MILWAUKEE ELECTRIC TOOL CORPORATION – TEST & MEASUREMENT PRODUCT
REPAIR SERVICE INSTRUCTIONS — CALIBRATION
2217-20 Digital Multimeter
Perform all calibration at an ambient temperature of 23°C ± 2°C / 73.4°F ± 3.6°F and relative
Environmental
humidity of 80% - allow the digital multimeter to sit at this temperature for a minimum of 30
Condition
minutes before proceeding.
MILWAUKEE ELECTRIC TOOL CORPORATION
13135 WEST LISBON ROAD ● BROOKFIELD, WISCONSIN 53005-2550 ● USA

REPAIR SERVICE

INSTRUCTIONS
Calibration
58-92-2217d1 02/2010

Advertisement

Table of Contents
loading

Related Manuals for Milwaukee 2217-20

Summary of Contents for Milwaukee 2217-20

  • Page 1: Repair Service

    MILWAUKEE ELECTRIC TOOL CORPORATION – TEST & MEASUREMENT PRODUCT REPAIR SERVICE INSTRUCTIONS — CALIBRATION 2217-20 Digital Multimeter Perform all calibration at an ambient temperature of 23°C ± 2°C / 73.4°F ± 3.6°F and relative Environmental humidity of 80% - allow the digital multimeter to sit at this temperature for a minimum of 30 Condition minutes before proceeding.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Page Introduction Symbols Safety Specifications c i f a t l c i f c i f , y t a t i c i f Frequency, Temperature, Thermocouple, Rotary Switch, Auto Power Off Specification i t s i t r c i f a i l...

  • Page 3: Introduction

    The information provided in this document is for the use of qualified personnel only. CAUTION The 2217-20 contain parts that can be damaged by static discharge. Follow the standard practices for handling static sensitive devices. Precautions and Safety Information Use the Meter only as described in the Operator’s Manual.

  • Page 4: Safety

    SAFETY Review the following safety precautions to avoid injury and prevent damage to this product or products connected to it. To avoid potential hazards, use the product only as specified. WARNING: These statements identify conditions or practices that could result in personal injury or loss of life.

  • Page 5: Specifications

    SPECIFICATIONS All specifications are warranted unless noted typical and apply to the 2217-20 DMM. Stated accuracies are at 23°C±5°C at than 80% relative humidity and without the battery indicator displayed. General specifications c i r y t i c i t Display "OL"...
  • Page 6 Measurement Characteristics Accuracy is ±(% reading + number of digits) at 23°C ± 5°C, less than 80% R.H. Temperature coefficient: 0.1 * (Specified accuracy)/°C, < 18°C, > 28°C (1) DC Voltage Range Resolution Accuracy 600.0mV 0.1mV 6.000V 0.001V ±(0.5% reading + 2 digits) 60.00V 0.01V 600.0V...
  • Page 7 (3) Lo-Z Voltage (Auto DC & AC Detection) Range Resolution Accuracy 600.0V DC & AC 0.1V ±(2% reading + 3 digits) Input Impedance: less than 6kΩ AC Frequency Response: 45 ~ 500Hz (Sine Wave) AC Conversion Type: RMS sensing, RMS indication Additional Accuracy by Crest Factor (C.F.): Same as ACV.
  • Page 8 (6) Resistance Range Resolution Accuracy 600.0Ω 0.1Ω 6.000kΩ 0.001kΩ 60.00kΩ 0.01kΩ ±(1% reading + 5 digits) 600.0kΩ 0.1kΩ 6.000MΩ 0.001MΩ 40.00MΩ * 0.01MΩ ±(2% reading + 5 digits) * There is a little rolling less then ±50 digits when measuring > 10.00 MΩ. Open Circuit Voltage: Approx.
  • Page 9 (9) Frequency Range Resolution Min. Sensitivity Accuracy 100.00Hz 0.01Hz > 10.0Vp-p 1000.0Hz 0.1Hz > 10.0Vp-p ±(0.1% reading + 2 digits) 10.000kHz 0.001Hz > 10.0Vp-p 50.00kHz 0.01Hz > 10.0Vp-p Max. Sensitivity: 600V rms Response Time: < 1.2 sec. when measuring bigger than 2.00Hz signal. Overload Protection: AC/DC 720V for 10 second.
  • Page 10 (15) Measuring Rate: 3 times/sec. (16) Fuse: 10A/600V Fast Action Fuse (Cat. No. 22-89-0300) (17) Battery: Alkaline 1.5V Battery * 2 (18) Low Battery Voltage: 2.3V ± 0.1V (19) Backlight The meter automatically turns the backlight off after lighting up and no operation for 10 ± 1 minutes.
  • Page 11 Physical and Environmental Characteristics 170mm×80mm×57mm Dimensions (H×W×D) ° 0 Non-Operating -40 to +60°C y t i < i t l ) . t Non-Operating 12,300M (40354 ft.) Vibration & shock Operating MIL-PRF-28800F for Class 2 Instrument Certifications and compliances Safety Designed to IEC61010-1, UL61010-1 and CSA specifications Input rating Category III 600V.
  • Page 12 Required Equipment Required equipment is listed in Table B. If the recommended models are not available, equipment with equivalent specifications may be used. Repairs or servicing should be performed only by qualified personnel. Table B. Required Equipment Equipment Required Characteristics Recommended Model AC Voltage Range: 0 ~ 750V AC Calibrator...

  • Page 13: Basic Maintenance

    Basic Maintenance WARNING To avoid shock, disconnect test leads from any voltage source than remove from meter before opening the case or replacing the battery. Opening the Battery Door CAUTION To avoid unintentional shock circuit, always place the uncovered Meter assembly on a protective surface.

  • Page 14: Testing Fuses

    WARNING To avoid shock, disconnect test leads from any voltage source than remove from meter before opening the case or replacing the fuse. Opening the Meter Case CAUTION To avoid unintentional shock circuit, always place the uncovered Meter assembly on a protective surface.

  • Page 15: Performance Tests

    Testing the Display Rotate the dial from the "OFF" position to any other position. Check the LCD display segments when all segments are displayed. Compare the display with the example in Figure 2. LCD Graphics 2217-20 Figure 2 Display Test...
  • Page 16 Testing the Voltage Function To verify accuracy in the AC and DC voltage ranges, do the following: 1. Turn the rotary switch to “V ” position. 2. Connect the Calibrator to the VΩ and COM inputs on the Meter. 3. Set the Calibrator for the voltage and frequency from step 1 to 12 in Table 1. 4.

  • Page 17: Testing The Resistance F U N T C O I N

    Testing the Resistance Function To verify the accuracy of the resistance function, do the following: 1. Connect the Calibrator to VΩHz and COM on the Meter. 2. Turn the rotary switch to Ω. 3. Apply the inputs for step 1-6 in Table 3. 4.

  • Page 18: Testing The Ampere F U N T C O I N

    Testing the Ampere Function To verify the accuracy of AC current measurement functions, do the following: 1. Connect the Calibrator to the A and COM inputs on the Meter. 2. Turn the rotary switch to A~. 3. Apply the inputs for steps 1-4 in Table 5. 4.

  • Page 19: Testing The Temperature F U N T C O I N

    Table 7 Frequency Test: Step Source Level Waveform Reading 8.0Vp-p 2.00Hz Square Wave 1.98Hz to 2.02Hz 8.0Vp-p 80.00Hz Square Wave 79.90Hz to 80.10Hz 8.0Vp-p 800.0Hz Square Wave 799.0Hz to 801.0Hz 8.0Vp-p 8.000kHz Square Wave 7.990kHz to 8.010kHz 10.0Vp-p 50.00kHz Square Wave 49.93kHz to 50.07kHz 600.0Vp-p 10.00Hz...

  • Page 20: Calibration Procedure

    Calibration Procedure Recalibrate the meter: It is recommended that the meter may be calibrated once year. Use the following procedure to calibrate the meter. Environmental Condition Perform calibration at an ambient temperature and relative humidity (23°C±2°C and R.H. < 80%). Allow the instrument to sit at this temperature for at least thirty minutes.
  • Page 21 (E) DCA Calibration (VR7) Rotate the rotary switch to DCA Function. Connect the output of a DCA calibrator to V and COM input terminals of the meter. Output DCA 5.000A from the calibrator. Adjust VR7 until the display shows 5.000A ± 0.001A. Turn off the output of the calibrator and disconnect the meter from the calibrator.
