- Page 1 Assembly Guide CW-119...
-
Page 3: Important Safety Instructions
You can find the serial number printed on a label you skip ahead, you may learn later that you have affixed to the CW-119. For future reference, write the to disassemble components and that you may serial number in the space provided below. -
Page 4: Table Of Contents
CW-119 Assembly Guide Table of Contents Important Safety Instructions .................. 3 Obtaining Service ............................. 3 Preparations ....................... 5 Unpacking the Equipment ......................... 5 Required Tools ............................5 Installation Requirements ......................... 5 Hardware Kit ............................. 6 Assembly Instructions ....................7 Open the Box ............................7 Assemble the Unit ............................. -
Page 5: Preparations
❏ Wire cutter or utility knife ❏ SAE hex key set Preparations Installation Requirements The CW-119 parts are inspected before shipment. Each unit contains several pieces that require Follow these installation requirements when assembly. You must obtain adult assistance during the assembling the unit: assembly process. -
Page 6: Hardware Kit
CW-119 Assembly Guide Hardware Kit Fastener -inch x ¾-inch buttonhead screw (A) -inch split washer (B) -inch x 1¼-inch buttonhead screw (C) -inch split washer (D) -inch washer (E) Preparations, continued page 6... -
Page 7: Assembly Instructions
CW-119 Assembly Guide Assembly Instructions Assembly of the CW-119 takes about 45 minutes to complete. If this is the first time you have assembled this type of equipment, plan on allowing more time. Be careful to open boxes and assemble components in the sequence presented in this manual. -
Page 8: Assemble The Unit
CW-119 Assembly Guide Assemble the Unit Attach the Main Frame to the Stabilizer using four -inch X ¾-inch buttonhead screws (A) four -inch split washers (B) Wrench tighten. Note: Make sure the wheels on the Stabilizer are positioned as shown in the illustration. -
Page 9: Assemble The Pads
1¼-inch buttonhead screws (C) four -inch split washers (D) four -inch washers (E) Wrench tighten. This completes the assembly of the CW-119. 3 - 1¼" buttonhead screws 3 - split washers 3 - washers 4 - 1¼" buttonhead screws 4 - split washers... -
Page 10: Clean The Pads And Assembly
Frequently vacuum the floor underneath the CW-119 to prevent the accumulation of dust and dirt. If necessary, use the Seat Pad to lift the front end and tip the CW-119 onto its wheels to roll it to a different location. Clean the Pads and Assembly page 10... -
Page 11: Limited Warranty Statement
PRECOR may require the Customer to Purchasers of PRECOR strength equipment have the right to bring an action at law or in equity affirm that he is the original owner of the equipment before providing warranty services. This to resolve disputes concerning or to enforce the provisions of this warranty. - Page 12 CW-119 Assembly Guide Notes: page 12...
-
Page 14: Specifications
Any party contemplating the use of CW-119 Assembly Guide CW33677-102 Precor’s product designs is hereby forewarned that Precor considers the unauthorized appropriation of its proprietary rights to be a Limited Warranty Statement CW31973-102 very serious matter.
