U Series 9 Product Manual, Rev. C Contents Introduction ......... . 1 Drive specifications .
Page 8
S.M.A.R.T. commands ....34 Seagate Technology support services ....37...
Page 9
U Series 9 Product Manual, Rev. C List of Figures Figure 1. Typical 5V startup and operation current profile ..11 Figure 2. Typical 12V startup and operation current profile ..11 Figure 3.
U Series 9 Product Manual, Rev. C Introduction This manual describes the functional, mechanical and interface specifications ® ® for the following Seagate U Series 9 model drives: • ST3160022A • ST3120025A • ST380012A These drives provide the following key features: •...
Unless otherwise noted, all specifications are measured under ambient con- ditions, at 25°C, and nominal power. For convenience, the phrases the drive and this drive are used throughout this manual to indicate ST3160022A, ST3120025A, and ST380012A model drives. Specification summary table The specifications listed in this table are for quick reference.
Page 14
U Series 9 Product Manual, Rev. C Drive specification ST3160022A ST3120025A ST380012A Average latency (msec) 4.16 Power-on to ready 10 sec (sec typical) Standby to ready 10 sec (sec typical) Startup current (typical) 12V (peak) 2.8 amps Track-to-track seek time (msec typical) <1.0 (read), <1.2 (write)
Page 15
U Series 9 Product Manual, Rev. C Drive specification ST3160022A ST3120025A ST380012A Ambient 0° to 60°C (operating) temperature –40° to 70°C (nonoperating) Temperature gradient 20°C (operating) (°C per hour max) 30°C (nonoperating) Relative humidity 5% to 90% (operating) 5% to 95% (nonoperating)
U Series 9 Product Manual, Rev. C Formatted capacity Formatted Guaranteed Model capacity sectors Bytes per sector ST3160022A 160 Gbytes 312,581,808 ST3120025A 120 Gbytes 234,441,648 ST380012A 80 Gbytes 156,301,488 2.2.1 LBA mode When addressing these drives in LBA mode, all blocks (sectors) are consec- utively numbered from 0 to n–1, where n is the number of guaranteed sectors...
U Series 9 Product Manual, Rev. C Seek time Seek measurements are taken with nominal power at 25°C ambient temper- ature. All times are measured using drive diagnostics. The specifications in the table below are defined as follows: • Track-to-track seek time is an average of all possible single-track seeks in both directions.
U Series 9 Product Manual, Rev. C 2.9.1 Power consumption Power requirements for the drives are listed in the table on page 10. Typical power measurements are based on an average of drives tested, under nominal conditions, using 5.0V and 12.0V input voltage at 25°C ambient temperature. •...
Page 20
U Series 9 Product Manual, Rev. C Power dissipation Average 5V typ 12V typ (watts, ST3160022A, 2-disc) (watts, 25° C) amps amps Spinup — — 2.8 (peak) Idle 0.482 0.424 Idle* (with offline activity) 0.587 0.530 Operating 40% r/w. 12.0 0.638...
U Series 9 Product Manual, Rev. C 2.9.1.1 Typical current profile Amps +5 Volt Current during spindle start — Typical Amperes Seconds Figure 1. Typical 5V startup and operation current profile +12 Volt Current during spindle start — Typical Amperes Amps Seconds Figure 2.
U Series 9 Product Manual, Rev. C 2.9.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 80-ohm resistive load on the +12 volt line or an equivalent 15-ohm resistive load on the +5 volt line. •...
U Series 9 Product Manual, Rev. C command. If the host has set the standby timer, the drive can also enter Standby mode automatically after the drive has been inactive for a specifi- able length of time. The standby timer delay is established using a Standby or Idle command.
U Series 9 Product Manual, Rev. C 2.10.2 Temperature gradient Operating: 20°C per hour (68°F per hour max), without condensation Nonoperating: 30°C per hour (86°F per hour max) 2.10.3 Humidity 2.10.3.1 Relative humidity Operating: 5% to 90% noncondensing (30% per hour max) Nonoperating: 5% to 95% noncondensing (30% per hour max) 2.10.3.2...
U Series 9 Product Manual, Rev. C 2.10.5 Shock All shock specifications assume that the drive is mounted securely with the input shock applied at the drive mounting screws. Shock may be applied in the X, Y or Z axis. 2.10.5.1 Operating shock These drives comply with the performance levels specified in this document...
(Number of seeks per second = 0.4 / (average latency + average access time) Table 1: Fluid Dynamic Bearing (FDB) motor acoustics Models Idle* Seek ST3160022A <2.5 bels (typ) 2.8 bels (typ) ST3120025A 2.7 bels (max) 3.0 bels (max) ST380012A *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T.
U Series 9 Product Manual, Rev. C 2.12 Electromagnetic immunity When properly installed in a representative host system, the drive operates without errors or degradation in performance when subjected to the radio frequency (RF) environments defined in the following table: Performance Reference Test...
Information Technology Equipment (ITE). Emission levels are defined by EN 55022, Class B and the immunity levels are defined by EN 55024. Seagate uses an independent laboratory to confirm compliance with the EC directives specified in the previous paragraph. Drives are tested in represen- tative end-user systems.
As a subassembly, no Federal Communications Commission verifica- tion or certification of the device is required. Seagate Technology LLC has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disc drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules.
U Series 9 Product Manual, Rev. C Configuring and mounting the drive This section contains the specifications and instructions for configuring and mounting the drive. Handling and static discharge precautions After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD) hazards.
U Series 9 Product Manual, Rev. C Jumper settings 3.2.1 Master/slave configuration The options jumper block shown in Figure 3 is used to configure the drive for operation. It is the 8-pin dual header between the interface connector and the power connector.
U Series 9 Product Manual, Rev. C 3.2.3 Alternate capacity jumper Some older computers may “hang” at startup if their BIOS detects a disc drive with a capacity greater than 32 Gbytes. This limits the drive’s capacity to 32 Gbytes when the alternate capacity jumper is used. To access the full capacity of the drive, you can: •...
U Series 9 Product Manual, Rev. C Drive mounting You can mount the drive in any orientation using four screws in the side- mounting holes or four screws in the bottom-mounting holes. See Figure 5 for drive mounting dimensions. Follow these important mounting precautions when mounting the drive: •...
U Series 9 Product Manual, Rev. C ATA interface These drives use the industry-standard ATA task file interface that supports 16-bit data transfers. It supports ATA programmed input/output (PIO) modes 0–4; multiword DMA modes 0–2, and Ultra DMA modes 0–5. The drive also supports the use of the IORDY signal to provide reliable high-speed data transfers.
U Series 9 Product Manual, Rev. C Drive pin # Host pin # and signal description Signal name Reset – Hardware Reset Ground Ground Host Data Bus Bit 7 Host Data Bus Bit 8 Host Data Bus Bit 6 Host Data Bus Bit 9 Host Data Bus Bit 5 DD10 Host Data Bus Bit 10...
U Series 9 Product Manual, Rev. C 4.1.1 Supported ATA commands The following table lists ATA-standard commands that the drive supports. For a detailed description of the ATA commands, refer to the Draft ATA-6 Standard. See “S.M.A.R.T. commands” on page 35 for details and subcommands used in the S.M.A.R.T.
Page 38
U Series 9 Product Manual, Rev. C Command name Command code (in hex) Set Multiple Mode S.M.A.R.T. Write Buffer Write DMA Write DMA Extended Write Multiple Write Multiple Extended Write Sectors Write Sectors Extended ATA-standard power-management commands Check Power Mode or E5 Idle or E3...
= none) Retired 0000 Retired 0400 Obsolete 0000 23–26 Firmware revision (8 ASCII character x.xx string, padded with blanks to end of string) 27–46 Drive model number: (40 ASCII charac- ST3160022A ters, padded with blanks to end of string) ST3120025A ST380012A...
Page 40
Number of sectors transferred during a xxxx Read Multiple or Write Multiple command 60–61 Total number of user-addressable LBA ST3160022A =0FFFFFFFh* sectors available ST3120025A = 234,441,648 ST380012A = 156,301,488 (see Section 2.2 for related information) *Note: The maximum value allowed in this field is: 0FFFFFFFh (268,435,455 sectors, 137 Gbytes).
Page 41
U Series 9 Product Manual, Rev. C Word Description Value Minimum multiword DMA transfer cycle 0078 time per word (120 nsec) Recommended multiword DMA transfer 0078 cycle time per word (120 nsec) Minimum PIO cycle time without IORDY 00F0 flow control (240 nsec) Minimum PIO cycle time with IORDY flow 0078 control (120 nsec)
Page 42
U Series 9 Product Manual, Rev. C Word Description Value 100–103 Total number of user-addressable LBA ST3160022A = 312,581,808 sectors available ST3120025A = 234,441,648 ST380012A = 156,301,488 (see Section 2.2 for related information) These words are required for drives that support the 48-bit addressing feature.
U Series 9 Product Manual, Rev. C Note. See the bit descriptions below for words 63, 88, and 93 of the Identify Drive data: Description (if bit is set to 1) Word 63 Multiword DMA mode 0 is supported. Multiword DMA mode 1 is supported. Multiword DMA mode 2 is supported.
Page 44
U Series 9 Product Manual, Rev. C value in the register does not represent a feature that the drive supports, the command is aborted. Power-on default has the read look-ahead and write caching features enabled. The acceptable values for the Features register are defined as follows: Enable write cache (default).
) that eliminates unnecessary drive returns. The diagnostic software ships with all new drives and is also available at: http://seatools.seagate.com. This drive is shipped with S.M.A.R.T. features disabled. You must have a recent BIOS or software package that supports S.M.A.R.T. to enable this feature.
Seagate storage solutions. The Reseller Marketplace at reseller.seagate.com, an exclusive service for US resellers participating in the Seagate Partner Program (SPP), is designed to streamline the purchas- ing process of Seagate solutions and provide unprecedented value to...
Page 48
If you need help installing your drive, consult your system's documentation or contact the dealer's support services department for assistance specific to your system. Seagate technical support is also available to assist you online at support.seagate.com or through one of our technical support service cen- ters.
Page 49
Resellers or end users of drive products should contact their place of purchase or one of the Seagate warranty service centers for assistance. Have your drive’s “ST” model number and serial number available. Authorized Service Centers In some countries outside the US, you can contact an Authorized Service Center for service.
Page 50
U Series 9 Product Manual, Rev. C European Support Services For European presales, technical support, and warranty service, dial the toll- free number for your specific country. If your country is not listed here, dial our European call center at +31-20-316-7222 from 8:30 .
Page 51
U Series 9 Product Manual, Rev. C Asia/Pacific Support Services For Asia/Pacific presales and technical support, dial the toll-free number for your specific country. The Asia/Pacific toll-free numbers are available from 6:00 . to 10:45 . and 12:00 . to 6:00 .
