AIR CONDITIONER
Wall Mounted Type
HEAT & COOL MODEL
(REVERSE CYCLE)
Indoor Unit
ASTG18LF
ASTG24LF
ASTG30LF
ASTG34LF
KEEP THIS OPERATION MANUAL FOR FUTURE REFERENCE
FUJITSU GENERAL LIMITED
9315345387_OM_EN.indb 1
9315345387_OM_EN.indb 1
OPERATING MANUAL
R410A
REFRIGERANT
This Air Conditioner contains
