T6197 Please keep this instruction sheet for future reference, as it contains important information. Adult assembly is required. Tools required for assembly: Phillips Screwdriver, Hammer and Scrap Block of Wood (not included). Requires three "AA" batteries (included). Age: 2-6 years. Weight limit: 60 lbs (27 kg).
Pedal Axle Pedal 4 Pedal Hubs and all related titles, logos and characters are trademarks of Viacom International, Inc. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A. CAUTION This product contains small parts in its unassembled state.
(Indented Side Down) Straight Axle • Slide a hubcap (peg side up) onto the straight axle. • Slide a rear wheel (indented side down) onto the straight axle. Hole Straight Axle BOTTOM VIEW • Turn the frame upside down. • Insert the straight axle through the holes in the rear of the frame.
Page 4
Pedal Hubs Pedal Axle Hole • While holding the pedal hubs on the pedal axle, insert the pedal axle through the hole in the center of the front wheel. • Push the pedal hubs into the center of the front wheel until they are fl ush with the surface of the front wheel.
Page 5
Handlebar Fork Cover Rear of Trike • Insert the fork post up through the hole in the neck of the frame. Make sure the fork is positioned so that the fork covers face the rear wheels. • Place the handlebar onto the fork post and push it down onto the frame.
Label Decoration (Place label 9 on opposite side) (Place label 3 on opposite side) (Place remaining label 1’s on opposite side of front wheel) SIDE VIEW DASH VIEW • Make sure the areas where the labels will be applied are clean and dry.
For best performance, we recommend replacing the batteries that came with this trike with three, new alkaline "AA" (LR6) batteries. Basket • Loosen and remove the two screws in the basket. Remove the basket. Basket Mount • Then, loosen and remove the four screws from the basket mount.
