IMPORTANT MANUAL
REPAIR PART'S MANUAL
MODEL:
PB195H42LT
LAWN TRACTOR
ALWAYS WEAR EYE PROTECTION DURING OPERATION
Visit our website: www.poulan-pro.com
532 43 84-94
Do Not Throw Away
WARNING:
Read this Man u al and follow all Warnings
and Safety Instructions. Failure to do so
can re sult in serious injury.
Advertisement
Table of Contents
Related Manuals for Poulan Pro Pro PB195H42LT
Summary of Contents for Poulan Pro Pro PB195H42LT
- Page 1 WARNING: Read this Man u al and follow all Warnings MODEL: and Safety Instructions. Failure to do so can re sult in serious injury. PB195H42LT LAWN TRACTOR ALWAYS WEAR EYE PROTECTION DURING OPERATION Visit our website: www.poulan-pro.com 532 43 84-94...
-
Page 2: Table Of Contents
HOW TO USE THIS MANUAL This manual is designed to provide the customer with a means to identify the parts on his/her tractor when ordering repair parts. The illustrations may or may not represent the actual assemblies; therefore, it is not recommended to use this manual as a guide to assemble or disassemble the tractor. Some hardware and parts are drawn larger in order to more readily identify them. -
Page 3: Schematic
TRACTOR - - MODEL NUMBER PB195H42LT (96042012300), PRODUCT NO. 960 42 01-23 SCHEMATIC SCH11 BATTERY SOLENOID STARTER FUSE AMMETER BLACK (OPTIONAL) WHITE WHITE ATTACHMENT CLUTCH (CLUTCH OFF) BLACK CLUTCH/BRAKE GRAY (PEDAL UP) REVERSE SWITCH BLACK (NOT IN REVERSE) BLACK BLACK BLACK BLACK SEAT SWITCH... -
Page 4: Electrical
TRACTOR - - MODEL NUMBER PB195H42LT (96042012300), PRODUCT NO. 960 42 01-23 ELECTRICAL T02S With 12V Outlet Option With Service Minder Option... -
Page 5: Electrical
TRACTOR - - MODEL NUMBER PB195H42LT (96042012300), PRODUCT NO. 960 42 01-23 ELECTRICAL PART DESCRIPTION 532 16 34-65 Battery 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 19 32-28 Box Battery 532 17 61-38 Switch Interlock 532 18 37-59 Harness Socket Light 532 00 41-52 Bulb, Light #1156... -
Page 6: Chassis
TRACTOR - - MODEL NUMBER PB195H42LT (96042012300), PRODUCT NO. 960 42 01-23 CHASSIS Chassis-tex_elite basic_11... -
Page 7: Chassis
TRACTOR - - MODEL NUMBER PB195H42LT (96042012300), PRODUCT NO. 960 42 01-23 CHASSIS PART DESCRIPTION 532 41 17-64 Dash 532 18 58-47 Hood 532 42 67-92 Grille 532 19 61-25 Plate Engine 817 06 05-12 Screw 5/16-18 x 3/4 532 43 65-23 Fender 873 68 05-00 Nut Lock 5/16-18... -
Page 8: Drive
TRACTOR - - MODEL NUMBER PB195H42LT (96042012300), PRODUCT NO. 960 42 01-23 DRIVE 80 125 drive-tex_K46_fender_24_r1... -
Page 9: Drive
TRACTOR - - MODEL NUMBER PB195H42LT (96042012300), PRODUCT NO. 960 42 01-23 DRIVE PART DESCRIPTION - - - - - - - - - Transaxle, Tufftorq K46BA 532 12 35-83 Key Square 819 13 13-16 Washer 13/32 x 13/16 x 16 Ga. 532 41 36-78 Spring, Brake 532 19 76-60 Rod Shift 532 14 08-45 Knob... -
Page 10: Engine
TRACTOR - - MODEL NUMBER PB195H42LT (96042012300), PRODUCT NO. 960 42 01-23 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-tex_BS_30... -
Page 11: Engine
TRACTOR - - MODEL NUMBER PB195H42LT (96042012300), PRODUCT NO. 960 42 01-23 ENGINE PART DESCRIPTION - - - - - - Engine B&S Model No. 31P677-3373-G1 532 13 73-52 Muffler 532 19 43-20 Keeper Belt Engine 532 40 54-71 Pulley Engine 532 40 75-45 Tank Fuel 1.50 532 43 02-20... -
Page 12: Steering
TRACTOR - - MODEL NUMBER PB195H42LT (96042012300), PRODUCT NO. 960 42 01-23 STEERING steering-tex_STDHRR_5_r1... -
Page 13: Steering
TRACTOR - - MODEL NUMBER PB195H42LT (96042012300), PRODUCT NO. 960 42 01-23 STEERING PART DESCRIPTION 532 42 45-51 Wheel, Steering 532 19 59-68 Axle Asm., Front 532 40 30-87 Spindle Asm., LH 532 40 30-88 Spindle Asm., RH 532 12 49-31 Washer Thrust 0.75 x 1.23 532 12 17-48 Washer 25/32 x 1-5/8 x 16 Ga. -
Page 14: Seat
TRACTOR - - MODEL NUMBER PB195H42LT (96042012300), PRODUCT NO. 960 42 01-23 SEAT seat-tex_6.5SL_2 PART PART DESCRIPTION DESCRIPTION 532 19 75-14 Seat 873 80 05-00 Nut, Lock 5/16-18 unc 532 18 01-66 Bracket Pivot Fender 532 19 76-61 Handle Slide 532 14 06-75 Strap, Asm Fender 532 19 82-00... -
Page 15: Decals
TRACTOR - - MODEL NUMBER PB195H42LT (96042012300), PRODUCT NO. 960 42 01-23 PART PART DESCRIPTION DESCRIPTION 532 42 95-55 Decal Eng. H.P . 532 16 03-96 Decal V-Belt Schematic 532 43 01-13 Decal Hood 532 14 50-05 Decal Bat Dan/Psn 532 43 03-35 Decal Side Panel Logo 532 16 69-60... -
Page 16: Mower Deck
TRACTOR - - MODEL NUMBER PB195H42LT (96042012300), PRODUCT NO. 960 42 01-23 MOWER DECK 42_D_man-tex_LT_35... - Page 17 TRACTOR - - MODEL NUMBER PB195H42LT (96042012300), PRODUCT NO. 960 42 01-23 MOWER DECK PART PART DESCRIPTION DESCRIPTION 532 19 64-95 Mower Housing 532 19 90-92 Spacer, Retainer 532 19 51-86 Arm Suspension 817 00 06-16 Screw Hexwsh Thd 3/8-16 x 1 532 41 63-58 Screw #10 x 0.750 BOS Thread 532 14 10-43...
-
Page 18: Mower Lift
TRACTOR - - MODEL NUMBER PB195H42LT (96042012300), PRODUCT NO. 960 42 01-23 MOWER LIFT 101* lift-tex_17_r3 *Key 91 may be substituted for Key 101 PART PART DESCRIPTION DESCRIPTION 532 42 20-27 Shaft Asm., Cross Lift 532 19 51-81 Link Lift Susp Mower Rear 532 19 52-31 Lever Asm., Lift RH 817 00 06-12... - Page 19 SERVICE NOTES...
-
Page 20: Warranty
LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materi- als and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
