Owner's Manual with Assembly Instructions
For Models 77760, 77767, 77768
Please read this manual and save it with your original sales receipt.
Tools needed for assembly: Assembly tool (included)
and Phillips Screwdriver (not included). Tool needed to access battery
compartment: Slotted screwdriver (not included)
Use only with a Power Wheels
®
6 Volt (4.0 Amp/Hr.) Rechargeable
Battery with Built-in Thermal Fuse and a Power Wheels
®
6 Volt
(4.0 Amp/Hr.) Charger (both included).
Advertisement
Table of Contents
Related Manuals for Fisher-Price Power Wheels 77760
Summary of Contents for Fisher-Price Power Wheels 77760
- Page 1 Product features may vary from the Product features may vary from picture above. Owner's Manual with Assembly Instructions For Models 77760, 77767, 77768 Please read this manual and save it with your original sales receipt. Tools needed for assembly: Assembly tool (included) and Phillips Screwdriver (not included).
-
Page 2: Table Of Contents
• Use this vehicle ONLY outdoors. Most interior flooring can be damaged by riding this vehicle indoors. Fisher-Price responsible for damage to the floor if the vehicle is used indoors. • To prevent damaging the motors and gears, do not tow anything behind the vehicle or overload it. -
Page 3: B Warnings And Cautions
WARNINGS AND CAUTIONS ELECTRICAL HAZARD • Battery can fall out and injure a child if vehicle tips over. Always use battery retainer. • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. -
Page 4: Cparts
• If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. •... -
Page 5: Parts Picture
PARTS PICTURE TABLE OF CONTENTS Handlebar Assembly Seat Vehicle Front Wheel Assembly 6 Volt (4.0 Amp/Hr.) Battery Lock Nut Steering Column Cap 77760pr-0921 77760pr-0921... -
Page 6: E Battery Charging
ELECTRICAL HAZARD ELECTRICAL HAZARD WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery retainer. • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. -
Page 7: Battery Charging
IMPORTANT! The battery must be removed from your vehicle for the initial charge in order to complete assembly. After assembly is complete, you do not need to remove the battery from your vehicle to recharge it. Unlocked Seat Lock Fastener •... -
Page 8: F Assembly
WARNING Children can be harmed by small parts, sharp edges and sharp points in the vehicle's unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle. - Page 9 Assembly Tool Lock Nut Steering Column • Place the lock nut (rounded side up) on to the end of the steering column. • Tighten the lock nut firmly using the closed end of the assembly tool. Steering Column • “Snap” the steering column cap over the lock nut. 77760pr-0921 ASSEMBLY Rounded Side Up...
-
Page 10: Gdecoration
• After applying a label, rub the label firmly with a clean, dry cloth to make sure the label is adhered to your vehicle. Start at the center of a label, and smooth towards the outer edges to remove air bubbles. Model 77760 DECORATION... -
Page 11: Battery Installation
BATTERY INSTALLATION IMPORTANT! Use only a Power Wheels ® battery and built-in thermal fuse. Use of any other battery will damage your vehicle. Make sure that you charge the battery for at least 18 hours using the enclosed Power Wheels (4.0 Amp/Hr.) charger before operating your vehicle for the first time. - Page 12 Battery Connector • Plug the battery connector into the motor connector. Hint: If the battery connector will not plug into the motor connector, turn it over and try again! Do not force the battery connector into the motor connector. Seat Tab Slot Seat •...
-
Page 13: Battery Care And Disposal
BATTERY CARE AND DISPOSAL Care If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic bag. See information below for proper disposal. If acid comes in contact with skin or eyes, flush with cool water for at least 15 minutes and call a physician. -
Page 14: Safe Driving Rules
RIDING HAZARD WARNING • Prevent Injuries and Deaths • Direct Adult Supervision Required. • Never Ride At Night. • Keep Children Within Safe Riding Areas. These areas must be: - away from swimming pools and other bodies of water to prevent drownings - generally level to prevent tipovers - away from steps, steep inclines, cars, roads and alleys. -
Page 15: Kvehicle Operation
VEHICLE OPERATION IMPORTANT! Use this vehicle ONLY outdoors. Most interior floor-ing can be damaged by riding this vehicle indoors. Fisher- Price ® will not be responsible for damage to the floor if the vehicle is used indoors. Drive Forward Press •... -
Page 16: Limited Warranty
*One year limited warranty from the date of purchase on the Power Wheels For the original purchaser, this one year limited warranty covers the Power Wheels defects in materials and workmanship. The six month limited warranty applies only to the 6 volt battery included by Power Wheels original purchase of the vehicle. -
Page 17: N Problems And Solutions Guide
PROBLEMS AND SOLUTIONS GUIDE IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels ® Consumer Relations, toll-free at 1-800-348-0751 between 9 AM - 7 PM (EST) Monday through Friday and 11 AM - 5 PM (EST) Saturday. - Page 18 PROBLEMS AND SOLUTIONS GUIDE PROBLEM Vehicle was running but suddenly stopped Short run time (Less than 1 - 3 hours per charge) POSSIBLE CAUSE Loose wires or loose connectors Tripped thermal fuse Undercharged battery Overcharged battery Battery is old and will not accept full charge Tripped thermal fuse SOLUTION...
- Page 19 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE Vehicle runs sluggishly Undercharged battery Battery needs charging Battery is old and will not accept full charge Vehicle is overloaded Driving conditions are too stressful Sometimes the vehicle doesn’t Loose wire or connector run, but other times it does Motor or electrical switch damage When the button is pressed,...
- Page 20 For the location nearest you, visit us on-line at www.powerwheels.com. ©2006 Viacom International Inc. Nickelodeon, Nick Jr., Dora the Explorer and all related titles, Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. PRINTED IN MEXICO 18 hours! is not used or stored.
