Summary of Contents for Mazda CX-9

Page 1: Table Of Contents
CX-9_8CA8-EA-11G_Edition1 Page479 Thursday, June 23 2011 11:6 AM Black plate (479,1) Maintenance and Care How to keep your Mazda in top condition. Introduction .................. 8-2 Introduction ................8-2 Scheduled Maintenance ..............8-3 Scheduled Maintenance (USA, Canada, and Puerto Rico) ..8-3 Scheduled Maintenance (Mexico) ..........
Page 2: Introduction
Claims against the warranty resulting from lack of maintenance, as opposed to defective materials or authorized Mazda workmanship, will not be honored. Any auto repair shop using parts equivalent to your Mazda's original equipment may perform maintenance. But we recommend that it always be done by an Authorized Mazda Dealer using genuine Mazda parts.
Page 3: Scheduled Maintenance
CX-9_8CA8-EA-11G_Edition1 Page481 Thursday, June 23 2011 11:6 AM Black plate (481,1) Maintenance and Care Scheduled Maintenance Scheduled Maintenance (USA, Canada, and Puerto Rico) Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions apply. Repeated short-distance driving Driving in dusty conditions Driving with extended use of brakes Driving in areas where salt or other corrosive materials are used...
Page 4: Scheduled Maintenance (Mexico)
CX-9_8CA8-EA-11G_Edition1 Page482 Thursday, June 23 2011 11:6 AM Black plate (482,1) Maintenance and Care Scheduled Maintenance qSchedule 1 Number of months or kilometers (miles), whichever comes first Months Maintenance Interval ×1000 km ×1000 miles 22.5 37.5 52.5 ENGINE Inspect every 168,000 km (105,000 miles) Drive belts Replace every 240,000 km (150,000 miles) Engine oil...
Page 5 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
Page 6 CX-9_8CA8-EA-11G_Edition1 Page484 Thursday, June 23 2011 11:6 AM Black plate (484,1) Maintenance and Care Scheduled Maintenance qSchedule 2 Number of months or kilometers (miles), whichever comes first Months Maintenance Interval ×1000 km ×1000 miles ENGINE Inspect every 160,000 km (100,000 miles) Drive belts Replace every 240,000 km (150,000 miles) Puerto Rico...
Page 7 CX-9_8CA8-EA-11G_Edition1 Page485 Thursday, June 23 2011 11:6 AM Black plate (485,1) Maintenance and Care Scheduled Maintenance Number of months or kilometers (miles), whichever comes first Months Maintenance Interval ×1000 km ×1000 miles CHASSIS and BODY Brake lines, hoses and connections Brake fluid level Disc brakes Tire (Rotation)
Page 8 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
Page 9 CX-9_8CA8-EA-11G_Edition1 Page487 Thursday, June 23 2011 11:6 AM Black plate (487,1) Maintenance and Care Scheduled Maintenance Scheduled Maintenance (Mexico) Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions apply. Repeated short-distance driving Driving in dusty conditions Driving with extended use of brakes Driving in areas where salt or other corrosive materials are used Driving on rough or muddy roads...
Page 10 CX-9_8CA8-EA-11G_Edition1 Page488 Thursday, June 23 2011 11:6 AM Black plate (488,1) Maintenance and Care Scheduled Maintenance qSchedule 1 Number of months or kilometers, whichever comes first Maintenance Interval Months ×1000 km 90 100 110 120 ENGINE Inspect every 40,000 km or 2 years Drive belts Replace every 240,000 km Engine oil...
Page 11 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
Page 12 CX-9_8CA8-EA-11G_Edition1 Page490 Thursday, June 23 2011 11:6 AM Black plate (490,1) Maintenance and Care Scheduled Maintenance qSchedule 2 Number of months or kilometers, whichever comes first Maintenance Interval Months ×1000 km ENGINE Inspect every 40,000 km or 2 years Drive belts Replace every 240,000 km Engine oil Engine oil filter...
Page 13 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
Page 14 CX-9_8CA8-EA-11G_Edition1 Page492 Thursday, June 23 2011 11:6 AM Black plate (492,1) Maintenance and Care Scheduled Maintenance (Cont.) Number of months or kilometers, whichever comes first Maintenance Interval Months ×1000 km 95 100 105 110 115 120 ENGINE Inspect every 40,000 km or 2 years Drive belts Replace every 240,000 km Engine oil...
Page 15 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
Page 16: Owner Maintenance
The owner or a qualified service technician should make these vehicle inspections at the indicated intervals to ensure safe and dependable operation. Bring any problem to the attention of an Authorized Mazda Dealer or qualified service technician as soon as possible.
Page 17: Owner Maintenance Precautions
Improper owner maintenance during the warranty period may affect warranty coverage. For details, read the separate Mazda Warranty statement provided with the vehicle. If you're unsure about any servicing or maintenance procedure, have it done by an Authorized Mazda Dealer.
Page 18: Engine Compartment Overview
CX-9_8CA8-EA-11G_Edition1 Page496 Thursday, June 23 2011 11:6 AM Black plate (496,1) Maintenance and Care Owner Maintenance Engine Compartment Overview Engine coolant reservoir Brake fluid reservoir Power steering Battery Fuse block fluid reservoir Relay box Windscreen washer Engine oil dipstick fluid reservoir Engine oil-filler cap 8-18 Form No.8CA8-EA-11G...
Page 19: Engine Oil
Changing the engine oil should be done by an and emission system protection standards Authorized Mazda Dealer. and fuel economy requirements of the Mazda recommends Mazda Genuine Parts International Lubricant Standardization and Castrol (U.S.A and Mexico). For and Approval Committee (ILSAC), optimal engine performance, there are comprised of U.S.
Page 20 CX-9_8CA8-EA-11G_Edition1 Page498 Thursday, June 23 2011 11:6 AM Black plate (498,1) Maintenance and Care Owner Maintenance The quality designation SM, or ILSAC CAUTION must be on the label. Do not add engine oil over MAX. This may cause engine damage. –40 –20 –30...
Page 21: Engine Coolant
When the engine and radiator are hot, scalding coolant and steam may shoot out under pressure and cause serious injury. NOTE Changing the coolant should be done by an Authorized Mazda Dealer. 8-21 Form No.8CA8-EA-11G...
Page 22 If the “FL22” mark is shown on or near the Ø Radiator coolant will damage cooling system cap, it is recommended to use paint. Mazda Genuine FL22 engine coolant (page Rinse it off quickly if spilled. 8-3). Ø Use only soft (demineralized) water in the coolant mixture.
Page 23: Brake Fluid
If it immediately flush your eyes with is excessively low, have the brake system water and get medical attention. inspected by an Authorized Mazda Brake fluid spilled on a hot engine Dealer. could cause a fire.
Page 24: Power Steering Fluid
The level must be kept between MAX and climates in which the vehicle will be operated. MIN. Visually examine the lines and hoses for leaks and damage. If new fluid is required frequently, consult an Authorized Mazda Dealer. 8-24 Form No.8CA8-EA-11G...
Page 25: Body Lubrication
CX-9_8CA8-EA-11G_Edition1 Page503 Thursday, June 23 2011 11:6 AM Black plate (503,1) Maintenance and Care Owner Maintenance Inspect fluid level in the washer fluid Body Lubrication reservoir; add fluid if necessary. All moving points of the body, such as door and hood hinges and locks, should be lubricated each time the engine oil is changed.
Page 26: Wiper Blades
Be careful not to pinch hands or fingers as it may cause injury, or damage the wipers. When washing or servicing your Mazda, make sure the wiper lever is in the OFF position. Contamination of either the windshield or the blades with foreign matter can reduce wiper effectiveness.
Page 27 CX-9_8CA8-EA-11G_Edition1 Page505 Thursday, June 23 2011 11:6 AM Black plate (505,1) Maintenance and Care Owner Maintenance 4. Tilt the blade assembly and remove it 6. Remove the metal stiffeners from each from the arm. blade rubber and install them in the new blade.
Page 28 CX-9_8CA8-EA-11G_Edition1 Page506 Thursday, June 23 2011 11:6 AM Black plate (506,1) Maintenance and Care Owner Maintenance 7. Carefully insert the new blade rubber. 2. Firmly rotate the wiper blade to the Then install the blade assembly in the right until it unlocks, then remove the reverse order of removal.
Page 29 CX-9_8CA8-EA-11G_Edition1 Page507 Thursday, June 23 2011 11:6 AM Black plate (507,1) Maintenance and Care Owner Maintenance 4. Remove the metal stiffeners from each blade rubber and install them in the new blade. CAUTION Don't bend or discard the stiffeners. You need to use them again. 5.
Page 30: Battery
CX-9_8CA8-EA-11G_Edition1 Page508 Thursday, June 23 2011 11:6 AM Black plate (508,1) Maintenance and Care Owner Maintenance Battery WARNING Wash hands after handling the battery and related accessories: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm. Read the following precautions carefully before using the battery or inspecting to ensure safe and correct handling: Always wear eye protection when working near the battery:...
Page 31 CX-9_8CA8-EA-11G_Edition1 Page509 Thursday, June 23 2011 11:6 AM Black plate (509,1) Maintenance and Care Owner Maintenance Keep all flames, including cigarettes, and sparks away from open battery cells: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode.
Page 32: Tires
Using Wrong-Sized Tires: accident. Do not use any part for the Using any other tire size than what is tire valve cap that is not a Mazda- specified for your Mazda (page 10-6) genuine part. is dangerous. It could seriously affect...
Page 33 CX-9_8CA8-EA-11G_Edition1 Page511 Thursday, June 23 2011 11:6 AM Black plate (511,1) Maintenance and Care Owner Maintenance í The Tire Pressure Monitoring System NOTE does not alleviate the need to check the Always check tire pressure when tires are tire condition every day, including cold.
Page 34 Out-of-balance wheel When replacing/repairing the tires or Severe braking wheels or both, have the work done by an Authorized Mazda Dealer, or After rotation, inflate all tire pressures to the tire pressure sensors may be specification (page 10-6) and inspect the damaged.
Page 35 CX-9_8CA8-EA-11G_Edition1 Page513 Thursday, June 23 2011 11:6 AM Black plate (513,1) Maintenance and Care Owner Maintenance If a tire wears evenly, a wear indicator The temporary spare tire is easier to will appear as a solid band across the handle because of its construction which tread.
Page 36 Ø WARNING tires or wheels or both, have the work done by an Authorized Always use wheels of the correct size Mazda Dealer, or the tire on your vehicle: pressure sensors may be Using a wrong-sized wheel is damaged. dangerous. Braking and handling The wheels equipped on your Ø...
Page 37 CX-9_8CA8-EA-11G_Edition1 Page515 Thursday, June 23 2011 11:6 AM Black plate (515,1) MEMO 8-37 Form No.8CA8-EA-11G...
Page 38: Light Bulbs
CX-9_8CA8-EA-11G_Edition1 Page516 Thursday, June 23 2011 11:6 AM Black plate (516,1) Maintenance and Care Owner Maintenance Light Bulbs Overhead light (Center) Overhead light (Rear) Overhead light/Map lights (Front) Side turn signal lights Vanity mirror lights Courtesy lights Parking lights Front side marker lights Headlights (High beam) Front turn signal lights Fog lights...
Page 39 Consult an Authorized Mazda Dealer when the replacement is necessary. Never touch the glass portion of a halogen bulb with your bare hands and always wear eye protection when 4.
Page 40 Low-beam bulb (Xenon fusion bulb) You cannot replace the low beam bulbs by yourself. The bulbs must be replaced at an Authorized Mazda Dealer. (Halogen bulbs) 1. Make sure the headlight switch is off. 2. Lift the hood. 8-40...
Page 41 To replace the bulb, contact an Authorized connector with your finger and pulling Mazda Dealer the connector downward. If the halogen bulb is accidentally touched, it should be cleaned with rubbing alcohol before being used.
Page 42 7. Install the coolant reservoir. If you are unsure of how tight the bolts should be, have them inspected at an Authorized Mazda Dealer. Bolt tightening torque 6.9―11.8 4. Turn the socket and bulb assembly N·m (kgf·m, ft·lbf) (0.7―1.2, 5.1―8.7)
Page 43 Taillights, High-mount brake light Due to the complexity and difficulty of the procedure, the LED bulbs must be replaced by an Authorized Mazda Dealer. NOTE LED bulb replacement is not possible because it is built into the unit. Replace the unit.
Page 44 CX-9_8CA8-EA-11G_Edition1 Page522 Thursday, June 23 2011 11:6 AM Black plate (522,1) Maintenance and Care Owner Maintenance Rear turn signal lights, Rear side- Rear turn signal lights marker light 1. Turn the bolts counterclockwise and remove them. Rear side-marker light 2. Pull the unit rearward to remove it. 4.
Page 45: Reverse Lights
4. Install the new bulb in the reverse order of removal. NOTE To replace the bulb, contact an Authorized Mazda Dealer. License plate lights 1. Wrap a flathead screwdriver with a soft cloth to prevent damage to the lens and...
Page 46 CX-9_8CA8-EA-11G_Edition1 Page524 Thursday, June 23 2011 11:6 AM Black plate (524,1) Maintenance and Care Owner Maintenance Overhead light (Center, Rear) Vanity mirror lights Luggage compartment light 3. Install the new bulb in the reverse order of removal. Courtesy lights 8-46 Form No.8CA8-EA-11G...
Page 47: Fuses
If the same fuse blows again, avoid using that system and consult an Authorized Mazda Dealer as soon as possible. 4. Pull the fuse straight out with the fuse puller provided on the fuse block qFuse Replacement located in the engine compartment.
Page 48 2. Remove the fuse block cover or the WARNING relay box cover. Do not replace the main fuse by Fuse block yourself. Have an Authorized Mazda Dealer perform the replacement: Replacing the fuse by yourself is dangerous because the MAIN fuse is a high current fuse. Incorrect...
Page 49 CX-9_8CA8-EA-11G_Edition1 Page527 Thursday, June 23 2011 11:6 AM Black plate (527,1) Maintenance and Care Owner Maintenance qFuse Panel Description Fuse block (Engine compartment) FUSE DESCRIPTION PROTECTED COMPONENT RATING MAIN 150 A For protection of all circuits ENGINE 20 A Engine control system R HEATER 40 A Heater...
Page 50 CX-9_8CA8-EA-11G_Edition1 Page528 Thursday, June 23 2011 11:6 AM Black plate (528,1) Maintenance and Care Owner Maintenance FUSE DESCRIPTION PROTECTED COMPONENT RATING OUTLET CTR 15 A Accessory socket (Center) OUTLET RR 15 A Accessory socket (Rear) í í AC PWR 15 A Moonroof , DC/AC inverter í...
Page 51 CX-9_8CA8-EA-11G_Edition1 Page529 Thursday, June 23 2011 11:6 AM Black plate (529,1) Maintenance and Care Owner Maintenance í Relay box (Engine compartment) FUSE DESCRIPTION PROTECTED COMPONENT RATING 7.5 A Engine control system ― ― ― ― ― ― 8-51 í Some models. Form No.8CA8-EA-11G...
Page 52 CX-9_8CA8-EA-11G_Edition1 Page530 Thursday, June 23 2011 11:6 AM Black plate (530,1) Maintenance and Care Owner Maintenance Fuse block (Glove box) FUSE DESCRIPTION PROTECTED COMPONENT RATING OUTLET FR 15 A Accessory socket (Front) MIRROR 7.5 A Power control mirror ― ― ―...
Page 53 CX-9_8CA8-EA-11G_Edition1 Page531 Thursday, June 23 2011 11:6 AM Black plate (531,1) Maintenance and Care Owner Maintenance FUSE DESCRIPTION PROTECTED COMPONENT RATING ― ― ― OUTLET CTR ― ― OUTLET RR ― ― WIPER 30 A Windshield wiper and washer P.WIND 30 A Power windows (Driver-side) 8-53...
Page 54: Appearance Care
Occurrence Prevention Industrial pollutants and vehicle emissions It is necessary to have your Mazda drift into the air and mix with rain or dew washed and waxed to preserve its finish to form acids. These acids can settle on a vehicle's finish.
Page 55 The rings Chipped paint can lead to rust forming on can damage your vehicle's finish. your Mazda. Before this happens, repair the damage by using Mazda touch-up paint Prevention according to the instructions in this section.
Page 56: Exterior Care
NOTE Keep hands and scrapers clear of Mazda is not responsible for scratches the windshield when the wiper caused by automatic car washes or lever is in the AUTO position and improper washing.
Page 57 CX-9_8CA8-EA-11G_Edition1 Page535 Thursday, June 23 2011 11:6 AM Black plate (535,1) Maintenance and Care Appearance Care WARNING CAUTION Dry off brakes that have become wet Ø Do not use steel wool, abrasive by driving slowly, releasing the cleaners, or strong detergents accelerator pedal and lightly applying containing highly alkaline or the brakes several times until the brake...
Page 58 CAUTION coated with anti-corrosive material. If your Mazda is damaged and needs metal parts repaired or replaced, Thoroughly flush the underbody and make sure the body shop applies...
Page 59 CX-9_8CA8-EA-11G_Edition1 Page537 Thursday, June 23 2011 11:6 AM Black plate (537,1) Maintenance and Care Appearance Care NOTE WARNING Do not use a wire brush or any abrasive Dry wet brakes by driving very slowly cleaner, polishing compound, or solvent on and applying the brakes lightly until aluminum wheels.
Page 60: Interior Care
CX-9_8CA8-EA-11G_Edition1 Page538 Thursday, June 23 2011 11:6 AM Black plate (538,1) Maintenance and Care Appearance Care High water temperature and high water Interior Care pressure car washers are available depending on the type of high pressure qDashboard Precautions car washer device. If the car washer nozzle is put too close to the vehicle or Prevent caustic solutions such as perfume aimed at one area for an extended...
Page 61 CX-9_8CA8-EA-11G_Edition1 Page539 Thursday, June 23 2011 11:6 AM Black plate (539,1) Maintenance and Care Appearance Care NOTE To keep the fabric looking clean and fresh, take care of it. Otherwise its color Because genuine leather is a natural will be affected, it can be stained easily, material, its surface is not uniform and it and its fire-resistance may be reduced.
Page 62 Black plate (540,1) Maintenance and Care Appearance Care qCleaning the Floor Mats WARNING Rubber floor mats should be cleaned with Have an Authorized Mazda Dealer mild soap and water only. replace damaged seat belts immediately: WARNING Using damaged seat belts is dangerous.
