Instruction Manual
Cradle Swing
Cradle
Swing
Model Number: 79595, 79596
Please keep this instruction sheet for future reference, as it contains important information.
Adult assembly is required.
Tools needed for assembly: Phillips Screwdriver and Adjustable Wrench (both not included).
Requires three "D" (LR20) alkaline batteries for operation (not included).
Maximum Weight Limit: 24 lbs. (10.9 kg.)
The maximum weight limit for this product is 24 lbs.
IMPORTANT! If your child weighs less than 24 lbs., but is really active and appears to be
able to climb out of the swing, immediately discontinue its use.
Advertisement
Table of Contents
Related Manuals for Fisher-Price 79596
Summary of Contents for Fisher-Price 79596
- Page 1 Cradle Swing Cradle Swing Model Number: 79595, 79596 Please keep this instruction sheet for future reference, as it contains important information. Adult assembly is required. Tools needed for assembly: Phillips Screwdriver and Adjustable Wrench (both not included). Requires three “D” (LR20) alkaline batteries for operation (not included).
-
Page 2: Warnings And Caution
Warnings and Caution WARNING • To prevent falls, never use with an active child who may be able to climb out of the seat. • Never leave child unattended. • To prevent injury or death from falls or sliding out, always use restraint system. - Page 3 IMPORTANT! Before each use or assembly, inspect this product for damaged hardware, loose joints, missing parts or sharp edges. DO NOT use if any parts are missing or broken. Contact Fisher-Price® for replacement parts and instructions if needed. Never substitute parts.
- Page 4 Assembly Hole Tubes Hole • Position the motorized frame so that the battery compartment is toward you. • Position the tubes in the motorized frame so that they are toward the outer edges. The holes in the tubes should be visible through the notches in the motorized frame.
- Page 5 Assembly Elastic Loop Bottom View • While holding the elastic loops in place, turn the seat face down. • Hook the elastic loop on the left side onto the peg on the right side. • Hook the elastic loop on the right side onto the peg on the left side.
- Page 6 Assembly Slot • Turn the seat upright. • Insert the tray tabs into the slots in each side of the seat. • Insert the ends of the toy bar into the holes in the tray. Press down on the ends of the toy bar to be sure they are secure. Seat Tube Button M4 x 31.5 mm Bolt...
-
Page 7: Battery Installation
Battery Installation 1.5V x 3 “D” (LR20) SHOWN ACTUAL SIZE Battery Compartment • Using a coin, press the tab on the battery compartment door and remove it. • Insert three “D” (LR20) alkaline batteries, as indicated inside the battery compartment. Hint: We recommend using alkaline batteries for longer battery life. - Page 8 IMPORTANT! Before each use or assembly, inspect this prod- uct for damaged hardware, loose joints, missing parts or sharp edges. DO NOT use if any parts are missing or broken. Contact Fisher-Price® for replacement parts and instructions if needed. Never substitute parts. Cradle Side-to-side swinging motion soothes baby.
- Page 9 Cradle and Swing Use Restraint Belts Waist Belt Crotch Belt • Place your child in the seat. • Pull the crotch belt up between your child’s legs and fasten both waist belts to the crotch belt. Make sure you hear a “click” on both sides. To Tighten Anchored End Free End...
- Page 10 Cradle and Swing Use Adjust Positions Seat Tube Cradle Swing You can adjust the seat tube to three different positions: • Press the seat tube button to unlock the seat tube. • Rotate the seat tube to the desired position. Adjust to Recline or Upright Positions Front Edge of Seat...
-
Page 11: Problems And Solutions
Problems and Solutions Condition Probable Cause Power indicator does not Power is not on light, motor is not running Batteries incorrectly installed Dead batteries Motor is running but Need to start swinging motion swinging stops after a few minutes Swing motion setting is inappropriate for child’s weight Weak batteries No difference noticed in... -
Page 12: One (1) Year Limited Warranty
Richmond, Victoria 3121 Australia. Consumer Advisory Service 1300 135 312. New Zealand: 16-18 William Pickering Drive, Albany 1331, Auckland. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A. ©2002 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
