Product features and decoration may vary from the picture above.
Super Talk!
™
BARBIE
™
Sun Jammer
™
4x4
Owner's Manual
with Assembly Instructions
Please read this manual and save it with your original sales receipt.
For Model 76960
Tools needed for assembly: Phillips Screwdriver, Hammer, and Safety Scissors (tools not included).
Use only with Power Wheels
®
12 Volt Lead-acid Rechargeable Battery and Power Wheels
®
12 Volt Charger
with Type "12V" Connector (included).
Requires three size "AAA" (LR03) alkaline batteries (not included) for the phone.
Advertisement
Table of Contents
Related Manuals for Fisher-Price SUPER TALK! 76960
Summary of Contents for Fisher-Price SUPER TALK! 76960
- Page 1 Product features and decoration may vary from the picture above. Super Talk! ™ BARBIE ™ Sun Jammer ™ Owner’s Manual with Assembly Instructions Please read this manual and save it with your original sales receipt. For Model 76960 Tools needed for assembly: Phillips Screwdriver, Hammer, and Safety Scissors (tools not included). Use only with Power Wheels ®...
-
Page 2: Table Of Contents
Important Information ..............2 Warnings . -
Page 3: Warnings
• Children can be harmed by small parts, sharp edges and sharp points in the vehicle’s unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle. -
Page 4: Parts
• If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. - Page 5 Parts #10 x 3" Screw – 2 Dashboard Knob – 2 Hood Latch – 2 " x " Machine Screw - 2 #6 x 1 " Screw – 4 Key Assembly #8 x 1" Screw – 11 #10 x 1" Screw – 2 Knob Plate #10 x "...
-
Page 6: Parts Diagram
Parts Diagram... - Page 7 Part Vehicle Body Steering Column .354 Cap Nut Hood Latch 12 Volt Battery Battery Retainer Key Chain Taillight Lens Taillight Housing #8 x 1" Screw Gas Cap Dash #10 x 1" Screw #10 x " Screw #10 x 3" Screw Knob Plate Dashboard Knob Phone...
-
Page 8: Battery Charging
WARNING • The battery must be handled by adults only. The battery is heavy and contains sulfuric acid (electrolyte). Dropping the battery could result in serious injury. • Never allow children to charge the battery. Battery charging must be done by adults only. - Page 9 Important Notes • Your new battery must be charged for at least 18 hours before you use it in your vehicle for the first time. • You do not need to remove the battery from your vehicle to recharge it. •...
-
Page 10: Assembly
Do not omit any steps. Please set aside at least 60 minutes for assembly. Dash • Position the dash on the vehicle body. Make sure the holes in the dash tabs align with the holes in the vehicle body and that the channel cover is captured by the dash. •... - Page 11 Dash Key Assembly Phone Cord Helpful Hint! It is easiest to apply the decorative labels to the dash before assembling the steering wheel. See page 17 for label placement instructions. • Bend the end of the phone cord so that it forms a “T”. •...
- Page 12 Steering Wheel • Fit the steering wheel cap into the center of the steering wheel with the screw holes aligned. • Insert two #8 x 1" screws as shown. • Tighten the screws with a Phillips screwdriver. Do not over-tighten. Wide Tab Lens Guard •...
- Page 13 Hood Tabs Slot • Position the hood over the front of the vehicle body as shown. • Insert the tabs on the hood into the slots in the vehicle body. • Close the hood. #8 x 1" Screws Windshield Brackets •...
- Page 14 Long Seat Belt Strap T-Loop Fastener End • Insert each fastener end of the long seat belt strap through a slot in the center of the seat. Make sure the fasteners face the outer edge of the seat. • Pull each side of the long seat belt strap evenly through the slots.
- Page 15 Sport Bar • Extend the canopy completely around the sport bar. Sport Bar Bracket Ring Tunnel Sport Bar Support • Using safety scissors, remove the sport bar brackets from the plastic connector. Dispose of the plastic connector. • Position the sport bar upright. •...
- Page 16 • Align the tabs on the inside of a light cover with the slots in one of the light housings on the light rack. Make sure the light covers are positioned with the wide spaced tabs towards the top. • Push firmly on the light cover to snap it to the light housing.
-
Page 17: Label Decoration
Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. •... - Page 18 Back View Right Side View Label Decoration • After applying the labels as shown in illustrations 1, 2, 3 and 4, apply labels as shown in illustrations 5, 6 and 7 to add sparkle to your vehicle. One-time assembly is now complete. IMPORTANT NOTES: •...
-
Page 19: Battery Installation
Important Note: Use only a Power Wheels Use of any other battery will damage your vehicle. Make sure that you charge the battery for at least 18 hours using the enclosed Power Wheels ® 12 volt charger before operating your vehicle for the first time. Charge the battery for at least 14 hours after each use of the vehicle. -
Page 20: Battery Care And Disposal
Battery Installation Hood Hood Latch • Lower the hood. • Lift the hood latches and fit the latch pegs onto the hood to close it. Battery Care and Disposal Disposal • Your Power Wheels ® battery is a sealed lead-acid battery. -
Page 21: Rules For Safe Driving
WARNING • Adult supervision is required. Children do not have the judgement necessary to avoid many accidents. Be sure that children operating this vehicle can do so safely and that they are supervised at all times. • Never use near steps, driveways, steep inclines, roadways, alleys, swimming pool areas or other bodies of water. -
Page 22: How To Operate Your Vehicle
Beginner Use - Low Speed Drive As assembled, your vehicle is ready to roll in low speed mph, maximum). It has been pre-set so it will only operate in low speed. After your child has mastered the basic skills of driving and understands the rules for safe driving, it’s time to remove the high speed lock-out screw to allow the vehicle to operate in low or high speed. -
Page 23: Caring For Your Vehicle
How to Operate Your Vehicle Advanced Use - High Speed Drive Disconnecting the High Speed Lock-Out Shifter Lock-Out Screw • Before you disconnect the high speed lock-out, make sure your child knows how to steer, how to start and stop the vehicle and knows the rules for safe driving. When the high speed lock-out is disconnected, the vehicle can be driven forward in low speed (2 maximum) or high speed (5 mph, maximum). -
Page 24: Problems And Solutions Guide
Problems and Solutions Guide IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels free at 1-800-348-0751 between 8 AM and 5 PM (EST) Monday through Friday. Or, contact your local Power Wheels authorized service center. - Page 25 Problems and Solutions Guide Problem Vehicle was running but Loose wire or loose connectors suddenly stopped Tripped thermal fuse Short run time (Less than Undercharged battery 1 - 3 hours per charge) Overcharged battery Battery is old and will not accept full charge Tripped thermal fuse Possible Cause...
- Page 26 Problems and Solutions Guide Problem Vehicle runs sluggishly Undercharged battery Battery needs charging Battery is old and will not accept full charge Vehicle is overloaded Driving conditions are too stressful Vehicle runs in low speed, but High speed lock-out not disconnected does not run in high speed (Please Note: The vehicle is designed to operate in low...
- Page 27 Problems and Solutions Guide Problem When the foot pedal is pressed, Loose wire or connector the vehicle won’t run without a push “Dead Spot” on motor Loud clacking or grinding Broken gears noise from a motor-gearbox Charger gets warm during use It is normal for some chargers to get warm during use and is not reason for concern.
-
Page 28: Limited Warranty
Bumper-to-Bumper* Limited Warranty *One year limited warranty from the date of purchase on the Power Wheels Six month limited warranty on the 12 volt battery. For the original purchaser, this one year limited warranty covers the Power Wheels ® ride-on vehicle (purchased from Power Wheels ®... - Page 29 DELAWARE SELBYVILLE - Ahern & Son, Inc., #2 S. Dupont Hwy Rt. 2, 19975, (302) 436-4100 WILMINGTON - Lyons Hardware Do-It Center, 2021 Kirkwood Highway, 19805, (302) 995-1260 MEXICO - S.E.G.E.S.A., Calz De Tlalpan 1172-A, CP3540 FLORIDA ATLANTIC BEACH - First Coast Repair, 25 Seminole Road, 32233, (904) 246-4616 CAPE CORAL - Family Hardware #0827 Do-It Express, 33904, (941) 542-6365...
- Page 30 MICHIGAN ALMONT - Almont Do It Center #421, 4545 Van Dyke, 48003, (810) 798-8922 BAY CITY - Bay Vac & Pedal, 805 Columbus Ave., 48708, (517) 892-7516 BRIGHTON - Complete Battery Source, 8023 W. Grand River, 48116, (810) 220-1050 DAVISON - Gill-Roy’s Hardware, 8405 East Davison, 48423, (810) 653-2288 DEARBORN - McNichols Electric Service, 1836 Grindley Park, 48124, (313) 563-7550...
- Page 31 OKLAHOMA MC ALESTER - Quality Upholstery, 803 E. Gene Stipe Blvd., 74501, (918) 423-4747 OKLAHOMA CITY - Brand Appliance Repair, Co., 538 N. Pennsylvania Avenue, 73107, (405) 235-0583 OKLAHOMA CITY - Appliance Services By CK, 101 East Madison, 73105, (405) 5258862 OKLAHOMA CITY - Oklahoma Service Center, 1940 North May Avenue, 73107, (405) 946-9841 TULSA - H.L.
- Page 32 ©DaimlerChrysler Corporation BARBIE and associated trademarks are owned by and used under license from Mattel, Inc. Fisher-Price, Power Wheels and Power Wheels by Fisher-Price are U.S. trademarks of Mattel, Inc. ©1999 Mattel, Inc. All Rights Reserved. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 Printed in the U.S.A.
