Seagate Cheetah 15K.5 SAS Series Product Manual

Cheetah 15k.5 sas
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Cheetah 15K.5 SAS
ST3300655SS
ST3146855SS
ST373455SS

Advertisement

Table of Contents
loading

Related Manuals for Seagate Cheetah 15K.5 SAS Series

Summary of Contents for Seagate Cheetah 15K.5 SAS Series

  • Page 1 Cheetah 15K.5 SAS ST3300655SS ST3146855SS ST373455SS...
  • Page 2 Technology LLC in the United States and/or other countries. Cheetah is either a trademark or registered trademark of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners.
  • Page 3 Cheetah 15K.5 SAS Product Manual, Rev. C...
  • Page 4 Cheetah 15K.5 SAS Product Manual, Rev. C...

  • Page 5: Table Of Contents

    Contents Scope ............... . 1 Standards, compliance and reference documents .
  • Page 6 Seagate Technology support services ........
  • Page 7 List of Figures Figure 1. Cheetah 15K.5 SAS disc drive .............1 Figure 2.
  • Page 8 Cheetah 15K.5 SAS Product Manual, Rev. C...

  • Page 9: Scope

    Scope ® ® This manual describes Seagate Technology LLC, Cheetah SAS (Serial Attached SCSI) disc drives. Cheetah drives support the SAS Protocol specifications to the extent described in this manual. The SAS Inter- face Manual (part number 100293071) describes the general SAS characteristics of Cheetah 15K.5 and other Seagate SAS drives.
  • Page 10 Cheetah 15K.5 SAS Product Manual, Rev. C...

  • Page 11: Standards, Compliance And Reference Documents

    Section 8.3. Standards The Cheetah SAS family complies with Seagate standards as noted in the appropriate sections of this manual and the Seagate SAS Interface Manual, part number 100293071. The Cheetah disc drive is a UL recognized component per UL1950, CSA certified to CAN/CSA C22.2 No. 950- 95, and VDE certified to VDE 0805 and EN60950.

  • Page 12: Compliance

    Lead (Pb), in electronic products effective July 2006. A number of parts and materials in Seagate products are procured from external suppliers. We rely on the rep- resentations of our suppliers regarding the presence of RoHS substances in these parts and materials. Our...

  • Page 13: Reference Documents

    Seagate also has internal systems in place to ensure ongoing compliance with the RoHS Directive and all laws and regulations which restrict chemical content in electronic products. These systems include standard operat- ing procedures that ensure that restricted substances are not utilized in our manufacturing operations, labora- tory analytical validation testing, and an internal auditing process to ensure that all standard operating procedures are complied with.
  • Page 14 Cheetah 15K.5 SAS Product Manual, Rev. C...

  • Page 15: General Description

    General description Cheetah drives combine perpendicular recording, giant magnetoresistive (GMR) heads, partial response/max- imum likelihood (PRML) read channel electronics, embedded servo technology, and a Serial Attached SCSI (SAS) interface to provide high performance, high capacity data storage for a variety of systems including engi- neering workstations, network servers, mainframes, and supercomputers.

  • Page 16: Standard Features

    Standard features Cheetah drives have the following standard features: • 1.5 / 3 Gbit Serial Attached SCSI (SAS) interface • Integrated dual port SAS controller supporting the SCSI protocol • Support for SAS expanders and fanout adapters • Firmware downloadable using the SAS interface •...

  • Page 17: Reliability

    136,331,467 82040CB 2. Seagate drives also may be used at the maximum available capacity at a given block size, but the excess capacity above the guaranteed level will vary between other drive families and from generation to genera- tion, depending on how each block size actually formats out for zone frequencies and splits over servo bursts.

  • Page 18: Options (Factory Installed)

    Options (factory installed) You may order the following items which are incorporated at the manufacturing facility during production or packaged before shipping. Some of the options available are (not an exhaustive list of possible options): • Other capacities can be ordered depending on sparing scheme and sector size requested. •...

  • Page 19: Performance Characteristics

    Performance characteristics This section provides detailed information concerning performance-related characteristics and features of Cheetah drives. Internal drive characteristics ST3300655SS ST3146855SS ST373455SS *,** Drive capacity 300.0 146.8 73.4 Gbytes (formatted, rounded off value) Read/write data heads Tracks per surface (total) 74,340 74,340 74,340 Tracks (user accessible)

  • Page 20: Format Command Execution Time (Minutes)

    4.2.2 Format command execution time (minutes) ST3300655SS ST3146855SS ST373455SS Maximum (with verify) Maximum (without verify) Execution time measured from receipt of the last byte of the Command Descriptor Block (CDB) to the request for a Status Byte Transfer to the Initiator (excluding connect/disconnect). 4.2.3 General performance characteristics Sustainable disc transfer rate*:...

  • Page 21: Prefetch/Multi-Segmented Cache Control

    The START STOP UNIT command may be used to command the drive to stop the spindle. Stop time is 30 sec- onds (maximum) from removal of DC power. There is no power control switch on the drive. Prefetch/multi-segmented cache control The drive provides a prefetch (read look-ahead) and multi-segmented cache control algorithms that in many cases can enhance system performance.

  • Page 22: Caching Write Data

    4.5.1 Caching write data Write caching is a write operation by the drive that makes use of a drive buffer storage area where the data to be written to the medium is stored while the drive performs the Write command. If read caching is enabled (RCD=0), then data written to the medium is retained in the cache to be made avail- able for future read cache hits.

  • Page 23: Reliability Specifications

    Reliability specifications The following reliability specifications assume correct host and drive operational interface, including all inter- face timings, power supply voltages, environmental requirements and drive mounting constraints. Seek error rate: Less than 10 errors in 10 seeks Read Error Rates Recovered Data Less than 10 errors in 10 bits transferred (OEM default settings)

  • Page 24: Seek Errors

    5.1.3 Seek errors A seek error is defined as a failure of the drive to position the heads to the addressed track. After detecting an initial seek error, the drive automatically performs an error recovery process. If the error recovery process fails, a seek positioning error (Error code = 15h or 02h) will be reported with a Hardware error (04h) in the Sense Key.

  • Page 25: Hot Plugging The Drive

    5.2.3 Hot plugging the drive When a disc is powered on by switching the power or hot plugged, the drive runs a self test before attempting to communicate on its’ interfaces. When the self test completes successfully, the drive initiates a Link Reset starting with OOB.

  • Page 26: Thermal Monitor

    Reporting control Reporting is controlled by the MRIE bits in the Informational Exceptions Control mode page (1Ch). Subject to the reporting method, the firmware will issue to the host an 01-5Dxx sense code. The error code is preserved through bus resets and power cycles. Determining rate S.M.A.R.T.

  • Page 27: Drive Self Test (Dst)

    If DST encounters an error during either of these tests, it reports a fault condition. If the drive fails the test, remove it from service and return it to Seagate for service. 5.2.6.1 DST failure definition The drive will present a “diagnostic failed”...
  • Page 28 DST. It is the responsibility of the host application to determine the “not ready” cause. While not technically part of DST, a Not Ready condition also qualifies the drive to be returned to Seagate as a failed drive.

  • Page 29: Product Warranty

    Seagate’s option and at no charge to the customer, if returned by customer at customer’s expense to Seagate’s designated facility in accordance with Seagate’s warranty procedure.
  • Page 30 Cheetah 15K.5 SAS Product Manual, Rev. C...

  • Page 31: Physical/Electrical Specifications

    Physical/electrical specifications This section provides information relating to the physical and electrical characteristics of the drive. AC power requirements None. DC power requirements The voltage and current requirements for a single drive are shown below. Values indicated apply at the drive connector.
  • Page 32 Table 3: DC power requirements ST3146855SS ST3146855SS ST3146855SS 1.5 Gbit mode 3 Gbit mode Notes (Amps) (Amps) (Amps) (Amps) Voltage +12V [2] +12V [2] Regulation ±5% ±5% [2] ±5% ±5% [2] Avg idle current DCX [1] [6] 0.76 0.56 0.75 0.56 Maximum starting current (peak DC) DC...

  • Page 33: Conducted Noise Immunity

    Degrees C ambient. For +12 V, a –10% tolerance is allowed during initial spindle start but must return to ±5% before reaching 15,000 RPM. The ±5% must be maintained after the drive signifies that its power-up sequence has been completed and that the drive is able to accept selection by the host initiator. See +12V current profile in Figure 2.

  • Page 34: Figure 2. Typical St3300655Ss Drive +12V Current Profile

    Figure 2. Typical ST3300655SS drive +12V current profile Figure 3. Typical ST3300655SS drive +5V current profile Cheetah 15K.5 SAS Product Manual, Rev. C...

  • Page 35: Figure 4. Typical St3146855Ss Drive +12V Current Profile

    Figure 4. Typical ST3146855SS drive +12V current profile Figure 5. Typical ST3146855SS drive +5V current profile Cheetah 15K.5 SAS Product Manual, Rev. C...

  • Page 36: Figure 6. Typical St373455Ss Drive +12V Current Profile

    Figure 6. Typical ST373455SS drive +12V current profile Figure 7. Typical ST373455SS drive +5V current profile Cheetah 15K.5 SAS Product Manual, Rev. C...

  • Page 37: Power Dissipation

    Power dissipation ST3300655SS in 3 Gbit operation Typical power dissipation under idle conditions in 3Gb operation is 14.34 watts (48.93 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 8).

  • Page 38: Figure 9. St3146855Ss (3 Gbit) Dc Current And Power Vs. Input/Output Operations Per Second

    in 3 Gbit operation ST3146855SS Typical power dissipation under idle conditions in 3Gb operation is 11.8 watts (40.27 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 8). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis.

  • Page 39: Figure 10. St373455Ss (3 Gbit) Dc Current And Power Vs. Input/Output Operations Per Second

    in 3 Gbit operation ST373455SS Typical power dissipation under idle conditions in 3Gb operation is 10.33 watts (35.25 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 8). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis.

  • Page 40: Environmental Limits

    Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 36°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. HDA Temp.

  • Page 41: Relative Humidity

    6.4.2 Relative humidity The values below assume that no condensation on the drive occurs. a. Operating 5% to 95% non-condensing relative humidity with a maximum gradient of 20% per hour. b. Non-operating 5% to 95% non-condensing relative humidity. 6.4.3 Effective altitude (sea level) a.

  • Page 42: Figure 12. Recommended Mounting

    36 in (914 mm) Drives packaged in single or multipacks with a gross weight of 20 pounds (8.95 kg) or less by Seagate for general freight shipment shall withstand a drop test from 48 inches (1,070 mm) against a concrete floor or equivalent.

  • Page 43: Air Cleanliness

    The sil- ver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%.

  • Page 44: Acoustics

    There will not be any discrete tones more than 10 dB above the masking noise on typical drives when mea- sured according to Seagate specification 30553-001. There will not be any tones more than 24 dB above the masking noise on any drive.

  • Page 45: Defect And Error Management

    Defect and error management Seagate continues to use innovative technologies to manage defects and errors. These technologies are designed to increase data integrity, perform drive self-maintenance, and validate proper drive operation. SCSI defect and error management involves drive internal defect/error management and SAS system error considerations (errors in communications between the initiator and the drive).
  • Page 46 The drive firmware error recovery algorithms consists of 11 levels for read recoveries and five levels for write. Each level may consist of multiple steps, where a step is defined as a recovery function involving a single re- read or re-write attempt. The maximum level used by the drive in LBA recovery is determined by the read and write retry counts.

  • Page 47: Sas System Errors

    SAS system errors Information on the reporting of operational errors or faults across the interface is given in the SAS Interface Manual. The SSP Response returns information to the host about numerous kinds of errors or faults. The Receive Diagnostic Results reports the results of diagnostic operations performed by the drive. Status returned by the drive to the initiator is described in the SAS Interface Manual.

  • Page 48: Deferred Auto-Reallocation

    DAR is most effective when AWRE and ARRE are enabled—this is the default setting from the Seagate factory. With AWRE and ARRE disabled DAR is unable to reallocate the failing location and will report an error sense code indicating that a write command is being attempted to a previously failing location.

  • Page 49: Installation

    Installation Cheetah disc drive installation is a plug-and-play process. There are no jumpers, switches, or terminators on the drive. SAS drives are designed to be used in a host system that provides a SAS-compatible backplane with bays designed to accommodate the drive. In such systems, the host system typically provides a carrier or tray into which you need to mount the drive.

  • Page 50: Cooling

    Cooling Cabinet cooling must be designed by the customer so that the ambient temperature immediately surrounding the drive will not exceed temperature conditions specified in Section 6.4.1, "Temperature." The rack, cabinet, or drawer environment for the drive must provide heat removal from the electronics and head and disc assembly (HDA).

  • Page 51: Drive Mounting

    Drive mounting Mount the drive using the bottom or side mounting holes. If you mount the drive using the bottom holes, ensure that you do not physically distort the drive by attempting to mount it on a stiff, non-flat surface. The allowable mounting surface stiffness is 80 lb/in (14.0 N/mm).
  • Page 52 Cheetah 15K.5 SAS Product Manual, Rev. C...

  • Page 53: Interface Requirements

    Interface requirements This section partially describes the interface requirements as implemented on Cheetah drives. Additional infor- mation is provided in the SAS Interface Manual (part number 100293071). SAS features This section lists the SAS-specific features supported by Cheetah drives. 9.1.1 task management functions Table 6 lists the SAS task management functions supported.

  • Page 54: Dual Port Support

    Dual port support Cheetah SAS drives have two independent ports. These ports may be connected in the same or different SCSI domains. Each drive port has a unique SAS address. The two ports run at the same link rate. The first port to successfully complete speed negotiation sets the link rate support by both ports.

  • Page 55: Scsi Commands Supported

    SCSI commands supported Table 8 lists the SCSI commands supported by Cheetah drives. Table 8: Commands supported by Cheetah 15K.5 SAS family drives Command name Command code Supported Change Definition Compare Copy Copy and Verify Format Unit [1] DPRY bit supported DCRT bit supported STPF bit supported IP bit supported...
  • Page 56 Table 8: Commands supported by Cheetah 15K.5 SAS family drives (continued) Command name Command code Supported Non-medium Error page (06h) Pages Supported list (00h) Read Error Counter page (03h) Read Reverse Error Counter page (04h) Self-test Results page (10h) Background Medium Scan page (15h) Start-stop Cycle Counter page (0Eh) Temperature page (0Dh) Verify Error Counter page (05h)
  • Page 57 Table 8: Commands supported by Cheetah 15K.5 SAS family drives (continued) Command name Command code Supported Reassign Blocks Receive Diagnostic Results Supported Diagnostics pages (00h) Translate page (40h) Release Release (10) Request Sense Actual Retry Count bytes Extended Sense Field Pointer bytes Reserve 3rd Party Reserve Extent Reservation...
  • Page 58 Table 8: Commands supported by Cheetah 15K.5 SAS family drives (continued) Command name Command code Supported FUA bit Write Long Write Same PBdata LBdata XDRead XDWrite XPWrite Cheetah drives can format to 512, 520, 524, or 528 bytes per logical block. Warning.

  • Page 59: Inquiry Data

    9.3.1 Inquiry data Table 9 lists the Inquiry command data that the drive should return to the initiator per the format given in the SAS Interface Manual. Table 9: Cheetah 15K.5 SAS inquiry data Bytes Data (hex) 0-15 xx** Vendor ID 16-31 Product ID 32-47...
  • Page 60 Select command before the drive achieves operating speed and is “ready.” An attempt to do so results in a “Check Condition” status. On drives requiring unique saved values, the required unique saved values are stored into the saved val- ues storage location on the media prior to shipping the drive. Some drives may have unique firmware with unique default values also.
  • Page 61 9.3.2.1 ST3300655SS Mode Sense data MODE DATA HEADER: 03 fa 00 10 00 00 00 08 BLOCK DESCRIPTOR: 22 ec b2 5c 00 00 02 00 MODE PAGES: 81 0a c0 0b ff 00 00 00 05 00 ff ff 81 0a ff ff 00 00 00 00 ff 00 ff ff 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00...
  • Page 62 9.3.2.2 ST3146855SS Mode Sense data MODE DATA HEADER: 03 fa 00 10 00 00 00 08 BLOCK DESCRIPTOR: 11 17 73 30 00 00 02 00 MODE PAGES: 81 0a c0 0b ff 00 00 00 05 00 ff ff 81 0a ff ff 00 00 00 00 ff 00 ff ff 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00...
  • Page 63 9.3.2.3 ST373455SS Mode Sense data MODE DATA HEADER: 03 fa 00 10 00 00 00 08 BLOCK DESCRIPTOR: 08 8b b9 98 00 00 02 00 MODE PAGES: 81 0a c0 0b ff 00 00 00 05 00 ff ff 81 0a ff ff 00 00 00 00 ff 00 ff ff 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00...

  • Page 64: Miscellaneous Operating Features And Conditions

    Miscellaneous operating features and conditions Table 10 lists various features and conditions. A “Y” in the support column indicates the feature or condition is supported. An “N” in the support column indicates the feature or condition is not supported. Table 10: Miscellaneous features Supported Feature or condition...

  • Page 65: Sas Physical Interface

    Figure 16 shows the location of the SAS device connector J1. Figures 17 and 18 provide the dimensions of the SAS device. Details of the physical, electrical, and logical characteristics are provided within this section. The operational aspects of Seagate’s SAS drives are provided in the SAS Interface Manual.. SAS Interface connector Figure 16.

  • Page 66: Figure 17. Sas Connector Dimensions

    0.80 (6X) 5.92 7.62 4.65 0.52 0.08 x 45 2.00 (3X) 0.45 0.03 (7X) 5.08 0.10 M E 42.73 REF. 41.13 0.15 0.20 B 0.30 0.05 (2X) 1.10 4.00 0.08 C OF DATUM D 0.15 D R0.30 0.08 (4X) 0.30 0.05 (4X) SEE Detail1 33.43...

  • Page 67: Physical Characteristics

    Detail A 6.10 0.30 0.05 x 45 (5X) 2.25 0.05 0.40 0.05 X 45 (3X) 4.85 0.05 0.10 B CORING ALLOWED IN THIS AREA. 4.40 0.15 R0.30 0.08 SEE Detail 2 1.95 0.08 0.35 0.05 SECTION C - C 3.90 0.15 SECTION A - A CONTACT SURFACE FLUSH...

  • Page 68: Electrical Description

    9.4.4 Electrical description SAS drives use the device connector for: • DC power • SAS interface • Activity LED This connector is designed to either plug directly into a backpanel or accept cables. 9.4.5 Pin descriptions This section provides a pin-out of the SAS device and a description of the functions provided by the pins. Table 12: SAS pin descriptions Signal name...

  • Page 69: Sas Transmitters And Receivers

    9.4.6 SAS transmitters and receivers A typical SAS differential copper transmitter and receiver pair is shown in Figure 19. The receiver is AC cou- pling to eliminate ground shift noise. Differential Transmitter Receiver Transfer Medium Figure 19. SAS transmitters and receivers 9.4.7 Power The drive receives power (+5 volts and +12 volts) through the SAS device connector.

  • Page 70: Differential Signals

    The Ready LED Out signal is designed to pull down the cathode of an LED. The anode is attached to the proper +3.3 volt supply through an appropriate current limiting resistor. The LED and the current limiting resis- tor are external to the drive. See Table 14 for the output characteristics of the LED drive signals. Table 14: LED drive signal State...

  • Page 71: Figure 20. Receive Eye Mask

    9.5.2.1.2 Receive eye mask Figure 20 describes the receive eye mask. This eye mask applies to jitter after the application of a single pole high-pass frequency-weighting function that progressively attenuates jitter at 20 dB/decade below a frequency of ((bit rate) / 1.667). Absolute amplitude (in V)

  • Page 72: Figure 22. Sinusoidal Jitter Mask

    The leading and trailing edge slopes of figure 20 shall be preserved. As a result the amplitude value of Z1 is less than that given in table 17 and Z1 and Z1 shall be defined from those slopes by the following equa- tion: )xadditional sinusoidal jitter –...
  • Page 73 9.5.2.2 Transmitter signal characteristics Table 16 specifies the signal requirements at the transmitter end of a TxRx connection as measured into the zero-length test load. All specifications are based on differential measurements. The OOB sequence is performed at signal voltage levels corresponding to the lowest supported transfer rate. Table 16 specifies the signal characteristics.
  • Page 74 9.5.2.3 Receiver signal characteristics Table 17 defines the compliance point requirements of the signal at the receiver end of a TxRx connection as measured into the test loads specified in figure 23 and figure 24. Table 17: Receiver signal characteristics Signal characteristic Units 1.5 Gbps...
  • Page 75 9.5.2.3.2 Receiver jitter tolerance Table 19 defines the amount of jitter the receiver shall tolerate . Table 19: Receiver jitter tolerance 1.5 Gbps 3.0 Gbps Sinusoidal Deterministic Total Sinusoidal Deterministic Total e,f,h e,g,h jitter jitter jitter jitter jitter jitter 0.10 0.35 0.65 0.10...
  • Page 76 Table 20: Impedance requirements (Sheet 2 of 2) Requirement Units 1.5 Gbps 3.0 Gbps Common mode impedance 20 min/40 max 20 min/40 max Transmitter source termination Differential impedance 60 min/115 max 60 min/115 max Differential impedance imbalance Common mode impedance 15 min/40 max 15 min/40 max a All times indicated for time domain reflectometer measurements are recorded times.

  • Page 77: Figure 23. Compliance Interconnect Test Load

    A combination of a zero-length test load and the transmitter compliance transfer function (TCTF) test load methodology is used for the specification of transmitter characteristics. This methodology specifies the trans- mitter signal at the test points on the required test loads. The transmitter uses the same settings (e.g., pre- emphasis, voltage swing) with both the zero-length test load and the TCTF test load.

  • Page 78: Figure 24. Zero-Length Test Load

    Figure 24 shows the zero-length test load. 50 ohm 10 nF Probe points 10 nF 50 ohm SAS internal connector Figure 24. Zero-length test load Figure 25 shows an ISI loss example at 3.0 Gbps. (dB) Compliance interconnect magnitude response and ISI loss example for 3.0 Gbps ISI loss >...
  • Page 79 9.5.2.5 Receiver characteristics The drive receiver is A.C. coupled. The receive network terminates the TxRx connection by a 100 ohm equiva- lent impedance as specified in table 20. The receiver operates within a BER of 10 when a SAS signal with valid voltage and timing characteristics is delivered to the compliance point from a 100 ohm source.
  • Page 80 Cheetah 15K.5 SAS Product Manual, Rev. C...

  • Page 81: Seagate Technology Support Services

    Seagate Service Centers Presales Support Our Presales Support staff can help you determine which Seagate products are best suited for your specific application or computer system, as well as product availability and compatibility. Technical Support Seagate technical support is available to assist you online at support.seagate.com or through one of our call...
  • Page 82 Data Recovery Services Seagate offers data recovery services for all formats and all brands of storage media. Our Data Recovery Ser- vices labs are currently located in North America. To speak with a case management representative, call 1-800-475-0143. Additional information, including an online request form and data loss prevention resources, is available at www.datarecovery.seagate.com.
  • Page 83 European support services For presales and technical support in Europe, dial the Seagate Service Center toll-free number for your spe- cific location. If your location is not listed here, dial our presales and technical support call center at +1-405- 324-4714 from 8:00 .
  • Page 84 ., Monday through Friday. Warranty service for Australia is available from 10:00 . to 7:00 ., April through October, and from 11:00 . to 8:00 . November through March (Australian Eastern time) Monday through Friday. Seagate Service Centers Call center Toll-free Direct dial Australia 1800-14-7201 —...
  • Page 85 Index unformatted 11 check condition status 56 chemical pollutants 35 Numerics class B limit 3 clear ACA function 45 12 volt clear task set function 45 pins 61 commands supported 47 5 volt pins 61 condensation 33 condition met/good status 56 connector illustrated 59 abort task set function 45...
  • Page 86 environment 42 requirements 45 environmental intermediate/condition met/good status 56 limits 32 intermediate/good status 56 requirements 15 internal data rate 11 environmental control 35 internal defects/errors 37 error internal drive characteristics 11 management 37 IRAW 40 rates 15 errors 37 jumpers 41 FCC rules and regulations 3 features 8 latency...
  • Page 87 receivers 61 recommended mounting 34 noise Recoverable Errors 15 audible 3 recovered media data 15 noise immunity 25 reference non-operating 33 documents 5 temperature 32 relative humidity 33 non-operating vibration 35 reliability 9 specifications 15 reliability and service 16 repair and return information 21 office environment 35 reporting actual retry count 56 operating 33...
  • Page 88 surface stiffness allowable for non-flat surface 43 switches 41 synchronized spindle operation 56 system chassis 43 task management functions 45 Abort task set 45 Clear ACA 45 Clear task set 45 terminate task 45 task management response codes 45 Function complete 00 45 Function not supported 05 45 Function reject 04 45 task set full status 56...
  • Page 90 Seagate Technology LLC 920 Disc Drive, Scotts Valley, California 95066-4544, USA Publication Number: 100384784, Rev. C, Printed in USA...
