SPECIFICATIONS
• IP54 dust protected & splash proof
• 2.5 mm ear phone jack: Using an earpiece with the
unit silences the unit's built-in speaker
• Built-in Electronic Compass for navigation to field
units and set/received waypoints
• A 120 x 140 transflective LCD monochrome grayscale
display – highly viewable, even in sunlight
• High sensitivity Atmel
®
built-in antenna
• Size: 59(W) x 114(H) x 30(D)mm;
2.32" (W) x 4.48" (H) x 1.18" (D)
• Weight: Approx. 115g (4.16 oz), with lithium ion battery
• Powered by a 3.7V / 1200mAH Li-Polymer battery that
is recharged via USB connection from the mic to a PC,
or 110/240 to 5 VDC, or 12 VDC to 5 VDC cigarette
lighter adapter accessory
• Long battery life: 18-20 hours with LCD backlight off
• Extended temperature operating range:
-35º to +55º C (-31º to 136º F)
• Cables available to fit most Icom 2 way radios,
including APCO 25 (P25) models
• May be powered by the Icom radio itself
MORE FEATURES
• Locate, poll and set a course, and navigate to a field unit
• See tracks made by other field units in relation to your position,
and set a course
• Set, store, and receive waypoints, send waypoints, set a course
to a waypoint
• Download all tracks from the unit via USB cable should you need
to transfer data to a PC
• Access GIS information for all users on the same radio channel
that are in the same group
• Set a course to a remote user, once in motion calculate the
estimated time of arrival and distance to be travelled
• Poll a unit: If a field unit has not been heard from, send a
command to receive and update the info
GPS receiver chip set with
RedHawk SA
GPS Speaker Mic With LCD Display
SOFTWARE
• Maptech Navigator Pro with
Terrain navigator Pro Team
Tracker Upgrade (for US only)
• ESRI ARC RedHawk SA Upgrade
COMES WITH
Battery
USB Cable
Quick Operators Guide
CD Operation Manual
WARRANTY
1-Year
Land Mobile: Product Catalog
Radio sold separately
24
