ELECTRONIC
ELECTRIC DRYERS
Use & Care Guide
For questions about features, operation/performance,
parts, accessories or service, call: 1-800-688-9900
or visit our website at...
www.amana.com
Table of Contents ................................................. 2
W10216186A

Advertisement

Table of Contents
loading

Summary of Contents for Amana W10216186A

  • Page 1 ELECTRONIC ELECTRIC DRYERS Use & Care Guide For questions about features, operation/performance, parts, accessories or service, call: 1-800-688-9900 or visit our website at... www.amana.com Table of Contents ... 2 W10216186A...
  • Page 2: Table Of Contents

    DRYER SAFETY...2 INSTALLATION INSTRUCTIONS ...4 Tools and Parts ...4 Optional Pedestal...4 Location Requirements ...4 Electrical Requirements ...6 Electrical Connection ...8 Venting Requirements... 13 Plan Vent System ... 14 Install Vent System... 15 Install Leveling Legs... 15 Connect Vent... 16 Level Dryer ... 16 Reverse Door Swing ...
  • Page 3 WARNING: To reduce the risk of fire, electric shock, or injury to persons when using the dryer, follow basic precautions, including the following: ■ Read all instructions before using the dryer. ■ Do not place items exposed to cooking oils in your dryer. Items contaminated with cooking oils may contribute to a chemical reaction that could cause a load to catch fire.
  • Page 4: Installation Instructions

    INSTALLATION INSTRUCTIONS Tools and Parts Gather the required tools and parts before starting installation. Read and follow the instructions provided with any tools listed here. ■ ■ Flat-blade screwdriver Vent clamps ■ #2 Phillips screwdriver ■ Caulking gun and compound (for installing ■...
  • Page 5 ■ A level floor with a maximum slope of 1" (25 mm) under entire dryer. (If slope is greater than 1" [25 mm], install Extended Dryer Feet Kit, Part Number 279810.) Clothes may not tumble properly and automatic sensor cycles may not operate correctly if dryer is not level.
  • Page 6: Electrical Requirements

    Installation spacing for cabinet installation ■ For cabinet installation, with a door, minimum ventilation openings in the top of the cabinet are required. 7"* (178 mm) 7"* (178 mm) 1"* 5"** 31½" (127 mm) (800 mm) (25 mm) (25 mm) *Required spacing **For side or bottom venting, 0"...
  • Page 7 If using a power supply cord: Use a UL listed power supply cord kit marked for use with clothes dryers. The kit should contain: ■ A UL listed 30-amp power supply cord, rated 120/240 volt minimum. The cord should be type SRD or SRDT and be at least 4 ft (1.22 m) long.
  • Page 8: Electrical Connection

    Power Supply Cord WARNING Fire Hazard Use a new UL listed 30 amp power supply cord. Use a UL listed strain relief. Disconnect power before making electrical connections. Connect neutral wire (white or center wire) to center terminal (silver). Ground wire (green or bare wire) must be connected to green ground connector.
  • Page 9 ■ Put power supply cord through the strain relief. Be sure that the wire insulation on the power supply cord is inside the strain relief. The strain relief should have a tight fit with the dryer cabinet and be in a horizontal position. Do not further tighten strain relief screws at this point.
  • Page 10 2. Remove neutral ground wire from external ground conductor screw. Connect neutral ground wire and the neutral wire (white or center wire) of power supply cord under center, silver-colored terminal block screw. Tighten screw. A. External ground conductor screw - Dotted line shows position of NEUTRAL ground wire before being moved to center silver-colored terminal block screw.
  • Page 11 3. Connect ground wire (green or bare) of direct wire cable to external ground conductor screw. Tighten screw. A. External ground conductor screw B. Ground wire (green or bare) of power supply cable C. ¾" (19 mm) UL listed strain relief D.
  • Page 12 3-wire connection: Direct wire Use where local codes permit connecting cabinet-ground conductor to neutral wire. Direct wire cable must have 5 ft (1.52 m) of extra length so dryer can be moved if needed. Strip 3½" (89 mm) of outer covering from end of cable. Strip insulation back 1"...
  • Page 13: Venting Requirements

    Venting Requirements WARNING Fire Hazard Use a heavy metal vent. Do not use a plastic vent. Do not use a metal foil vent. Failure to follow these instructions can result in death or fire. WARNING: To reduce the risk of fire, this dryer MUST BE EXHAUSTED OUTDOORS.
  • Page 14: Plan Vent System

    ■ Do not use an exhaust hood with a magnetic latch. Improper venting can cause moisture and lint to collect indoors, which may result in: Moisture damage to woodwork, furniture, paint, wallpaper, carpets, etc. Housecleaning problems and health problems. Plan Vent System Choose your exhaust installation type Recommended exhaust installations Typical installations vent the dryer from the rear of the dryer.
  • Page 15: Install Vent System

    ■ Periscope Installation (For use with dryer vent to wall vent mismatch): Part Number 4396037 - 0" (0 mm) to 18" (457.2 mm) mismatch Part Number 4396011 - 18" (457.2 mm) to 29" (736.6 mm) mismatch Part Number 4396014 - 29" (736.6 mm) to 50" (1270 mm) mismatch Special provisions for mobile home installations The exhaust vent must be securely fastened to a noncombustible...
  • Page 16: Connect Vent

    Connect Vent 1. Using a 4" (102 mm) clamp, connect vent to exhaust outlet in dryer. If connecting to existing vent, make sure the vent is clean. The dryer vent must fit over the dryer exhaust outlet and inside the exhaust hood. Check that the vent is secured to exhaust hood with a 4"...
  • Page 17: Complete Installation

    4. Move hinge to the other side and reattach with the 4 screws removed in Step 2. Make sure locator pins line up in holes and drive the top 2 screws in place first to help drive locator pins into proper location. 5.
  • Page 18: Dryer Use

    WARNING Explosion Hazard Keep flammable materials and vapors, such as gasoline, away from dryer. Do not dry anything that has ever had anything flammable on it (even after washing). Failure to follow these instructions can result in death, explosion, or fire. WARNING: To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance.
  • Page 19: Stopping Your Dryer

    How Automatic Cycles Work The AccelerCare function improves drying performance with Auto Moisture Sensing Plus, which advances the cycle as moisture is extracted from clothing. A thermistor (electronic temperature sensor) and moisture sensing strips in the dryer drum help measure the amount of moisture in the clothes as they tumble. An electronic control determines the load type to help save time, avoid overdrying, and increase the accuracy of the end dryness level.
  • Page 20: Status Lights

    Status Lights You may follow the progress of your dryer with the drying Status indicator lights. Timed Cycle The Timed Cycle light glows green during a Timed Cycle. The Wet light glows green at the beginning of Automatic Cycle if a wet item is detected or in a timed cycle after 5 minutes.
  • Page 21: Options

    Timed Cycles Use Timed Cycles to select a specific amount of drying time and a drying temperature. (Temperatures are not selectable with Air Fluff.) When a Timed Cycle is selected, the Estimated Time Remaining display shows the actual time remaining in your cycle. You can change the actual time in the cycle by pressing More Time or Less Time.
  • Page 22: Modifiers

    Modifiers Use Modifiers to select time, temperatures, and dryness levels for the Timed Cycles. Not all Modifiers are available with all options and cycles. Available modifier settings will glow amber. Current selections will glow green. If a modifier is unavailable with a selected cycle, the light will not illuminate.
  • Page 23: Dryer Care

    To use the heated dryer rack: Do not remove the lint screen. 1. Open dryer door. A. Front edge 2. Place dryer rack over the bottom of the dryer door opening. Rest the back wire on the dryer back ledge. Push down on the frame front to secure over lint screen.
  • Page 24: Cleaning The Dryer Interior

    IMPORTANT: ■ Do not run the dryer with the lint screen loose, damaged, blocked, or missing. Doing so can cause overheating and damage to both the dryer and fabrics. ■ If lint falls off the screen into the dryer during removal, check the exhaust hood and remove the lint.
  • Page 25: Troubleshooting

    First try the solutions suggested here and possibly avoid the cost of a service call... Dryer Operation Dryer will not run ■ Has a fuse blown, or has a circuit breaker tripped? There may be 2 fuses or circuit breakers for the dryer. Check that both fuses are intact and tight, or that both circuit breakers have not tripped.
  • Page 26 ■ Is the exhaust vent or outside exhaust hood clogged with lint, restricting air movement? Run the dryer for 5-10 minutes. Hold your hand under the outside exhaust hood to check air movement. If you do not feel air movement, clean exhaust system of lint or replace exhaust vent with heavy metal or flexible metal vent.
  • Page 27: Assistance Or Service

    ASSISTANCE OR SERVICE For Assistance and Service Call Maytag Services, LLC Customer Assistance toll free: 1-800-688-9900, or visit our website at www.amana.com/help Our consultants provide assistance with: ■ Features and specifications on our full line of appliances.
  • Page 28: Warranty

    5. Cosmetic damage, including scratches, dents, chips or other damage to the finish of your major appliance, unless such damage results from defects in materials or workmanship and is reported to Amana within 30 days from the date of purchase.
