Page 1: Repair Parts
DRYER Repair Parts List MODEL NUMBER MDG2500BWW When requesting service or ordering parts, always provide the following information: - Product Type - Part Number - Model Number - Part Description ©2005 Maytag Services... - Page 2 Section: CONTROL PANEL Model: MDG2500BWW LD11-106...
-
Page 3: Control Panel
Section: CONTROL PANEL Part No. Description Series Qty Y22002339 SCREW 33002563 PANEL, CONTROL (WHT) 33001621 SKIRT, TIMER DIAL (WHT) 22001659 TIMER KNOB - GREY 22001664 TIMER KNOB INSERT/CAP (WHT) 33001619 BUTTON, PUSH TO START (WHT) 33001690 SCREW, TIMER 33001632 TIMER 33001806 BACK, CONSOLE PANEL 216423... - Page 4 Section: CABINET-FRONT Model: MDG2500BWW LD12-57...
-
Page 5: Cabinet-Front
Section: CABINET-FRONT Part No. Description Series Qty 33002631 COVER, TOP (WHT-AS PK) 33001896 COVER, TOP (WHT) 2 N 22003643 CABINET ASSY. (WHT AS PK) 2 N 33001897 CABINET (WHT) 22002643 WIRE HARNESS, MAIN 22002049 CLIP 213280 FRONT PANEL BRACKET/FASTENER 22001995 SCREW 22003298 RETAINER, WIRE... - Page 6 Section: CABINET-REAR Model: MDG2500BWW LD12-76...
-
Page 7: Cabinet-Rear
Section: CABINET-REAR Part No. Description Series Qty 1 N 33002643 CABINET ASSY. (WHT AS PK) 22001995 SCREW 1 N 33002624 CABINET, ASSY. (WHT-AS PK) 1 N 33001897 CABINET (WHT) 22003367 HINGE, PLASTIC 22001995 SCREW 33001795 COVER, TERMINAL BLOCK 22001995 SCREW 211881 GROMMET, CORD 33002494... - Page 8 Section: DOOR Model: MDG2500BWW LD17-26...
- Page 9 Section: DOOR Part No. Description Series Qty 33001767 SEAL, SHROUD 22002247 HOOK, SECURITY 33001900 SHROUD (WHT) 22001995 SCREW 33001768 SCREW, SHROUD 33001509 SWITCH, DOOR 33001760 BRACKET, HINGE 8 N 33001174 PLUG, DOOR CATCH Y304578 CATCH, DOOR (FEMALE) 33001791 CATCH, DOOR (W/PLUG) 33002094 SEAL, DOOR 22002038...
- Page 10 Section: TUMBLER Model: MDG2500BWW LD13-46...
- Page 11 Section: TUMBLER Part No. Description Series Qty 33001799 OUTLET DUCT ASSEMBLY 33001808 FILTER, LINT 33001758 SEAL, BLOWER 33002190 SCREW (#10-3/8") 22003298 RETAINER, WIRE 33001802 FRONT, TUMBLER (W/SEAL) 410233 RING, RETAINING 306508 TUMBLER BEARING KIT 210720 RIVET 216423 SCREW 210932 SCREW, #8 X 9/16 CTSK 12 N 312311 SCREW----NA 33001855...
- Page 12 Section: GAS VALVE Model: MDG2500BWW CD14-5...
-
Page 13: Gas Valve
Section: GAS VALVE Part No. Description Series Qty 306195 CONVERSION KIT (NATURAL TO LP) 306204 CONVERSION KIT (LP TO NATURAL) 304971 SCREW 304970 IGNITER ASSY, GAS VALVE 33001247 BURNER ASSY. 306176 VALVE, GAS 306106 COIL, HOLDING & BOOSTER 306105 COIL, SECONDARY 9 N 313561 SCREW----NA 10 N 33001834... - Page 14 Section: MOTOR DRIVE Model: MDG2500BWW LD11-85...
-
Page 15: Motor Drive
Section: MOTOR DRIVE Part No. Description Series Qty 33001789 HOUSING, BLOWER 33001800 DUCT ASSY., EXHAUST 22001995 SCREW 410233 RING, RETAINING 33001790 WHEEL, BLOWER 312967 CLAMP, BLOWER HOUSING 33001855 SCREW (HEX HEAD) 7 N 313561 SCREW----NA 307250 THERMOSTAT, MULTI-TEMP (GAS) 216423 SCREW 33001762 FUSE, THERMAL (W' BRACKET) - Page 16 Section: WIRING INFORMATION Model: MDG2500BWW 15002735...
