Fujitsu ASTG24JF Operating Manual

Wall mounted type cool model
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

AIR CONDITIONER

Wall Mounted Type
COOL MODEL

Indoor Unit

ASTG24JF
ASTG30JF
ASTG34JF
KEEP THIS OPERATION MANUAL FOR FUTURE REFERENCE
FUJITSU GENERAL LIMITED

OPERATING MANUAL

REFRIGERANT
THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED
BY QUALIFIED PERSONNEL.
Refer to Commonwealth, State, Territory and local legislation,
regulations, codes, installation & operation manuals, before
the installation, maintenance and/or service of this product.
R410A
This Air Conditioner contains
and operates with refrigerant R410A.
PART No. 9315345509

Advertisement

Table of Contents
loading

Related Manuals for Fujitsu ASTG24JF

Summary of Contents for Fujitsu ASTG24JF

  • Page 1: Operating Manual

    THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED BY QUALIFIED PERSONNEL. Refer to Commonwealth, State, Territory and local legislation, regulations, codes, installation & operation manuals, before the installation, maintenance and/or service of this product. KEEP THIS OPERATION MANUAL FOR FUTURE REFERENCE FUJITSU GENERAL LIMITED PART No. 9315345509...

  • Page 2: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS ........En-1 SWING OPERATION .......... En-11 FEATURES AND FUNCTIONS ......En-2 ECONOMY OPERATION ........En-11 NAME OF PARTS ..........En-3 MANUAL AUTO OPERATION ......En-11 PREPARATION .............En-5 CLEANING AND CARE ........En-12 OPERATION ............En-6 SELECTING THE REMOTE CONTROLLER TIMER OPERATION ..........En-8 SIGNAL CODE ............En-14 SLEEP TIMER OPERATION .........En-9 TROUBLESHOOTING ........En-15...

  • Page 3: Features And Functions

    FEATURES AND FUNCTIONS FEATURES AND FUNCTIONS Energy saving and Comfortable function Clean function INVERTER REMOVABLE INTAKE GRILLE The indoor unit’s intake grille can be removed for easy clean- At the start of operation, large amount of power is used to ing and maintenance.

  • Page 4: Name Of Parts

    NAME OF PARTS Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6 To facilitate explanation, the accompanying illustration has been drawn to show all possible indicators; in actual operation, however, the display will only show those indicators appropriate to the current operation.
  • Page 5 Fig. 1 Indoor Unit Fig. 5 Remote Controller 1 Operating Control Panel (Fig. 2) F Signal Transmitter 2 MANUAL AUTO button G MODE button ● H ECONOMY button When the MANUAL AUTO button is pressed I SLEEP button in for more than 10 seconds, the forced cooling operation will start.

  • Page 6: Preparation

    PREPARATION CAUTION! Turn on the Power ● Take care to prevent infants from acciden- tally swallowing batteries. Turn on the circuit breaker ● When not using the Remote Controller for an extended period, remove the batteries to avoid possible leakage and damage to the unit.

  • Page 7: Operation

    OPERATION To Select Mode Operation Press the START/STOP button (Fig.5 L). The indoor unit’s OPERATION Indicator Lamp (green) (Fig. 3 5) will light. The air conditioner will start operating. Press the MODE button (Fig.5 G) to select the de- sired mode. Each time the button is pressed, the mode will change in the following order.
  • Page 8 OPERATION To Stop Operation Press the START/STOP button (Fig. 5 L). The OPERATION Indicator Lamp (green) (Fig.3 5) will go out. About AUTO CHANGEOVER Operation ● When AUTO CHANGEOVER operation ¿ rst selected, the fan will operate AUTO: at very low speed for about a few minutes, during which time the unit de- tects the room conditions and selects the proper operating mode.

  • Page 9: Timer Operation

    TIMER OPERATION Before using the timer function, be sure that the Remote Controller is set to the correct current time (☞ P.5). To Use the ON timer or OFF timer Press the START/STOP button (Fig. 5 L) To Cancel the Timer (if the unit is already operating, proceed to step 2).

  • Page 10: Sleep Timer Operation

    SLEEP TIMER OPERATION Unlike other timer functions, the SLEEP timer is used to set the length of time until air conditioner operate is stopped. To Use the SLEEP Timer To Cancel the Timer: While the air conditioner is operating or stopped, press the Use the TIMER MODE button to select SLEEP button (Fig.

  • Page 11: Adjusting The Direction Of Air Circulation

    ADJUSTING THE DIRECTION OF AIR CIRCULATION ● Adjust the up, down, left, and right AIR directions with the AIR DIRECTION buttons on the Remote Controller. ● Use the AIR DIRECTION buttons after the Indoor Unit has started operating and the airÀ ow-direction louvers have stopped moving.

  • Page 12: Swing Operation

    SWING OPERATION Begin air conditioner operation before performing this procedure. To select SWING Operation Press the SWING button (Fig. 5 O). The SWING Display (Fig. 6 [) will light. Each time the SWING button is pressed, the swing operation will change in the following order.

  • Page 13: Cleaning And Care

    CLEANING AND CARE ● Before cleaning the air conditioner, be sure to turn it off and disconnect the Power Supply Cord. CAUTION! ● Be sure the Intake Grille (Fig. 1 8) is installed securely. ● When removing and replacing the air ¿ lters, be sure not to touch the heat exchanger, as personal injury may result.
  • Page 14 CLEANING AND CARE Air Cleaning Filter Installation Replacing dirty Air cleaning ¿ lters 1. Open the Intake Grille and remove the Air Replace ¿ lters with the following components (purchased sep- arately). ¿ lters. ● POLYPHENOL CATECHIN AIR CLEANING FILTER : UTR-FA13-1 ●...

  • Page 15: Selecting The Remote Controller Signal Code

    CLEANING AND CARE Filter Indicator Reset (The special setting) • Can be used if set correctly during installation. ● Indicator Lamp Please consult authorized serviceman when using this function. • It lights on when it is time to clean the air ¿ lters. OPERATION Clean the ¿...

  • Page 16: Troubleshooting

    TROUBLESHOOTING In the event of a malfunction (burning smell, etc.), immediately stop operation, turn off the electrical WARNING! breaker and consult authorized service personnel. Merely turning off the unit’s power switch will not completely disconnect the unit from the power source.

  • Page 17: Operating Tips

    OPERATING TIPS AUTO Restart In Event of Power Interruption ● If a power interruption occurs during TIMER operation, the ● The power supply to the air conditioner is stopped by a timer will be reset and the indoor unit will begin (or stop) op- power interruption.
