Setup functions

Shaded areas below apply only to TH7220.
0120 Year
(first two digits)
0130 Year
(second two digits)
0140 Month
0150 Date
0160 Schedule format
0165 Restore energy saving
schedule
0170 System type
0180 Fan control
(heating)
0190 Changeover valve
(O/B terminal)
0200 Auxiliary heat
0210 External fossil
fuel kit
0220 1st stage com-
pressor cycle rate
0230 2nd stage com-
pressor cycle rate
Settings & Options
20 (2000-2099)
21 (2101-2178)
12 (2012)
[Other options: 00-99]
6 [Other options: 1-12]
15 [Other options: 1-31]
4 7-day programming
0 Non-programmable
0 Continue using programmed schedule.
1 Restore thermostat program to energy saving settings.
1 1 heat/1 cool conventional
2 1 heat/1 cool heat pump (no aux. heat)
3 Heat only (2-wire systems)
4 Heat only with fan
5 Hot water Series 20 system (power to open & close zone
valves/normally open zone valves)
6 Cool only
7 2 heat/1 cool heat pump (with aux. heat)
8 2 heat/2 cool multistage conventional
9 2 heat/1 cool multistage conventional
10 1 heat/2 cool multistage conventional
0 Gas/Oil heat (equipment controls heating fan)
1 Electric furnace (thermostat controls heating fan)
0 O/B terminal controls valve in cooling
1 O/B terminal controls valve in heating
0 Electric backup heat
1 Fossil fuel backup heat
1 External fossil fuel kit controls backup heat
0 Thermostat controls backup heat (outdoor sensor required)
3 Recommended for most compressors
[Other options: 1, 2, 4, 5 or 6 CPH]
3 Recommended for most compressors
[Other options: 1, 2, 4, 5 or 6 CPH]
7
(factory default in bold)
Continued on next page
