Shift pqrs wxyz Power Key SPACE Microphone I/O Connector...

  • Page 4: Back Panel

    Back Panel Laser/Scan Engine Rear Speaker Camera Flash Stylus Tether/ Lanyard Slot Color Camera SIM Card Socket Battery Door MicroSD Memory Card Socket Battery Door Latch...
  • Page 5 Keyboard 29-key Alphanumeric Keyboard BKSP g hi Shift pqrs wxyz SPACE...

  • Page 6: Installing The Battery Pack

    Mating wet components may cause dam- age not covered by the warranty. The Dolphin 6000 is shipped with the battery packaged separately from the terminal. Perform the following steps to install the battery. 1. Slide the latch to unlock the battery door.

  • Page 7: Removing The Battery Pack

    Note: Install the battery door before powering the terminal. 5. Connect the terminal to one of the Dolphin 6000 charging peripherals to charge the battery pack. We recommend use of Honeywell Li-Ion battery packs. Use of any non-Honeywell battery may result in damage not covered by the warranty.
  • Page 8 Charging the Dolphin Dolphin terminals ship with the battery significantly discharged of power. Charge the battery pack with a Dolphin charging device for a minimum of 4 hours before initial use.
  • Page 9 HomeBase AUX Battery Well AUX Battery Charge State LED HomeBase Back Panel Serial Port USB Port DC Power Jack HomeBase Battery Well LED Indicators Green Full (completed charge) Fast charge Orange Pre-charge (low battery status) Orange - Blinking Battery cannot be charged No battery, fault or over temperature...
  • Page 10 Charging/Communication Cable Power Adapter Cable Host Device COMM Cable USB Connector...

  • Page 11: Turning Device On/Off

    Turning Device On/Off To turn the Dolphin 6000 terminal on: 1. Press and hold the Power button for 3 seconds. To turn the terminal off, press the Power button for 5 seconds. 2. Tap OK to shutdown. Suspending/Resuming Terminal To put the device into Suspend mode when the terminal is powered 1.

  • Page 12: Activesync Communication

    For additional information on ActiveSync or Windows Mobile Device Center visit www.microsoft.com. We recommend use of Honeywell peripherals, power cables, and power adapters. Use of any non-Honeywell peripherals, cables, or power adapters may cause damage not covered by the warranty.

  • Page 13: Installing A Memory Card

    Installing a Memory Card Step 4 1. Power down the terminal. 2. Unlock and remove the battery door. 3. Remove the battery. 4. Slide the latch toward the top of the terminal to Step 5 unlock the SIM card. 5. Lift the SIM card latch to reveal the SIM card. 6.

  • Page 14: Installing A Sim Card

    Installing a SIM Card Step 4 1. Power down the terminal. 2. Unlock and remove the battery door. 3. Remove the battery. 4. Slide the latch toward the top of the terminal to Step 5 unlock the SIM card. 5. Lift the SIM card latch. 6.

  • Page 15: Using The Scan Engine

    Using the Scan Engine Point the aiming beam at a bar code. The aiming beam must align with the bar code for the best results. Holding the terminal between 4-10 inches (10-25 cm) from a bar code is recommended. Note: The touch panel display can be activated by using the stylus (included with the terminal) or your finger.

  • Page 16: Aiming Beam

    Aiming Beam The aiming beam is narrower when you hold the terminal closer to a bar code and the aiming beam is wider when you hold it farther from the bar code. The aiming beam must be aimed closer to symbologies that have smaller bars or elements (mil size).

  • Page 17: Technical Assistance
