1
MXM10-072699
version:
Contents
Channel Controls and Inputs .................................................. 5
Channels 1 to 4 .................................................................... 5
Channels 1 and 2 ................................................................. 5
XLR Phantom Power .......................................................... 5
EQ Controls .......................................................................... 5
Channels 5/6 and 7/8 ........................................................ 6
1/4" Inputs on Channels 5 to 10 ....................................... 6
Channels 9 and 10 ............................................................... 6
Tape In (RCAs) .................................................................... 6
Send Controls ...................................................................... 6
Stereo Return ............................................................................. 7
Main Level Pot and LEDs ......................................................... 7
Tape Out (RCAs) ........................................................................ 7
Power Indicator and Switch ..................................................... 7
Setting Up the Outputs ............................................................ 9
Headphones............................................................................... 10
Gain Settings ............................................................................. 10
Using the Send and Return for Effects .................................. 10
MIXIM 10
................................................................. 2
.......................................................................... 5
...................................................................... 9
.................................................. 12
MANUAL
™
....................... 4
........................................ 8
................................... 10
...................................... 11
Advertisement
Table of Contents
Related Manuals for M-Audio Mixim 10
Summary of Contents for M-Audio Mixim 10
-
Page 1: Table Of Contents
MANUAL MIXIM 10 ™ MXM10-072699 version: Contents Introduction ..............2 Front & Rear Panels - Fig. 1 ....... 4 Overview ................5 Channel Controls and Inputs ..........5 Channels 1 to 4 ..............5 Channels 1 and 2 ..............5 XLR Phantom Power ............ -
Page 2: Introduction
10 is ideal: “Front End” to a Digital Audio System miXim 10 is ultra quiet which makes it the perfect mixer for the front end of a digital recording set up. Because it’s so quiet it won’t add any noise to your digital recording. Also, because... -
Page 3: Home Studios
Live Band, Duos and Trios miXim 10 takes up very little space. With its built-in mic preamps and variety of controls, it can mix all instruments along with microphones and drive a power amplifier. -
Page 4: Front & Rear Panels - Fig. 1
Front & Rear Panels - Fig. 1 High Norm 9 VAC Channel 3 mon 5L mon 7L mon 9L mon OUT L OUT R MIC 1 MIC 2 IN 1 IN 2 4 mon 6R str 8R str 10R str STR RET SEND LEFT... -
Page 5: Overview
Channel Controls and Inputs Channels 1 to 4: The miXim 10 has 4 mono inputs (1 through 4) with gain control, pan control, a mono send and 3 stage EQ. Channels 1 and 2: Channels 1 and 2 have both XLR and 1/4"... -
Page 6: Channels 5/6 And 7/8
Channel 7/8 and are thus subject to the 7/8 Gain, Balance and Send Controls. Send Controls: Channels 1 through 8 on the miXim 10 have indi- vidual Send controls. These Send controls provide up to 6 dB of post-fader gain over the channel's own gain stage. The combined Send signals are sent out the Send Out at the top right of the unit. -
Page 7: Stereo Return
Stereo Return miXim 10 has a stereo Return. This return is designed to be used with a tip/ring/sleeve jack. The tip goes left, the ring goes right and the sleeve is common (ground) to both channels. The Stereo Return level is controlled by the miXim 10's "Stereo Rtn" pot. If you are not using the Return, it can be used as additional unity gain stereo input. -
Page 8: Typical Set-Up - Fig. 2
Typical Set-Up - Fig. 2 Master Keyboard Speakers Right Output Left Output Master Keyboard Power Amplifier MIDI Sound Module Left Left Left Right Right Right Right Left Effects Unit Stereo Input Output To EQable Ins SEND STR RET (3 & 4) OUT R &... -
Page 9: Setting-Up
Setting Up the Outputs If you are using the miXim 10 in live performance, you will prob- ably want to connect the Left and Right Outs to the input(s) of a power amplifier. If you are using miXim 10 in a studio applica-... -
Page 10: Headphones
The output levels of miXim 10 are controlled by the stereo Main level pot. When set to 9 o'clock, miXim 10 has unity gain. This is the best setting for going into a mixing board. If you are going into a power amplifier, this pot will act as a convenient volume control. -
Page 11: Block Diagram - Fig. 3
For the best S/N ratio, set the send level on the miXim 10 so that the effects unit is getting the “hottest” possible signal without overloading. -
Page 12: Limited Warranty
Limited Lifetime Warranty MIDIMAN warrants that this product is free of defects in materials and workmanship under normal use so long as the product is owned by the original purchaser and that purchaser has registered his/her ownership of the product by sending in the completed warranty card.
