1. ON/OFF Switch: This switch turns the PRO 2000 on and off.
The switch lights up when turned to the "ON" position, providing
power to components plugged into the switched outlets. Pressing
the switch to the "OFF" position shuts off power. This switch
also acts as the reset for the PRO 2000's 15-amp thermal
breaker, which automatically cuts off power to protect connected
components from over-voltage situations.
2. Coaxial Video Monitor/Satellite Antenna Input/Output:
Allows you to hook up a video monitor or satellite antenna,
and protect your system against power surges coming from them.
3. GROUND OK Indicator: Indicates the wall outlet
that the PRO 2000 is plugged into is properly grounded.
4. PROTECTION ON Indicator: Indicates the PRO 2000's
internal surge protection is active.
2
Top View
1
11
3
4
5
6
®
INTRODUCTION
Thank you for purchasing Monster's PRO2000 PowerCenter.
The PRO2000 proudly reflects Monster's unwavering commitment
to creating the ultimate performance-enhancing solutions
for professional audio applications, giving you superior component
operation, the highest audio quality, and the best protection
for your precious equipment and instruments.
Ideal for high quality performance environments and studios,
the PRO2000's patented Clean Power
Stage 2 filter circuitry virtually
eliminates the noise that goes right through typical surge protectors.
Two isolated filters, optimized for analog and digital equipment,
provide excellent AC power line noise rejection and isolation
of analog gear from digital components for improved component-
generated noise rejection, leaving you with more natural tone, increased
dynamic range and none of the "dirty" AC-induced gremlins that would
otherwise interfere with the way you and your gear perform. Four high
current filtered outlets provide power-hungry amplifiers with the current
they need to operate with maximum headroom, the best transient
response and the clearest tone.
The PRO2000 is equipped with Monster's fast-acting, high-capacity
2775 Joule, Multiple SurgeGuard
and Dual-Mode Plus Protection
Circuitry, which instantly detects any voltage surge or spike,
POWERCENTER PRO2000 FEATURES
5. WIRING FAULT Indicator: Indicates that a wall outlet
is incorrectly wired.
6. Telephone/Network Input/Output: Allows you to hook
up to telephone lines (RJ11) or networks (RJ45), and protect
your system against power surges coming from them.
7. High Current Filtered Outlets: These outlets are intended
for power-hungry devices like amplifiers and powered monitors
that require high amounts of current for optimal performance.
8. Analog Filtered Outlets: These outlets have a special filter
circuit that reduces audible noise in your analog musical
and professional audio components.
9
8
14
7
8
PRO2000
PowerCenter
Professional
TM
immediately suppresses it before it can reach your gear, and will emit
an audible alarm to let you know that surge suppression occurred.
Plus, the PRO2000 has a pair of coaxial connectors and a pair
of telephone/network connectors, so you can hook up a computer,
a video monitor or a satellite receiver with the confidence that
you've got total equipment protection. Another Monster breakthrough
is the PRO2000's ultra low loss RF protection, which, unlike other surge
protectors, provides complete protection with virtually no signal loss.
The PRO2000's two separate digital LED meters ("Voltage Availability,"
"Current Draw") and three indicator LEDs ("Protection On," "Ground
OK,"and "Wiring Fault") report the status of the power coming from
your wall outlet and alert you if there are problems. All of the PRO2000's
12 switched AC power outlets are widely spaced to accommodate bulky
"wall wart" adapters, and the unit's illuminated power switch also serves
double duty as a 15-amp thermal breaker, providing a convenient reset
for those instances where the PRO2000 automatically cuts off power
to protect your gear.
9. Digital Filtered Outlets: These outlets have a special filter
circuit that reduces audible interference in your digital musical
and professional audio components.
10. Current and Voltage Availability LED Meters:
These digital meters provide constant status regarding
the quality and stability of the power coming from
the wall outlet to your PRO 2000.
11. Extra heavy duty, 10ft. shielded power cord: This power
cord's extra length enables flexible placement of the PRO 2000
to reach inconveniently located wall outlets. The cord's rugged
heavy duty, shielded construction protects it from damage
while also rejecting RF interference. The cord can be conveniently
wrapped around the unit's end caps for easy storage.
Top View
13
11
10
With its aluminum extruded exterior and rubberized finish,
the PRO2000 is rugged, road-ready and built to deliver clean, safe
power no matter where your music takes you. You'll really appreciate
its 10-ft long, extra heavy duty, shielded power cord—it's length lets
you place the PRO2000 wherever shared power is needed most,
and the cord can be conveniently wound around the unit's end caps
for trip- and tangle-free portability.
The driving force behind the success of the PRO 2000 and the entire Monster Power family is Noel Lee, The Head Monster.
Noel is best known for popularizing the concept of high performance audio cable over 20 years ago with his creation
of Monster Cable. Originally a laser-fusion design engineer at Lawrence Livermore National Laboratory and later a touring
musician, Noel has invented or co-invented over 125 U.S. and international patents and drives the explosive growth
of The Monster Group into more than 80 countries worldwide. Monster Power is his realization of a long-nurtured vision
of making affordable power solutions that deliver the best possible sound and picture.
12. Gold-plated, three-prong plug: This plug features
24k gold-plated contacts for maximum power transfer.
It can be snapped onto the power cord.
13. Rubberized ABS-Plastic End Caps: These end caps
enhance the PRO 2000's durable chassis. The unit's power
cord can be wound around the end caps.
14. Aluminum Extruded Exterior: This rugged chassis provides
an high level of protection and stability when used in its intended
operational environment.
2
1
9
3
4
5
7
6
165023
rm
companies.
respective
their
of
trademarks
be
may
names
product
and
company
other
States
United
the
in
subsidiaries
its
or
Inc.,
Products,
Cable
Monster
of
trademarks
are
SurgeGuard"
"POWERCENTER"
Power"
"Monster
"Monster"
reserved.
rights
All
Inc.
Products,
Cable
2000
PRO
POWERCENTER
PROFESSIONAL
monsterpower.com
at
web
the
on
us
Visit
89128
NV
Vegas
Las
Floor
3rd
West,
Blvd
Mead
Lake
LLC.
Monster,
INTRODUCTION
The three-prong plug, which features 24 karat gold-plated contacts
for maximum, instantaneous power transfer, can be snapped onto
the power cord when you're ready to pick up and go.
Clean power, clean sound, complete protection and total
convenience for all professional audio applications. Just like you expect
in a Monster Power product . . . because you get more of everything
from the Monster.
About Noel Lee, The Head Monster
8
14
13
10
8
All
countries.
other
and
"Multiple
Power"and
"Pre
Monster
©2003
Copyright
7251
The Head Monster

Advertisement

loading

Summary of Contents for Monster POWERCENTER PRO2000

  • Page 1 12 switched AC power outlets are widely spaced to accommodate bulky The driving force behind the success of the PRO 2000 and the entire Monster Power family is Noel Lee, The Head Monster. dynamic range and none of the “dirty” AC-induced gremlins that would “wall wart”...
  • Page 2: Troubleshooting

    • Press the PRO 2000 switch into the “ON” position. Possible Solutions Do not operate your Monster POWERCENTER if liquid of any kind is spilled onto or inside WARNING – GROUNDING AND POLARIZATION • Make sure the PRO 2000’s AC power plug is plugged into a properly •...
