ZEUS HIGH PERFORMANCE AMPLIFIERS The Zeus ZRX Series products have been designed to a very high level of performance, with features unavailable in any other product. All of the amplifiers have variable crossovers built in, with added touches such as subsonic filter, bass equalization and a remote Level control module(some models) that allows subwoofer Level control from the drivers seat. -
Page 3: General Installation Procedure
GENERAL INSTALLATION PROCEDURE System Design The success of any car stereo system relies on several factors, such as the system design, execution of the installation, and system setup. Please remember that any system is only as good as its weakest link. Please remember that higher power systems are not necessarily useful purely for high sound pressure levels, but also to establish a headroom capability, to reproduce musical peaks cleanly without distortion. -
Page 4: Amplifier Feature Descriptions
AMPLIFIER FEATURE DESCRIPTIONS ZEUS ZRX AMPLIFIERS: Each model is capable of 4 & 2-Ohms stereo per channel, or 4-Ohms mono bridged operation except CAUTION: DO NOT OPERATE ANY AMPLIFIER BELOW THE INTENDED IMPEDANCE. YOU the mono amps which are capable of 4, 2 and 1-Ohm loads. WILL CAUSE DAMAGE TO THE AMPLIFIER THAT WILL NOT BE COVERED UNDER THE WARRANTY PRINTED IN THE BACK OF THE MANUAL. -
Page 5: Zrx500.2 / Zrx1200.2 2-Channel Amplifier Applications
ZRX500.2 / ZRX1200.2 2-CHANNEL AMPLIFIER APPLICATIONS FULL RANGE STEREO This is the most basic application for the ZRX Series 2 channel amplifiers. 4. Line Level: Refer to the section “Setting up systems after installation for best performance” 1. Interconnect cable checklist: Connect the LINE INPUTS to the Radio/CD with good quality RCA cables. -
Page 6: Zrx600.4 / Zrx1000.4 / Zrx2000.4 4-Channel Amplifier Applications
ZRX600.4 / ZRX1000.4 / ZRX2000.4 4-CHANNEL AMPLIFIER APPLICATIONS 4 CHANNEL FULL RANGE SYSTEM Here we show how to use the 4 channel amplifiers as straightforward discrete 4 - HI PASS: N/A channel full range units. - LOW PASS: N/A Interconnect cable checklist: Channels 3/4: - Connect the four inputs of the amplifier to a Radio/CD with quality RCA cables. -
Page 7: Zrx600.4 / Zrx1000.4 / Zrx2000.4 4-Channel Amplifier Applications
ZRX600.4 / ZRX1000.4 / ZRX2000.4 4-CHANNEL AMPLIFIER APPLICATIONS Front/Rear high pass, using a 2 channel amplifier for mono sub bass The combination of a 2 and a 4 channel amplifier, utilizing their built in Channels 1/2: crossovers, makes it a snap to put together a full system with front and rear - HI PASS: 100 Hz highs, with mono sub bass. -
Page 8: Zrx1000.1D / Zrx1500.1D / Zrx2000.1D / Zrx3000.1D 1-Channel Amplifier Applications
ZRX1000.1D / ZRX2000.1D / ZRX3000.1D 1-CHANNEL AMPLIFIER APPLICATIONS Basic application These sub bass amplifiers can be used in any of the bi-amplification systems described in Crossover frequency control checklist: this manual, replacing the 2 channel amplifiers as per the illustrations. LOW PASS: 30Hz to 250Hz SUBSONIC:15 Hz to 35 Hz Interconnect cable checklist:... -
Page 10: Setting Up Systems After Installation For Best Performance
SETTING UP SYSTEMS AFTER INSTALLATION FOR BEST PERFORMANCE ZRX500.2 / ZRX1200.2 / ZRX600.4 / ZRX1000.4 / ZRX2000.4 General: At this point you are ready to get more specific on the settings for your amplifier. High Pass: -When in Hi Pass operation, this setting acts as a low frequency cut off for your system reproduction. The point that you set it at cuts off any frequencies from reproduction beyond this point. -
Page 11: Troubleshooting And Diagnostics
TROUBLESHOOTING A SYSTEM The key to finding the problem in a misbehaving sound system is to isolate parts of that system in a logical fashion to track down the fault. Description of the PROTECT system built into all Hifonics amplifiers The diagnostic system will shut down the amplifier, until reset by turning the head unit off, and back on. -
Page 12: Product Warranty
Maxxsonics Limited Warranty As the manufacturer of Maxxsonics, MB Quart, Autotek, Crunch and Hifonics car audio products, Maxxsonics USA Inc. Warrants to the original consumer purchaser the amplifier to be free from defects in material and workmanship for one (1) Year from date of purchase. All other parts and accessories of the system are warrantied to be free from defects in material and workmanship for one (1) year from date of purchase. -
Page 13: Oem Integration Accessories
OEM Integration Accessories MX-1 Premium High To Low Level Converter MX-3 Bass Controller * Converts High Level OEM speaker wires to Ultra Clean RCA Low Level Outputs * High Level Inputs: Accepts all types of High level Inputs * Parametric Bass EQ: Provides a wide array of subwoofer output signal including floating ground and high voltages up to 30 volts. - Page 14 PART#: A811...
