HANNspree K206-10H1 Quick Start Manual

K206-10H1 9.6" Liquid Crystal Display TV
This guide is designed as a reference to help you start using your LCD TV quickly.
Please refer to the User's Manual for more detailed installation and safety instructions.
Front View Front View
Speaker
Volume
adjust
Menu
Remote IR sensor

Making Connections

Connecting to Antenna/Cable TV
Antenna
DC 12V 4-IN-1 HEADPHONE ANT
ANT jack
(VHF/UHF IN Jack)
DC 12V 4-IN-1 HEADPHONE ANT
Antenna/CATV
coaxial cable
Connecting to a VCR, VCD, DVD Player, or Video Game Console
1. The illustration presented
here shows you how to
connect your TV to a
VCR, VCD, DVD player
or video game console.
4-IN-1 A/V jack
DC 12V
Video game console
B
R
W
Y
4-IN-1 A/V cable

Connecting the Power Adapter

Power outlet
DC 12V 4-IN-1 HEADPHONE ANT
Power cord
DC 12V 4-IN-1 HEADPHONE ANT
DC-IN
Power adapter
Copyright 2005, Hannspree, Inc. All rights reserved.

Quick Start Guide

Source
Channel
Power/
select
Power indicator LED
1. Connect one end of the VHF/UHF
(Antenna) or CATV cable to ANT Jack
(VHF/UHF IN Jack) on the back of the
TV.
2. Connect the other end of the VHF/UHF
(Antenna) or CATV cable to the Antenna
or CATV socket.
VCR
VCD
DVD
DC 12V 4-IN-1 HEADPHONE ANT
2. The cables are
color-coded (black,
red, white, and yellow).
B R W Y
4-IN-1 HEADPHONE ANT
Connect each color-
S-Video
coded cable to
connector
the appropriate
connector on your
device.
AV connectors
1. Connect the power cord to the power
adapter as illustrated.
2. Plug the power adapter connector into
the DC-IN input jack on the rear panel
of the TV.
3. Insert the three-pronged plug at the
other end of the power cord into a
power outlet.
Note :
Images are for illustration only and may
vary by model or region.
Other Models
The information in this Quick Start Guide applies to all models shown below.
Rear View Rear View
Speaker
Note: Do not unzip the plush cover. The plush
cover may only be removed by the qualified
personnel to service the product.
A/V and Channel Setup
Selecting A/V Sources
1. Make sure your TV is turned on and a
device such as a DVD player is connected.
2. Press the SOURCE button on the
control panel to select different source signals.
TV channel number, AV or AVs appear on the screen.
Note : AVs only appears on the screen when
S-Video is connected.
menu
VOL
Auto Channel Setup
Please follow the instructions by using the control panel.
1. Press the MENU button to enter the OSD menu.
2. Use the CH
3. Press the VOL
4. Press the CH
5. Press the VOL
6. Your television will begin automatically memorizing the available channels.
DC 12V 4-IN-1 HEADPHONE ANT
DC 12V 4-IN-1 HEADPHONE
4-IN-1 Antenna/Cable TV
DC 12V Headphone jack
CH
SOURCE
VOL
CH
button to select "TV".
+
button to enter the TV setting.
button until the "Auto Program" feature is selected.
+
button to begin "Auto Program".
Auto Program
TV
Auto-Programming
093.84 MHz
1 6%
Return :
ANT
TV
AV
CH
menu SOURCE
VOL VOL
CH
MENU
MAD-001280
