Fisher-Price SMARTCYCLE RACER T3857 Owner's Manual page 6

Seat
7
• At an angle, fi t the upper tabs on the front
of the seat into the slots on the seat post.
• Lower the seat to fi t the bottom tabs on
the seat into the slots on the seat post.
You should hear a "click".
• Push down on the seat to be sure it
is secure.
6
Assembly
8
• For your child's comfort, the seat can
be adjusted to any of three seat heights
(upper slots for shorter children and lower
slots for taller children).
• To remove the seat, press the tabs
underneath and lift.
• Replace the seat at the desired height and
push down on the seat to be sure it is
secure in the slots in the seat post.
Seat Height 3
(Shortest)
Seat Height 2
Seat Height 1
(Tallest)
