Thank you very much for purchasing the ZOOM
Please read this manual carefully to learn about all the functions of the
so that you will be able to use it fully for a long time.
Keep this manual in a convenient place for reference when necessary.
* A printed list of effect parameters is not included with the
Please download a copy from the ZOOM website. → http://www.zoom.co.jp/downloads/
Copying or reproduction of this document in whole or in part without permission is prohibited.
OPERATION MANUAL
.
© 2012 ZOOM CORPORATION
.
If the
hours, it will turn off automatically
by default.
If you want the power to stay ON all the time,
please see "4 To set the Power Management
function" on page 22 and set the value to OFF.
is not used for 10

Advertisement

Table of Contents
loading

Related Manuals for Zoom MULTISTOMP MS-100BT

Summary of Contents for Zoom MULTISTOMP MS-100BT

  • Page 1 * A printed list of effect parameters is not included with the function" on page 22 and set the value to OFF. Please download a copy from the ZOOM website. → http://www.zoom.co.jp/downloads/ © 2012 ZOOM CORPORATION Copying or reproduction of this document in whole or in part without permission is prohibited.

  • Page 2: Table Of Contents

    Contents Introduction ………………………………………… 3 Tapping the Tempo ……………………………… 18 Usage and Safety Precautions …………………… 4 Using Bluetooth Functions ……………………… 20 Part Names ………………………………………… 6 Changing Various Settings ……………………… 21 Turning the Power ON ……………………………… 8 Effect Types ……………………………………… 26 Adjusting Effects ………………………………… 10 Restoring the to its Factory Default Settings …...

  • Page 3: Introduction

    StompShare includes a wide variety of effects, ranging from emulations of classic gear and standard pedals that belong in every setup to amp models and unique ZOOM original effects. After auditioning these effects and trying them out, you can easily buy the ones you like. We plan to continue increasing the variety of effects available in the future. Download the StompShare app for free from the App Store.

  • Page 4: Usage And Safety Precautions

    OFF and disconnect other cables. Contact the store where you bought the unit Do not drop, bump or apply excessive force to the unit. or ZOOM service with the following information: product model, serial number and specific Be careful not to allow foreign objects or liquids to enter the unit.
  • Page 5 U.S. and other countries. Bluetooth and the Bluetooth logo are registered trademarks of Bluetooth SIG, Inc. and are used under license by ZOOM CORPORATION. All other trademarks, product names and company names mentioned in this documentation are the property of their respective owners.

  • Page 6: Part Names

    DC9V AC adapter jack Bluetooth To power the unit from an outlet, Use to connect with an iOS device connect an AD-16 adapter here and add new effects ( →P20). (→P8). Use also to update the firmware (→P25). OUTPUT jacks INPUT jack Connect to an amp or another Connect a guitar.
  • Page 7 Parameter knobs Cursor keys From the left Parameter knob 1 [ Turn left and right to adjust the parameter. Press to open the MENU where you can remove and rearrange effects and make various settings (→P14, 21). You can also check the firmware version (→P25). Up and down cursor keys [ Parameter knob 2 [ Press to change the effect type.

  • Page 8: Turning The Power On

    Plug a guitar cable into the INPUT jack. To turn the power ON Lower the amplifier’s volume all the way. Power the unit with batteries or an adapter. <When using batteries> Open the cover on the bottom of the unit and insert batteries in the compartment.
  • Page 9 Edit Screen shows parameter being edited Display information The Home Screen shows the current effect Effect type Page tabs Parameter names Virtual knob Parameter values HINT Graphic for selected effect Shows other effects are in this direction. adjusted, multiple page tabs will be shown. HINT parameter values.

  • Page 10: Adjusting Effects

    Confirm that the Home Screen is shown. To select an effect type To turn an effect ON and OFF Press either Press HINT See step 2 of ”To add an effect” . (See page 14.) To adjust parameters NOTE Turn Adjusting Effects...
  • Page 11 To change the page Effect processing limit T h e a l l o w s y o u to combine 6 effects as you like. Press However, if you combine effect types that require great amounts of processing power (amp models, for example), the available processing The next page opens.

  • Page 12: Selecting And Saving Patch Memories

    Confirm that the Home Screen is shown. Select the patch memory to be saved with a new name. To select a patch memory Turn When shipped from the factory, the automatic patch Press memory saving function is active. As soon as a parameter is adjusted this change is automatically saved.

  • Page 13: Changing Patch Memories With The Footswitch

    Confirm that the Home Screen is shown. To cycle through patch memories in the list in order using the footswitch To add or remove patch memories to a list that the footswitch cycles through Open the MEMORY list. Open the MEMORY list. Press Press Change the patch memory.

  • Page 14: Using 2 Or More Effects

    Confirm that the Home Screen is shown. To remove an effect To add an effect Open the MENU. Open the ADD EFFECT UNIT screen. Press Press and hold either for 1 second Select DELETE EFFECT UNIT. Select the effect category. Turn Press Press any...
  • Page 15 Select the effect to move and ”lift” it. To scroll through the effects shown Turn When multiple effects are in use, scroll to change the (Select) visible one. Press either Press (Lift) HINT Shows the effect number counting from the right. Shows how many effects are in this direction.

  • Page 16: Using The Tuner

    To activate the Tuner To change the tuner’s standard pitch Confirm that the Tuner Screen is open. Press Press hold for 1 second Turn NOTE A setting must be changed to make pressing and holding the footswitch activate Tap Tempo. (See page 21.) To select the tuner type Confirm that the Tuner Screen is open.
  • Page 17 CHROMATIC To tune a instrument The chromatic tuner shows the nearest pitch name (semitone) and how far the input sound is from that pitch. Play the open string that you want to tune and tune it. Other tuner types Depending on the selected type, the nearest string Chromatic tuner name and how far the sound input is from that pitch The name of the nearest note and the pitch accuracy...

  • Page 18: Tapping The Tempo

    Delay effects and some modulation and filter effects can Tap the footswitch 2 or more times at the be synchronized to the tempo. Select an effect that can be desired tempo. synchronized, and set its Time, Rate or other parameter that can be synchronized to a or note value.
  • Page 19 To tap tempo by hand Open an effect that can be synchronized to the tempo on the Home Screen. (See page 10, 26.) Open the parameter editing screen. Press Tap the knob 2 or more times at the desired tempo. Press The ON/OFF indicator flashes in time with the tempo.

  • Page 20: Using Bluetooth Functions

    Select ZOOM MS-100BT on the iOS device. To connect to an iOS device To connect to an iOS device, you must pair the connections, see the Help guide of the with the iOS device. StompShare app. Open the MENU. connected, ON is selected automatically.

  • Page 21: Changing Various Settings

    To change various settings To set the function activated by pressing and holding the footswitch Open the MENU. Set the function activated by pressing the footswitch Press continuously for 1 second to TUNER or TAP TEMPO. Select HOLD FOR TUNER/TAP from the SETTINGS menu.
  • Page 22 To set the tuner mode To set the Power Management function Select BYPASS/MUTE TUNER from the SETTINGS menu. Select POWER MANAGEMENT from the SETTINGS menu. Turn Turn Press Press Set the tuner mode Set the Power Management function. Turn Turn Press Press HINT...
  • Page 23 To set the Auto Save function To select the battery type Select AUTO SAVE from the SETTINGS menu. Select BATTERY TYPE from the SETTINGS menu. Turn Turn Press Press Set the Auto Save function. Set the type of batteries used. Turn Turn Press...
  • Page 24 To adjust the display contrast To set the amount of time until the backlight dims Select LCD CONTRAST from the SETTINGS menu. Select LCD BACKLIGHT from the SETTINGS menu. Turn Turn Press Press Adjust the display contrast. Set the amount of time until the backlight dims. Turn Turn Press...
  • Page 25 To view the firmware versions Open the MENU. Press Select VERSION. Turn Press The firmware version is shown. HINT Use the StompShare app to check for the latest firmware. If there is newer firmware, use StompShare to update the pedal. Changing Various Settings...

  • Page 26: Effect Types

    This effect uses the comb filter that results from fixing the CombFLTR ZOOM's unique noise reduction modulation of the flanger like an cuts noise during pauses in equalizer. playing without affecting the tone.
  • Page 27 Tempo Tempo Category Effect type Effect explanation Category Effect type Effect explanation sync. sync. This effect varies the sound like a Simulation of the Ibanez TS808, talking modulator. which is loved by many guitarists T Scream as a booster and has inspired This envelope filter has the flavor numerous clones.
  • Page 28 A high gain sound with even with a built-in tube. Z Wild more overdrive boost. ZOOM original unadorned clean Z Clean L e a d a b r i g h t a n d s m o o t h sound.
  • Page 29 Tempo Tempo Category Effect type Effect explanation Category Effect type Effect explanation sync. sync. Modeled sound of a Fender Twin The 3-channel high gain sound FD COMBO Reverb ('65), which is loved by of a Diezel Herbert, which is guitarists in various genres. DZ DRIVE a h a n d m a d e G e r m a n g u i t a r amplifier that allows control of 3...
  • Page 30 Tempo Tempo Category Effect type Effect explanation Category Effect type Effect explanation sync. sync. This models the sound of a BOSS WarpPhase This phaser has a one way effect. SuperCho CH-1 SUPER CHORUS. This vibe sound features unique This analog flanger sound is TheVibe VinFLNGR undulations.
  • Page 31 Tempo Tempo Category Effect type Effect explanation Category Effect type Effect explanation sync. sync. This is a pitch shifter with little This effect produces an explosive Bomber sound variance for monophonic sound when picking. MonoPitch (single note) playing. This effect produces the sound This intelligent pitch shifter of a monophonic (single-note outputs the effect sound with the...
  • Page 32 Tempo Tempo Category Effect type Effect explanation Category Effect type Effect explanation sync. sync. This delay effect allows the use This stereo delay allows the left ModDelay of modulation. and right delay times to be set StereoDly separately. This analog delay simulation has AnalogDly a long delay with a maximum This effect applies a phaser to a...
  • Page 33 Tempo Category Effect type Effect explanation sync. This reverb effect simulates the TiledRoom acoustics of a tiled room. This reverb effect simulates a Spring spring reverb. This reverb effect simulates the Arena acoustics of a large enclosure DLY/REV such as a sports arena. This effect reproduces only the EarlyRef early reflections of reverb.

  • Page 34: Restoring The To Its Factory Default Settings

    Press the footswitch to execute it. To execute the All Initialize function The All Initialize function restores all the factory Press default settings. NOTE Executing the All Initialize function will restore all the settings of the , including its patch memories, to factory defaults.

  • Page 35: Troubleshooting

    The unit will not turn ON An effect is not working to the INPUT jack to start the unit. ”DSP Full!” appears on the effect graphic. In this case, the effect is bypassed (→P11). No sound or very low volume Batteries lose their charge quickly →P8).
  • Page 36 Cannot pair or connect with an Communication with the connected iOS device device is not possible Bluetooth function is set to PAIRING (→P20). the iOS device and the that the Bluetooth function is set much as possible to increase communication to ON (→P20).

  • Page 37: Specifications

    Output Maximum output level: Line +5dBm (with output load impedance of 10 k or more) AC adapter DC9V (center minus plug), 500 mA (ZOOM AD-16) Power Batteries Continuous operation using 2 AA alkaline batteries for about 7 hours with mono input or...

  • Page 38: Tuner Types

    Tuner Types String number / Note name Display Meaning GUITAR Standard tuning for guitars, including 7-string guitars OPEN A In open A tuning, the open strings make an A chord OPEN D In open D tuning, the open strings make a D chord OPEN E In open E tuning, the open strings make an E chord OPEN G...
  • Page 39 For EU Countries For U.S.A. Declaration of Conformity: This product complies with the requirements of This equipment has been tested and found to comply with the limits R&TTE Directive 1995/5/EC and for a Class B digital device, pursuant to part 15 of the FCC Rules. These ErP Directive 2009/125/EC and limits are designed to provide reasonable protection against harmful RoHS Directive 2011/65/EU...
  • Page 40 ZOOM CORPORATION 4-4-3 Surugadai, Kanda, Chiyoda-ku, Tokyo 101-0062 Japan http://www.zoom.co.jp Z2I-1528-02...
