- Page 1 G Series CD Player Installation Guide...
-
Page 2: Important Safety Instructions
Important safety instructions P r e f a c e To avoid overheating • Read the instructions. • Keep these instructions. • Leave at least 10cm around the equipment to ensure sufficient • Follow all instructions. ventilation. • Do not use this apparatus near water. •... -
Page 3: Table Of Contents
i i i Contents C o n t e n t s Introduction Provides information about the CD player models, a description of each product, and technical specifications. Specifications Installing the CD player Unpacking Describes how to install the CD player and connect it to the other equipment in the system. - Page 4 Meridian Audio Ltd. Copyright © 2003-2007 Meridian Audio Ltd This guide was produced by Human-Computer Interface Ltd, Designed and manufactured in the UK by Meridian Audio Ltd. http://www.interface.co.uk/ Meridian Audio reserves the right to make changes and improvements to any of the products described in this document without prior notice.
-
Page 5: Introduction
This guide provides full information about unpacking the CD player and connecting it to the other equipment in the system. Once you have connected the product, refer to the G Series System Guide for information about operating it. G Series CD Players... - Page 6 I n t r o d u c t i o n G08.2 24-bit Upsampling CD Player In addition to the features provided by the G06.2, the G08.2 includes powerful on-board Digital Signal Processing (DSP) with the capability of an impressive 150 MIPS (million instructions per second).
-
Page 7: Specifications
I n t r o d u c t i o n Specifications G06.2 G08.2 Less than 0.003%. Less than 0.0025%. Noise Better than -99dB A weighted. Better than -100dB A weighted. Mechanism ATAPI ROM Drive. ATAPI ROM Drive. Upsampling using 150MIPS Motorola DSP56367. Convertors 192kHz capable, 24-bit, dual differential, Delta-Sigma, superb Class A analogue design. - Page 8 I n t r o d u c t i o n...
-
Page 9: Installing The Cd Player
• Meridian Comms lead. • Power cord. • This manual. • Meridian G Series System Guide . If any of these items are missing please contact your dealer. Note: You should retain the packaging in case you need to transport the unit. -
Page 10: Audio Connections
I n s t a l l i n g t h e Audio connections C D p l a y e r G06.2 24-bit CD Player Use this output To connect to this ANALOGUE OUT The analogue inputs of a preamplifier, such as the G01 Control Unit, or an integrated amplifier, such as the G51 Receiver, using analogue phono leads. - Page 11 G08 24-BIT UPSAMPLING CD PLAYER WARNING SHOCK HAZARD DO NOT OPEN NO USER SERVICEABLE PARTS INSIDE NO USER SERVICEABLE PARTS INSIDE DESIGNED AND MADE IN ENGLAND BY MERIDIAN AUDIO LTD DESIGN AND COPYRIGHT 2003 SERIAL NUMBER CLASS 1 LASER PRODUCT VOLTAGE TESTED...
- Page 12 I n s t a l l i n g t h e C D p l a y e r To connect to a digital surround controller (eg G68) G06.2/G08.2 G61R/G68 Digital Surround Controller ����� ���������� ���������� ����������� ����� ����������...
- Page 13 I n s t a l l i n g t h e C D p l a y e r To connect to a preamplifier with unbalanced inputs (eg G01/G51) G06.2 24-bit CD Player G01/G51 ANALOGUE IN ANALOGUE OUT COMMS COMMS COMMS LEAD...
-
Page 14: Communications Connections
C D p l a y e r Use this connection To connect to this DIN COMMS Other Meridian G Series or 800 Series equipment, or Meridian DSP loudspeakers. BNC COMMS Meridian components with BNC Comms connections. RS232 connection A computer, for configuring the CD player. - Page 15 Auto Note: Do not, under any circumstances, connect any equipment other than Meridian G Series or 800 Series to the socket marked COMMS on the back of the product. One unit will then be designated as the controller, and display:...
- Page 16 I n s t a l l i n g t h e C D p l a y e r...
-
Page 17: Resetting The Cd Player
R e s e t t i n g t h e C D p l a y e r Resetting the CD player This chapter explains how to reset the CD player using the front-panel controls. Resetting the product •... - Page 18 R e s e t t i n g t h e C D p l a y e r Types A description of each Type is shown on the top line of the display. As you select each Type the CD player is reset to that Type. The following table lists the available Types: When you have selected the Type you want: Type...
-
Page 19: Troubleshooting
G Series CD player with every available disc; furthermore, some discs currently on sale do not conform to the agreed format specifications. -
Page 20: Audio Problems
Tr o u b l e s h o o t i n g No lights are displayed when switching on • Check that the correct source has been selected on your • Check that the AC power supply is connected correctly. preamplifier. -
Page 21: Maintenance
• Disconnect the power cord before cleaning the unit. Before replacing a blown fuse, it is best to ascertain the cause of The exterior surfaces of Meridian G Series products are made from the failure. solid anodised aluminium, powder coated steel, thermoplastic rubber, and glass. -
Page 22: Service And Guarantee
Tr o u b l e s h o o t i n g Service Guarantee The Meridian G Series of hi-fi components has been carefully The product is guaranteed against defects in material and designed to give years of untroubled service. There are no user- workmanship for two years from the date of purchase. -
Page 23: Index
I n d e x accessories 5 mains fuse, changing 17 audio connections 6 automatic setup 11 preamplifier, connecting to 8 product, resetting 13 balanced preamplifier, connecting to 8 resetting the product 13 cleaning 17 COMMS, connecting 11 communications connections 10 safety warnings ii connections specifications 3... - Page 24 I n d e x...
