Please read this manual and save it with your

Tools needed for assembly: Phillips Screwdriver, Adjustable

Wrench (or Pliers) and Safety Scissors (all not included).

Use only with a Power Wheels

Battery and Power Wheels

with Type 12V Connector (both included).

Requires four "C" (LR14) alkaline batteries

for FM Radio/Digital Clock operation (not included).

Product features may vary from the picture above.

Owner's Manual

with Assembly Instructions

For Model: K9758

For Model: K4563

original sales receipt.

12 Volt Lead Acid Rechargeable

12 Volt Charger

Table of Contents

Summary of Contents for Fisher-Price Power Wheels K9758

Page 1 Product features may vary from the picture above. Product features may vary from the picture above. Owner's Manual Owner's Manual with Assembly Instructions with Assembly Instructions For Model: K9758 For Model: K4563 12 Volt Lead Acid Rechargeable 12 Volt Lead Acid Rechargeable ® ®...
Page 2: Table Of Contents
• Use this vehicle ONLY outdoors. Most interior flooring can be damaged by riding this vehicle indoors. Fisher-Price responsible for damage to the floor if the vehicle is used indoors. • To prevent damaging the motors and gears, teach your child to stop the vehicle before switching direction.
Page 3: B Warnings And Cautions
WARNINGS AND CAUTIONS ELECTRICAL HAZARD • Battery can fall out and injure a child if vehicle tips over. Always use battery retainer. • PREVENT FIRE - N ever modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. - U se of the wrong type battery or charger could cause a fire or explosion resulting in serious injury. - U se of Power Wheels components in products other than Power Wheels ® cause overheating, fire or explosion. • T he battery must be handled by adults only. The battery is heavy and contains sulfuric acid (electrolyte). Dropping the battery could result in serious injury. • Never allow children to charge the battery. Battery charging must be done by adults only. A child could be injured by the electricity involved in charging the battery. • Read the safety instructions on the battery. • Examine the battery, charger and their connectors for excessive wear or damage each time you charge the battery. If damage or excessive wear is detected, do not use the charger or the battery until you have replaced the worn or damaged part. • HOT motors. Handle carefully. RIDING HAZARD • Prevent Injuries and Deaths • Direct Adult Supervision Required • Never Ride at Night.
Page 4: C Parts
• If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. •...
Page 5 TABLE OF CONTENTS PARTS #8 x 1" Screw – 6 12 Volt Battery 12 Volt Charger #10 x ¾" Screw – 22 Taillight Lens Set Taillight Housing Set " x 1 " Pin - 1 Spacer - 2 #8- 32 x 1.625" Screw – 2 #8 x4"...
Page 6: D Parts Picture
Note: Some parts shown are assembled on both sides of the vehicle. 1 Vehicle Steering Column Hood Latch 12 Volt Battery 12 Volt Charger Key Assembly Taillight Lens Taillight Housing Hood 10 Cap 1 1 Dash TABLE OF CONTENTS PARTS PICTURE Headlight Lens - 2 Light Cover - 2 Lens Guard - 2...
Page 7: E Battery Charging
ELECTRICAL HAZARD WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery retainer. • PREVENT FIRE - N ever modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. - U se of the wrong type battery or charger could cause a fire or explosion resulting in serious injury. - U se of Power Wheels components in ® products other than Power Wheels vehicles could cause overheating, fire or explosion. • T he battery must be handled by adults only. The battery is heavy and contains sulfuric acid (electrolyte). Dropping the battery could result in serious injury. • Never allow children to charge the battery. Battery charging must be done by adults only. A child could be injured by the elec- tricity involved in charging the battery. • Read the safety instructions on the battery. • Examine the battery, charger and their connectors for excessive wear or damage each time you charge the battery. If damage or excessive wear is detected, do not use the charger or the battery until you...
Page 8: F Assembly
BATTERY CHARGING • Plug the charger connector into the battery • Plug the charger into a standard wall outlet Notes: - If power flow to the wall outlet is controlled by a switch, make sure the switch is “ON”. - Use the charger only in a wall outlet. Do not plug the charger into a ceiling outlet.
Page 9 DASH VIEW • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. • Place the labels exactly as shown in the illustration. • For best results, avoid repositioning a label once it has been applied to the vehicle.
Page 10 " x 1 " Pin • Insert the " x 1 " pin through the hole in the end of the steering column. • Lower the steering column so that the pin fits inside the center of the steering wheel. •...
Page 11 Grille Slot FRONT VIEW • Fit a lens assembly tab into the headlight slots in the grille. • Press firmly to snap the lens assembly into the grille. • Repeat this procedure to snap the other lens assembly into the grille. Hood Latch Slot...
Page 12 Brush Guard • Fit and hold the brush guard against the front end of the vehicle. Hint: Using the end of a Phillips screwdriver, poke a hole in the thin, plastic covering over the lower holes in the brush guard. •...
Page 13 Seat Back Tabs PUSH HERE Slot SIDE VIEW • With the seat at an angle, insert the tabs on the front edge of the seat into the slots in the foot-well wall • Push down firmly on the edge of the seat above each tab to snap the tabs into the slots •...
Page 14 • Fit a support to one side of the sport bar. • Insert a #8- 32 x 1.625 " screw through the support, the sport bar and out through the support. • Fit an #8 acorn lock nut to the end of the screw. •...
Page 15 Taillight Housing Taillight Lens #8 x 1" Screws BACK VIEW • Turn the vehicle upright. • Using safety scissors, remove the taillight lenses and the taillight housings from the plastic connectors. Dispose of the plastic connectors. • Face the rear of the vehicle. •...
Page 16: Gdecoration
ASSEMBLY Compartment Door • Locate the FM Radio on the dash. • Loosen both screws in the battery compartment door. • Remove the battery compartment door. • Insert four, new "C" (LR14) alkaline batteries. Hint: We recommend using alkaline batteries for longer battery life. •...
Page 17 DECORATION FRONT LEFT SIDE FRONT RIGHT SIDE K9758pr-0920 K9758pr-0920...
Page 18: H Battery Installation
IMPORTANT! Use only a Power Wheels rechargeable battery. Use of any other battery will damage your vehicle. Make sure that you charge the battery for at least 18 hours using the enclosed Power Wheels operating your vehicle for the first time. Charge the battery for at least 14 hours after each use of the vehicle.
Page 19: I Battery Care And Disposal
BATTERY CARE AND DISPOSAL Care If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic bag. See information below for proper disposal. If acid comes in contact with skin or eyes, flush with cool water for at least 15 minutes and call a physician.
Page 20: J Safe Driving Rules
RIDING HAZARD WARNING • Prevent Injuries and Deaths • Direct Adult Supervision Required • Never Ride at Night. • K eep Children Within Safe Riding Areas. These areas must be: - away from swimming pools and other b odies of water to prevent drownings - generally level to prevent tipovers - away from steps, steep inclines, cars, roads and alleys. • Riding Rules M ake sure children know and follow these rules for safe driving and riding. - Always sit on the seat. - Always wear shoes. - Only 2 (two) riders at a time. SAFE DRIVING RULES Teach Safety Rules to Children While children can quickly develop the skill necessary to drive this vehicle, it is important to remember that their judgment skills are still very immature.
Page 21: K Vehicle Operation
IMPORTANT! Use this vehicle ONLY outdoors. Most interior floor- ing can be damaged by riding this vehicle indoors. Fisher-Price will not be responsible for damage to the floor if the vehicle is used indoors. Beginner Use - Low Speed Drive As assembled, your vehicle is ready to roll in low speed mph, maximum).
Page 22: L Fm Radio/Digital Clock Use
FM RADIO/DIGITAL CLOCK USE Volume Power Power/Volume • Press the power button to turn on or off. • Turn the volume dial to adjust to a comfortable listening level. Hint: The FM Radio will turn off automatically after about one hour of non-use. FM Radio •...
Page 23: Mvehicle Care
VEHICLE CARE • Check all screws, cap nuts and their protective coverings regularly and tighten as required. Check plastic parts on a regular basis for cracks or broken pieces. • During snowy or rainy weather, the vehicle should be stored inside or under a protective cover.
Page 24: Pproblems And Solutions Guide
PROBLEMS AND SOLUTIONS GUIDE IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels or 11 AM - 5 PM (EST) Saturday. Or, contact your local Power Wheels on-line at www.powerwheels.com, or call 1-800-348-0751.
Page 25 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE Short run time (Less than Undercharged battery 1 - 3 hours per charge) Overcharged battery Battery is old and will not accept full charge Tripped thermal fuse Vehicle runs sluggishly Undercharged battery Battery needs charging Battery is old and will not accept full charge Vehicle is overloaded Driving conditions are too stressful K9758pr-0920 SOLUTION Charge the battery. A new battery should have been charged for at least 18 hours before using the vehicle for the first time. After first- time use, recharge the battery for at least 14 hours after each use. Never charge the battery longer than 30 hours. Check all wires and connectors. Make sure the charger connector is plugged into the battery, and that the charger is plugged into the wall. Make sure power flow to the wall outlet is “ON”. Do not charge the battery longer than 30 hours. If you suspect that your battery is damaged as a result of overcharging, contact your ® local Power Wheels authorized service center. They can test your battery for you. Even with proper care, a rechargeable battery does not last forever. Average battery life is 1 to 3 years depending on vehicle use and use conditions. Replace the battery with a new Power ®...
Page 26 PROBLEMS AND SOLUTIONS GUIDE PROBLEM Vehicle runs in low speed, but does not run in high speed. Please note: The vehicle is designed to operate in low speed only in reverse. When the foot pedal is pressed one rear wheel spins Sometimes the vehicle doesn’t run, but other times it does When the go foot pedal is pressed, the vehicle won’t run without a push Battery's thermal fuse constantly "trips", but the vehicle is not overloaded nor the driving conditions too severe Loud clacking or grinding noise from a motor-gearbox Charger gets warm during use Battery makes a sizzling or gurgling noise when charging POSSIBLE CAUSE High speed lock-out not disconnected. Operation of vehicle in low speed Loose wire or connector Motor or electrical switch damage Loose wire or connector “Dead Spot” on motor Damaged battery Child is switching between FORWARD and REVERSE without stopping Broken gears It is normal for some chargers to get warm during use and is not reason for concern.
Page 27 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE FM Radio does not function at all Power is off "C" batteries are weak or dead FM Radio station Poor reception changes automatically Power was turned off and the radio reset back to the first station Digital Clock display is faint "C" batteries are weak or dead or not visible at all FM Radio is in use I still hear sounds, but the "C" batteries are weak or dead display is blank on the FM Radio/Digital Clock FM Radio/Digital Clock Electronic lock-up function erratically If, after reviewing the Problems and Solutions Guide, the vehicle still fails to operate, please contact your nearest authorized service center. K9758pr-0920 SOLUTION Power automatically turns off after about one hour of non-use.
Page 28 ©2006 Viacom International Inc. Nickelodeon, Nick Jr., Dora the Explorer and all related titles, logos and characters are trademarks of Viacom International, Inc. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©2007 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
