FIRST MADE FOR
MATERIAL OR MODEL
DIMENSION OR MAKER
COLOR
NOTE
APPROVALS
N.Yamazaki
2005/Dec/09
CHECK
Tai C S
2005/Dec/08
DESIGN
Tai C S
2005/Nov/08
DRAWN
REMARKS:
INSTRUCTION MANUAL
Andy P
28/Feb/08
Andy P
8/June/06
K. Fujinaka
18/Dec/05
APPROVALS
SAMS ONLY
SA-56P
*PAPER-JO
WOODFREE 80gm
BLACK Print
A4 SIZE
1.) Change warranty card (Back)
TAI C S
C
28/Feb/08
1.) Content change : Cover Pg & Pg
TAI C S
B
5/June/06
1.)Text change : Cover Pg & Contents Pg
TAI C S
A
2.)Additional last 2 Pages: Warranty Card
15/Dec/05
DATE
PART CODE
851-6-4119-752-00-0
PART NAME
EXPLANATORY BOOKLET
REVISIONS
3
2
1
R.NO

Advertisement

Table of Contents
loading

Related Manuals for Sanyo SA-56P

Summary of Contents for Sanyo SA-56P

  • Page 1 INSTRUCTION MANUAL FIRST MADE FOR SA-56P MATERIAL OR MODEL *PAPER-JO DIMENSION OR MAKER WOODFREE 80gm COLOR BLACK Print NOTE A4 SIZE APPROVALS N.Yamazaki 2005/Dec/09 CHECK Tai C S 2005/Dec/08 1.) Change warranty card (Back) Andy P TAI C S 28/Feb/08...

  • Page 2: Room Air Conditioner

    INSTRUCTION MANUAL ( With Warranty Card ) Cooling only Model SA-56P Room Air Conditioner Save These Instructions! 85164119752003 © S ANYO 2005 SANYO Electric Co., Ltd. P ub. OI-...

  • Page 4: Table Of Contents

    Thank you for choosing SANYO air conditioner. Our design is based on the best efficiency and the lowest noise operation and it can keep the room comfortable. Please read this Instruction Manual carefully before operating the unit and keep it for consultation. If you still have any difficulties or problems, consult your dealer for help.

  • Page 5: Function And Working Temperature Range

    Function and working temperature range Introduction Window type room air conditioners of SANYO can regulate the room temperature,dry the room. It is convenient for your work,study and life. It can be widely used in residence, shop, hotel, office, library and laboratory, and so on.

  • Page 6: Technical Specifications

    Technical specifications SA-56P Model Function Cooling Power supply 230 V~ 60Hz Cooling capacity (KJ/h) 6, 00 Power input (kW) Current Refrigerant R22 E.E.R (KJ/Wh) 10.3 Noise Indoor 54 / 50 (Hi / Low) (Cooling) (Hi / Low) Outdoor 62 / 58...

  • Page 7: Operating Condition

    Operating condition Please operate air conditioner in correct conditions as following: Cool mode operation 1. Outdoor temperature should be in range of 19 to 43 . Otherwise it is possible for air conditioner to breakdown. 2. Room temperature should be in the range of 19 to 32 .

  • Page 8: Installation

    Installation Installation precaution: Window type conditioner is so valuable and the improper installation of it will cause a lot of damage! Please associate the professional techni- cian to install the unit and don’ t install it by yourself. Otherwise, we are not responsible for the damage like this. Before installation, check that the voltage of the electric supply in your home or office is the same as the voltage shown on the name plate.

  • Page 9: Installation Procedure

    Installation procedure: 1) Remove the sticker from the front panel. 2) Put the unit into the installation hole. Horizontal line When installing the unit, it should be slanted down to the back to avoid the enlargement of noise or vibration. (Slant between 6-10mm.) (Shown at right figure.) The installation place should be strong enough to avoid the enlargement of noise or vibration.

  • Page 10: Notes For Installation

    Notes for installation Remove Before removing air conditioner to the other place, you should contact the seller firstly. Then it must be done under the direction of the professional technician. In addition, the charge of this must be paid. Noise Install in a location where is firm enough to avoid the enlargement of noise and vibration.

  • Page 11: Part Identification

    Part identification 1.) Front Panel 2.) Air louvers 3.) Air conditioner tabs 4.) Control Panel 5.) Slide-out filter...

  • Page 12: Air Conditioner Operation

    Air conditioner operation Operating your air conditioner properly helps you to obtain the best possible results. This section explains proper air conditioner operation. IMPORTANT: * If you turn the air conditioner off, wait at least 3 minutes before turning it back on. This prevents the air conditioner from blowing a fuse or tripping a circuit breaker.
  • Page 13 Air conditioner operation - (continued) CHANGING AIR DIRECTION The louvers in the top of the front panel allow you to control the direction of the cooled air. Use the tabs to direct the air right or left (some models). Rotate the whole catridge to direct air up, down or straight ahead.

  • Page 14: Operation Tips

    Operation tips Operation for comfort and economy Do not overcool the room Adjust the vertical and Keep blind or curtains closed, temperature, this is not good for horizontal airflow direction to Do not let sunshine enter the room directly when the air health and waste electricity.

  • Page 15: Caution

    Caution 1) T he plug must be accessible after the appliance is positioned. 2) Do not use this appliance in the laundry. 3) If the power cord is damaged, it must be replaced by the manufacture or its service agent in avoid of hazard. Do not use the air conditioner Do not pull out the power cord.

  • Page 16: Care And Maintenance

    Care and maintenance Always turn off the air conditioner and main power supply before cleaning to ensure safety. Clean unit Air filter 1. Plug out first before cleaning. The air filter behind the intake grille should be washed at least every two weeks or as often as it needs cleaning. Plug out only after air conditioner How to clean the air filter:...

  • Page 17: When Trouble Shooting

    When trouble shooting If your air conditioner does not work properly, first check th e following items before for servicing, it help to save your time and money. If it still does not work properly, then only contact your dealer or service center. Fault phenomenon Trouble-shooting * Is power fail?
  • Page 18 Immediately stop all operations and plug out, contact with your dealer in the following situations. * Electrical lines are much hot or lines cover * Operation starts or stops abnormally; breaks; * Power fuse or switch often breaks; * Other strange situations. * Carelessly splash water or something into air conditioner;...

  • Page 20: Warranty Card

    Branch Product Warranty Certificate This quality SANYO product is guaranteed for one (1) year from the date of purchase of original buyer against defect in manufacture or material. The compressor is guaranteed for five (5) years while refrigerant and other consumable items are not covered by this warranty after one (1) year from the date of original purchase.
  • Page 21 SANYO Service Corporation's authorized technicians. 4. This Warranty is valid only on the product purchased and used in the Philippines.
